C40 Controller Upgrade Kit installation instructions for the ClubTrack® 510 and ClubTrack 612 Treadmills. Please check the attached pdf for details...
read moreApplies to SCL800 Issue Symptoms The Obstruction error alerts the user that something is blocking the OBS sensors. When detected, the machine immediately slows to a stop and the "OBS Obstruction Detected" message is displayed. Typically an object is blocking the IR beam between the emitter and receiver OBS sensors. Other causes could include dirty sensor IR lens or a faulty damaged...
read moreApplies to 9.23, 9.27, TR211, TRM200-14 treadmills Issue symptoms This error is shown in the console TIME window indicating an incline problem. This error will occur if the incline is unable to move or if the incline position potentiometer is not functioning. When the E2 error occurs, all drive motor and lift motor motion stops and the display is blank except for the error display. ...
read moreApplies to SCL800 Issue Symptoms Error 55 occurs when a workout is started and the Holding Brake Lever is in the OFF "Released" position. The Holding Brake Lever must be in the ON "Normal" position to start a workout. The LPCA detects that the Holding Brake Manual Release lever switch signal is continuously in the Manual Release active state for longer than 5 seconds. The most ...
read moreApplies to SCL800 Issue Symptoms Error 53 means the Holding Brake has slipped when it should not. This error occurs when the LPCA detects the stairs moving while machine is STOPPED and the Holding Brake is engaged. The holding brake should not allow the stairs to slip or move when stopped or the power is switched OFF. This error triggers when the either the Holding Brake is engaged ...
read moreApplies to SCL800 Issue Symptoms Hardware version of Error 50, see 50 . The LPCA Hardware has detected that the Resistance Brake Current was too High. Too much current is being fed to the Resistance Brake resulting in the holding brake engaging. Error 52 triggers when the Resistance brake current is continuously greater than 2 Adc for longer than 410 ms. This event...
read moreApplies to Consumer EFX200/400, SCL800 Issue symptoms EFX200/400 Error 56 indicates the LPCA has lost communication with the DC motor assembly, which controls the magnetic brake assembly. The magnetic brake will remain at the last position successfully set by the DC motor, so the resistance applied by the brake will not change until new instructions are successfully received and...
read moreApplies to SCL800 Issue Symptoms Software version of Error 56, see 56. The LPCA software has detected that the Resistance Brake Current is too low. The Resistance Brake is not receiving enough current to properly slow the stairs and will result in the Hold Brake engaging. Error 51 triggers when the Resistance Brake current is continuously less than 100 milli‑Adc for longer ...
read moreApplies to Consumer EFX, AMT, UBK/RBK, EFX16, SCL800 Issue symptoms Consumer EFX, AMT, UBK/RBK, EFX16 This error is associated with eddy current EFXs, AMTs, Climbers and Bikes. The resistance (brake) control system constantly monitors the amount of current being demanded by the eddy current magnet. Error 50 indicates that the amount of current being demanded by the eddy current magnet is ...
read moreApplies to Chrono bike Issue symptoms Error 47 (High current) Battery charging current is or has been detected as too high. The error is only detected or cleared while pedaling because, when pedaling, the generator SHOULD be charging the battery. Error 48 (High voltage) Battery voltage is or has been detected as too high. Note: The battery fuse should be checked for all battery ...
read more6114 Madison Ct.
