Life Fitness - T3 - T3i

Repair Parts for Life Fitness T3 - T3i T3-XX00-0101

Brand: Life Fitness

Category: Residential Treadmills

Type: Non Folding Treadmills

Model Number:

Model Numbers are Unique Identifiers, they are important because they lead you to access diagrams and part lists specific to the version of a given model equipment you own. Bottom line, they help you get the right part. Note: Sometimes we put a serial prefix in this field to elicit versioning, and if this field is blank that means the model name alone will suffice for part selection.

T3-XX00-0101

Model Name: T3 - T3i

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

VIEWS

Catalog #	MPN	Part List Key	Quantity On Model	Part Description	Available Used	Model Compatibility List	New price
1005227-R	6821501	#	1	2.5 HP Drive Motor (Refurbished Only)	Yes	Model Compatibility List	$334.66 / Each Out Of Stock	10
1015426	6836101	#	1	Wire harness, Switch (used)	Yes	Model Compatibility List	$20.15 / Each	4
1015425	Optowireclamp	1	1	Opto Optical Wire Clamp (Used)	Yes	Model Compatibility List	$13.43 / Each	5,10
000348	7758401	#	1	Treadbelt Treadmill Belt 20 Inch Wide	Yes	Model Compatibility List	$388.42 / Each	15
1015433	lft5tooth	#	6	Tooth Lock Washer	No	Model Compatibility List	$5.36 / Each	2
1001781	k14003-0020	#	1	Incline Motor (Used)	Yes	Model Compatibility List	$186.82 / Each Out Of Stock	10
1001610	6822301	A3	1	Rear Roller (Used Only)	No	Model Compatibility List	$92.74 / Each	8
1024313	7074401	15	1	Bracket Mounting (Used)	No	Model Compatibility List	$5.56 / Each	1
000030	0K40-01026-0001	0	1	Deck Spring	Yes	Model Compatibility List	$21.59 / Each	1
000031	0K40-01026-0001	0	1	Deck Spring	Yes	Model Compatibility List	$16.79 / Each	1
506263	3208001	A21	4	Flat Head Screw 1-4-20-3 Inches (Used)	No	Model Compatibility List	$1.86 / Each	2,41
1026062	3221101	0	1	Long Arm 5-32 Inch Hex Wrench key L type (Used)	No	Model Compatibility List	$11.99 / Each Out Of Stock	1
1026035	6835201	0	1	Large Handrail Spacer (Used)	No	Model Compatibility List	$5.81 / Each Out Of Stock	1
1026049	T3i-BSMHG	0	1	Bracket Stopper Motor Hood Grip (Used)	No	Model Compatibility List	$11.99 / Each	2,41
506183	3102903	A21	4	Screw	No	Model Compatibility List	$1.86 / Each	2,41
1026023	3206001	0	1	Roller Screw 5/16-18-3.20 Inches (Used)	No	Model Compatibility List	$11.99 / Each	2,41
1026077	6833401	0	1	20x54 Treadmill walking Belt (Used)	No	Model Compatibility List	$118.80 / Each Out Of Stock	15,23
1026076	6856701	0	1	Cable Assembly, Circuit Breaker (Used)	No	Model Compatibility List	$5.99 / Each	4,5,19,42
1026050	T3i-PHRTS	0	1	Polar Heart Rate Transmittor Strap (Used)	No	Model Compatibility List	$11.99 / Each	1
1026063	T3i-PPHRSST	0	1	Polar Pulse Heart Rate Sensor Strap Transmitter (Used)	No	Model Compatibility List	$17.99 / Each Out Of Stock	1
1000259-R	6839601	0	1	Lower Control Board PCA Speed Controller (Used)	No	Model Compatibility List	$253.19 / Each Out Of Stock	7,48
1000316	3204201	29	1	Main Drive Belt	No	Model Compatibility List	$32.38 / Each	15
20000022	LEA3102802	33-pg4	1	NUT, NYLOCK 3/8-16	Yes	Model Compatibility List	$7.19 / Each
20000053	LEA3102514	28-pg4	1	.375 HXS SOC CS ST ZN X 1.00	No	Model Compatibility List	$2.54 / Each
20000054	LEA3102701	29-pg4	1	NUT, HEX	No	Model Compatibility List	$3.41 / Each
1000317	3204201			Main Drive Belt	Yes	Model Compatibility List	$23.99 / Each	15

View Drawing
