Cybex - Arc Trainer 362A

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

Search on this page by part name

Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
5 514741 AW-14007 B73 POWER CORD,115V,60HZ PWR SUPPLY IEC320 (SJT) Yes Model Compatibility List $53.75 / Each

4,5,6
2 515132 BD-20325 219 BELT,DRIVE,350A 36" No Model Compatibility List $57.38 / Each

10,15
6 516842 KAD-22013 604 BOARD, MOTOR CONTROL No Model Compatibility List $20.00 / Each

7
6 516843 KAD-22026 607 BOARD,CONTROL,360A Yes Model Compatibility List $192.54 / Each

7
3 516844 KAD-22048 301 PCA,DISPLAY,360A Yes Model Compatibility List $660.80 / Each

1
6 516845 KAD-22245 607 ASSY,230V LOWER CONTROLLER W/ No Model Compatibility List $178.74 / Each

7,8
1 516860 KAF-21950 106 FRONT LINKAGE,RIGHT No Model Compatibility List $0.00 / Each
Out Of Stock
1
1 516861 KAF-21959 108 LINKAGE,BACK RIGHT Yes Model Compatibility List $225.79 / Each
Out Of Stock
4,5,6
2 516862 KAF-22015 234 BASE, MOTOR No Model Compatibility List $16.39 / Each

3
1 516863 KAF-22039 105 LINKAGE,FRONT,LEFT No Model Compatibility List $193.50 / Each

1
1 516865 KAF-22072 107 LINKAGE,BACK,LEFT No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
1 516866 KAF-22088 118 BACK,ADJUST No Model Compatibility List $46.39 / Each

4,5,6
1 516867 KAF-23621 116 BRACKET,CONSOLE SUPPORT,WHITE No Model Compatibility List $253.34 / Each

7,2,3,4,5,6
1 516868 KAF-24000 102 NC R&R FLYWHEEL BASE No Model Compatibility List $0.00 / Each
Out Of Stock
8,3
1 516869 KAF-24001 112 Bracket, Shuttle, Pivot No Model Compatibility List $178.74 / Each

2,8,3,4,5,6
1 516870 KAF-24002 121 Tube, Support, Chain Cover No Model Compatibility List $72.14 / Each

9,3
2 516871 KAF-24003 232 Plate, Axle Support No Model Compatibility List $3.94 / Each

8,3
6 516874 KAW-22383 611 12P POWER WIRE BOTTOM 1500MM,6 No Model Compatibility List $57.38 / Each

4,5,6
6 516875 KAW-22384 610 12P POWER WIRE UPPER 1000MM,61 Yes Model Compatibility List $73.79 / Each

4,5,6
1 516881 KAX-20904 113 LINKAGE,ARM RIGHT & LEFT Yes Model Compatibility List $66.20 / Each

3
K 516884 KAX-22268 K13 ASSY,REAR LINKAGE ARM,RIGHT No Model Compatibility List $464.03 / Each

3
K 516892 KAX-23308 K06 ASSY,FRAME SUPPORT,REAR No Model Compatibility List $447.91 / Each

3
K 516893 KAX-23312 K10 ASSY,FRONT LINKAGE ARM,LEFT Yes Model Compatibility List $567.48 / Each

3
K 516894 KAX-23313 K11 ASSY,FRONT LINKAGE ARM,RIGHT No Model Compatibility List $334.80 / Each

3
6 516913 KDE-22104 623 DECAL,RPM TARGET DISK No Model Compatibility List $22.96 / Each

7,3
7 516914 KDE-22310 703 DECAL,CYBEX VORTEX,FLYWHEEL ST No Model Compatibility List $9.30 / Each

7,8,3
6 516915 KDE-23109-4 631 LABEL,BIGGEST LOSER,5"W X 4.86 No Model Compatibility List $3.89 / Each

1
6 516917 KEC-22035 624 SENSOR, SPEED Yes Model Compatibility List $37.81 / Each

1
6 516918 KEC-22756 616 KIT,360A SOFTWARE UPDATE,V3.05 No Model Compatibility List $50.83 / Each

1
6 516920 KEF-22041 602 FUSE Yes Model Compatibility List $7.38 / Each

1
2 516921 KFM-20911 223 AXLE,DRIVE LINKAGE No Model Compatibility List $11.47 / Each

8,10
4 516922 KFM-20920 432 AXLE,LINKAGE ARM Yes Model Compatibility List $15.44 / Each

8
4 516923 KFM-21953 463 SPACER,BEARING No Model Compatibility List $14.76 / Each

2,3,4,5,6
A 516924 KFM-21958 A14 TUBE,BEARING SUPPORT No Model Compatibility List $3.12 / Each

3
4 516925 KFM-21965 433 AXLE,BACK LINKAGE Yes Model Compatibility List $26.03 / Each

4,5,6,8
4 516926 KFM-21967 455 SLEEVE Yes Model Compatibility List $11.11 / Each

2,3
4 516927 KFM-21973 464 SPACER,BEARING No Model Compatibility List $14.59 / Each

2,3,4,5,6
4 516928 KFM-21974 465 SPACER No Model Compatibility List $3.12 / Each

2,3,4,5,6
4 516929 KFM-22009 458 SPACER No Model Compatibility List $12.36 / Each

2
4 516930 KFM-22016 404 SHAFT, M10X64 No Model Compatibility List $2.30 / Each

1
4 516931 KFM-22017 406 SHAFT, MOTOR No Model Compatibility List $5.90 / Each

1
4 516932 KFM-22076 405 SHAFT M12 X 22 No Model Compatibility List $3.84 / Each

1
2 516933 KFM-22079 222 CRANK Yes Model Compatibility List $67.55 / Each

8
4 516934 KFM-22080 434 AXLE,FOOT SUPPORT No Model Compatibility List $54.11 / Each

8,9,3
1 516935 KFM-22098 120 FLYWHEEL Yes Model Compatibility List $69.19 / Each

8
2 516936 KFM-22099 220 DISK,ALUMINUM No Model Compatibility List $65.60 / Each

1
4 516937 KFM-22101 431 SHAFT, 10 X 106 No Model Compatibility List $4.92 / Each

1
1 516938 KFM-22110 117 NC R&R Crank Disk Axle No Model Compatibility List $0.00 / Each
Out Of Stock
8
2 516939 KHB-20905 205 BEARING 2205-2RS Yes Model Compatibility List $32.80 / Each

1
2 516940 KHB-20906 206 BEARING 6001 No Model Compatibility List $8.42 / Each

1
2 516941 KHB-20909 216 BUSHING,FRONT LINK Yes Model Compatibility List $6.40 / Each

8
2 516942 KHB-20910 217 BUSHING,DRIVE LINKAGE No Model Compatibility List $10.24 / Each

8,10
3 516943 KHB-20913 319 BUSHING No Model Compatibility List $1.64 / Each

8
3 516944 KHB-20914 320 BUSHING,BACK LINKAGE Yes Model Compatibility List $1.64 / Each

8,4,5,6
2 516945 KHB-21951 202 BEARING W Tolerance Ring,6804 No Model Compatibility List $25.99 / Each

1
2 516946 KHB-21960 208 BEARING,6205Z No Model Compatibility List $12.82 / Each

8
2 516947 KHB-21961 209 BEARING,BL-6206 No Model Compatibility List $36.72 / Each

1
2 516948 KHB-21970 207 BEARING 6005 No Model Compatibility List $16.62 / Each

1
3 516949 KHB-21972 321 BUSHING,HANDLE BAR BOTTOM No Model Compatibility List $3.12 / Each

8,11
2 516950 KHB-22070 203 BEARING 2202 No Model Compatibility List $29.11 / Each

8
5 516951 KHB-22084 505 BUSHING,CRANK 35 X 35MM Yes Model Compatibility List $12.19 / Each

8
2 516952 KHB-22085 204 BEARING,PEDESTAL No Model Compatibility List $42.64 / Each

1
2 516953 KHB-22100 240 BEARING,6000 No Model Compatibility List $17.45 / Each

1
5 516954 KHN-21955 508 NUT NYLON M10 No Model Compatibility List $0.42 / Each

2
4 516955 KHN-22022 425 NUT, NYLON M6 No Model Compatibility List $0.42 / Each

2
4 516956 KHN-22023 426 NUT, NYLON M8 No Model Compatibility List $0.42 / Each

2
4 516957 KHN-22024 424 NUT M5 No Model Compatibility List $4.60 / Each

2
4 516958 KHN-22077 428 NUT NYLON M12 No Model Compatibility List $0.42 / Each

2
4 516959 KHN-22082 430 NUT 3-4 X 16 No Model Compatibility List $2.70 / Each

2
2 516960 KHP-20912 224 PIN,FRONT LINKAGE Yes Model Compatibility List $9.54 / Each

12,13,14
4 516961 KHS-20917 402 BOLT,HEX,FLAT M8X16 Yes Model Compatibility List $1.06 / Each

2
5 516962 KHS-20918 502 SCREW,BUTTON HEAD CAP M6x16 No Model Compatibility List $1.24 / Each

2,9
5 516963 KHS-20925 501 BOLT,HEX HD M8x16 Yes Model Compatibility List $1.06 / Each

2
5 516964 KHS-21954 504 BOLT, 12 X 70 No Model Compatibility List $4.63 / Each

2
4 516965 KHS-21964 422 SCREW,PHILLIPS M5 X 35 Yes Model Compatibility List $0.74 / Each

2
4 516966 KHS-21984 437 SCREW, PHILLIPS M4X15 No Model Compatibility List $0.43 / Each

2
5 516967 KHS-21985 506 SCREW, ALLEN M6X12 No Model Compatibility List $1.99 / Each

2
4 516968 KHS-21988 435 SCREW,PHILLIPS M4X15 No Model Compatibility List $2.21 / Each

2
5 516969 KHS-21990 517 SCREW,HEX HD CAP M8 X 25 Yes Model Compatibility List $3.84 / Each

2,9
5 516970 KHS-21998 507 SCREW,ALLEN M4 X 19 No Model Compatibility List $0.42 / Each

2
5 516971 KHS-21999 514 SCREW,ALLEN M4 X 15 No Model Compatibility List $1.56 / Each

2
4 516972 KHS-22010 416 SCREW, M10X30 No Model Compatibility List $7.80 / Each

2
4 516973 KHS-22018 407 SCREW, BTN HD M5X10 No Model Compatibility List $0.42 / Each

2
4 516974 KHS-22019 414 SCREW, M6X40 No Model Compatibility List $1.56 / Each

2
4 516975 KHS-22020 415 SCREW, PHILLIPS M3X12 No Model Compatibility List $0.42 / Each

2
4 516976 KHS-22021 421 SCREW, BTN HD M3X6 No Model Compatibility List $0.42 / Each

2
4 516977 KHS-22027 481 SCREW,PHILLIPS M3 X 6 No Model Compatibility List $11.47 / Each

2
4 516978 KHS-22029 410 SCREW,BTN HD M10 X 40 No Model Compatibility List $1.97 / Each

2
4 516979 KHS-22045 408 SCREW,BTN HD M5 X 25 No Model Compatibility List $2.30 / Each

2
4 516980 KHS-22059 409 SCREW,BTN HD,M8 X 16 No Model Compatibility List $1.24 / Each

2
4 516981 KHS-22081 417 SCREW,M10 X 40 No Model Compatibility List $1.97 / Each

2
4 516982 KHS-22087 419 SCREW,M14 X 30 No Model Compatibility List $7.72 / Each

2
4 516983 KHS-22090 403 SCREW,M10 X 45 No Model Compatibility List $5.41 / Each

2
4 516984 KHS-22091 413 SCREW,M4 X 45 No Model Compatibility List $1.97 / Each

2
4 516985 KHS-24006 412 Bolt, 8 x 220mm, Pivot Shaft No Model Compatibility List $15.83 / Each

2,8
4 516986 KHS-24007 453 Screw, 8 x 35mm No Model Compatibility List $2.05 / Each

2
4 516988 KHS-24013 423 Bolt, End Cap No Model Compatibility List $2.05 / Each

2,9
4 516989 KHS-24014 454 Bolt, End CapScrew, Main Cover No Model Compatibility List $1.06 / Each

2,9
4 516990 KHW-20924 451 WASHER 20x6xT 1.5 No Model Compatibility List $0.82 / Each

2
5 516991 KHW-20927 509 WASHER, BO, 16x6x2mm No Model Compatibility List $0.82 / Each

2
5 516992 KHW-20928 510 WASHER, 30x8xT2.0 No Model Compatibility List $1.06 / Each

2
5 516993 KHW-21956 511 WASHER,18 X 12 X T3.5 Yes Model Compatibility List $2.30 / Each

2
5 516994 KHW-21957 512 WASHER,18 X 10 X T3.0 No Model Compatibility List $0.42 / Each

2
4 516995 KHW-21966 447 WASHER, 30X8XT3.0 No Model Compatibility List $1.93 / Each

2
5 516996 KHW-21991 515 WASHER,CURVED 16 X 8 X T2 No Model Compatibility List $0.74 / Each

2
5 516997 KHW-21992 516 WASHER,WAVE No Model Compatibility List $0.74 / Each

2,4,5,6
4 516998 KHW-22011 443 WASHER,16 X 10 X T2.0 No Model Compatibility List $1.56 / Each

2
4 516999 KHW-22037 456 WASHER, M3 No Model Compatibility List $0.42 / Each

2
4 517000 KHW-22078 449 WASHER,18 X 10 X T3.0 No Model Compatibility List $1.56 / Each

2
4 517001 KHW-22083 446 WASHER,32 X 6 X T2.0 No Model Compatibility List $1.56 / Each

2
4 517002 KHW-22086 445 WASHER,22X 14 X T2.0 No Model Compatibility List $0.74 / Each

2
4 517003 KHW-22092 450 WASHER,18X10XT5.1 No Model Compatibility List $3.84 / Each

2
4 517004 KHW-22095 468 WASHER,14 X 8.5 X T1.5 No Model Compatibility List $1.24 / Each

2
4 517005 KHW-22103 442 WASHER,14 X 8 X T2.0 No Model Compatibility List $1.56 / Each

2
4 517006 KHW-22168 448 WASHER,8 X 27 X T2.0 No Model Compatibility List $0.42 / Each

2
2 517007 KHW-24004 237 Washer, Shaft, Pivot No Model Compatibility List $5.66 / Each

2,8
2 517008 KHW-24005 238 Washer, Spacer, Pivot Nut No Model Compatibility List $8.20 / Each

2,8,3,4,5,6
2 517009 KHX-20907 210 RING,TOLERANCE AN28-(ID28xT8) No Model Compatibility List $3.28 / Each

1
2 517010 KHX-20908 214 RING,TOLERANCE AN52-(ID52xT7) No Model Compatibility List $8.20 / Each

1
4 517011 KHX-20921 439 CLIP,R; 1.25" OD No Model Compatibility List $2.05 / Each

2
4 517012 KHX-20922 441 CLIP,R; 2.25" OD No Model Compatibility List $4.10 / Each

2
2 517014 KHX-21952 211 RING,TOLERANCE (ID32XT7) No Model Compatibility List $11.47 / Each

1
2 517015 KHX-21971 213 RING, TOLERANCE (ID47XT12) No Model Compatibility List $17.56 / Each

1
3 517016 KHX-21976 364 GRIP,HANDLEBAR No Model Compatibility List $23.20 / Each

11
3 517017 KHX-21989 324 FOOT PAD INSERT - LEG STAND,REAR SUPPORT No Model Compatibility List $17.99 / Each

3
2 517018 KHX-22003 212 RING, TOLERANCE (ID35XT14) No Model Compatibility List $12.36 / Each

3
2 517019 KHX-22014 228 BUTTON, ADJUST No Model Compatibility List $1.56 / Each

1
2 517020 KHX-22036 236 BASE, SENSOR No Model Compatibility List $2.70 / Each

3
1 517021 KHX-22073 119 BASE,MAGNETIC No Model Compatibility List $30.91 / Each

8,3
2 517022 KHX-22075 218 SPRING No Model Compatibility List $1.93 / Each

2
4 517023 KHX-22102 438 S CLIP No Model Compatibility List $0.42 / Each

2
4 517027 KHX-24008 482 Spacer, 5 x8mm, LCB No Model Compatibility List $2.78 / Each

2,3,4,5,6
6 517030 KMR-22028 606 MOTOR,ELEVATION No Model Compatibility List $358.80 / Each

10
3 517032 KPL-20915 360 END CAP No Model Compatibility List $8.05 / Each

9
3 517033 KPL-20916 361 END CAP Yes Model Compatibility List $4.02 / Each

9
3 517034 KPL-21947 351 COVER,HANDLEBAR FRONT END,UPPE Yes Model Compatibility List $29.10 / Each

9,11
3 517035 KPL-21948 352 COVER,HANDLEBAR FRONT END,BOTT No Model Compatibility List $29.10 / Each

9,11
3 517036 KPL-21962 312 COVER,AXLE,FOOT SUPPORT TUBE No Model Compatibility List $11.47 / Each

8,9,3
3 517037 KPL-21963 317 COVER,REAR AXLE,DRIVE LINKAGE Yes Model Compatibility List $9.60 / Each

8,9,10
3 517038 KPL-21977 365 COVER,HANDLEBAR END Yes Model Compatibility List $3.84 / Each

9,11
3 517039 KPL-21981 358 FOOT PEDAL BASE, LEFT Yes Model Compatibility List $65.86 / Each
Out Of Stock
3,8,9
3 517040 KPL-21982 357 TOE-CAP, FOOT PEDAL Yes Model Compatibility List $11.83 / Each

8,9
3 517041 KPL-21983 363 CUSHION, SOFT PEDAL No Model Compatibility List $28.34 / Each

8,9,3
3 517042 KPL-21994 353 COVER,WATER BOTTLE,OUTER,LT Yes Model Compatibility List $0.00 / Each
9
3 517043 KPL-21995 354 COVER,WATER BOTTLE,INNER,LT Yes Model Compatibility List $30.91 / Each

9
2 517044 KPL-21996 230 COVER,INSERT PLASTIC No Model Compatibility List $2.30 / Each

9
3 517045 KPL-21997 362 INSERT,WATER BOTTLE - CUP HOLDER Yes Model Compatibility List $18.19 / Each

1
3 517046 KPL-22005 315 COVER, FRONT LINKAGE AXLE Yes Model Compatibility List $11.99 / Each

8,9
3 517047 KPL-22006 325 COVER, END No Model Compatibility List $3.94 / Each

9
3 517048 KPL-22033 311 COVER,PULLEY Yes Model Compatibility List $33.78 / Each

8,9
3 517049 KPL-22034 310 COVER,REAR,MAIN RIGHT Yes Model Compatibility List $21.31 / Each

9
3 517050 KPL-22038 307 COVER,MAIN RIGHT No Model Compatibility List $98.64 / Each

9
2 517051 KPL-22043 233 FACIA,SWITCH No Model Compatibility List $3.52 / Each

4,5,6
3 517052 KPL-22044 308 BEZEL,SWITCH PLATE No Model Compatibility List $11.11 / Each

4,5,6
3 517053 KPL-22046 306 COVER,MAIN,LEFT No Model Compatibility List $98.38 / Each

9
3 517054 KPL-22047 309 COVER,MAIN,LEFT,INCLINE MOTOR Yes Model Compatibility List $21.31 / Each

9,10
3 517055 KPL-22049 302 COVER,FRONT FASCIA No Model Compatibility List $23.20 / Each

9
3 517056 KPL-22050 303 COVER,REAR No Model Compatibility List $46.39 / Each

9
3 517057 KPL-22051 304 CONSOLE TRAY,UPPER No Model Compatibility List $24.60 / Each
Out Of Stock
7
3 517058 KPL-22052 305 CONSOLE TRAY,BOTTOM No Model Compatibility List $14.76 / Each
Out Of Stock
7
3 517059 KPL-22062 359 PEDAL, FOOT BASE, RIGHT No Model Compatibility List $75.26 / Each
Out Of Stock
3,8,9
3 517060 KPL-22065 355 COVER,WATER BOTTLE,OUTER,RT Yes Model Compatibility List $29.03 / Each

9
3 517061 KPL-22066 356 COVER,WATER BOTTLE,INNER,RT Yes Model Compatibility List $30.91 / Each

9
K 517084 KSK-22004 K04 LEFT FOOT PEDAL BASE Yes Model Compatibility List $327.95 / Each

3,8,9
6 517085 KSK-22040 601 INLET,POWER Yes Model Compatibility List $23.99 / Each

4,5,6
6 517086 KSK-22042 603 SWITCH,ON-OFF POWER No Model Compatibility List $19.93 / Each

4,5,6
K 517087 KSK-22106 K15 LEFT FOOT PLATE Yes Model Compatibility List $133.27 / Each
Out Of Stock
9
K 517088 KSK-22127 K15 RIGHT FOOT PLATE No Model Compatibility List $127.90 / Each

9
K 517089 KSK-22128 K05 RIGHT FOOT PEDAL BASE Yes Model Compatibility List $341.39 / Each

3,8,9
K 517090 KSK-22160 K08 HANDLEBAR ASSEMBLY, RIGHT No Model Compatibility List $287.10 / Each

11
K 517091 KSK-22161 K07 HANDLEBAR ASSEMBLY,LEFT No Model Compatibility List $278.75 / Each

11
K 517092 KSK-23309 K07 No Model Compatibility List $0.00 / Each
Out Of Stock
1
K 517093 KSK-23310 K08 No Model Compatibility List $0.00 / Each
Out Of Stock
1
6 517101 KSW-23106-4 608 MEMBRANE,362A TOP,ENGLISH No Model Compatibility List $29.28 / Each

1
6 517102 KSW-23107-4 609 MEMBRANE,362A BTM,ENGLISH No Model Compatibility List $13.78 / Each

1
6 517115 KWR-22109 615 WIRE,3C POWER WIRE,900MM No Model Compatibility List $18.26 / Each

4,5,6
6 517251 LT-20894-1 626 MANUAL,360A,GER No Model Compatibility List $12.30 / Each

1
6 517252 LT-20894-3 626 MANUAL,360A,SPA No Model Compatibility List $12.30 / Each

1
6 517253 LT-20894-4 626 MANUAL,360A,ENG No Model Compatibility List $40.99 / Each

1
2 517854 PL-20326 227 DRIVE WHEEL,350A No Model Compatibility List $126.43 / Each

8,10
K 519050 SK-20058 K09 Assy, Handle, Drive Link No Model Compatibility List $82.00 / Each

10,11
K 519051 SK-20061 K14 ASSY,LINKAGE ROD,LEFT Yes Model Compatibility List $178.74 / Each

3
K 519052 SK-20063 K04 Cover,Rear Support Yes Model Compatibility List $19.68 / Each

9,3
K 519053 SK-20065 K02 ASSY,COVERS,REAR SUPPORT,LEFT No Model Compatibility List $82.00 / Each

9,3
K 519054 SK-20067 K17 Assy, Main Drive No Model Compatibility List $1.34 / Each

10
K 519055 SK-20068 K16 Assy, Motor, Resistance No Model Compatibility List $0.00 / Each
Out Of Stock
10
A 519056 SK-20076 A12 Assy, Switch Plate No Model Compatibility List $19.97 / Each

4,5,6
5 519057 SK-20301 513 NLA: FOOT,LEVELING,350A No Model Compatibility List $0.00 / Each
Out Of Stock
9
K 519058 SK-20310 K03 ASSY,COVER,REAR SUPPORT,RIGHT No Model Compatibility List $82.00 / Each

9,3
K 519059 SK-20319 K12 ASSY,REAR LINKAGE ARM,LEFT No Model Compatibility List $573.91 / Each

3
K 519060 SK-20330 K18 ASSY,FLYWHEEL SET No Model Compatibility List $286.96 / Each

8
K 519062 SK-23311 K09 No Model Compatibility List $0.00 / Each
Out Of Stock
1
View Drawing
