HEALTH RIDER - 830

Repair Parts for HEALTH RIDER 830 HREL49010

Brand: HEALTH RIDER

Category: Residential Ellipticals

Type: Elliptical

Model Number:

Model Numbers are Unique Identifiers, they are important because they lead you to access diagrams and part lists specific to the version of a given model equipment you own. Bottom line, they help you get the right part. Note: Sometimes we put a serial prefix in this field to elicit versioning, and if this field is blank that means the model name alone will suffice for part selection.

HREL49010

Model Name: 830

Exploded Diagrams

Other Languages Available

VIEWS

Catalog #	MPN	Part List Key	Quantity On Model	Part Description	Available Used	Model Compatibility List	New price
116611	102356	#		FLYWHEEL BEARING	No	Model Compatibility List	$81.02 / Each	8
100396	104838	#		LUBE, GREASE	No	Model Compatibility List	$6.19 / Each	1,15
101730	112006	59		M10 SPLIT WASHER	No	Model Compatibility List	$0.29 / Each	2
100081	113842	58		ROLLER MAGNET	Yes	Model Compatibility List	$1.10 / Each	8,1
107288	012022	66		M6 LOCKNUT	No	Model Compatibility List	$0.56 / Each
106291	130286	35		M10 LARGE WASHER	No	Model Compatibility List	$8.46 / Each	2
100079	131090	54		RSW CLAMP	Yes	Model Compatibility List	$0.46 / Each	4,5,6,2,1,47
106319	132651	62		M10 X 70MM BOLT	No	Model Compatibility List	$11.75 / Each	2
107103	013303	61		5/16 X 1" SCREW,BKT/CNSL	No	Model Compatibility List	$0.35 / Each
100685	013356	71		M5 X 16MM SELF-TAP SCREW	No	Model Compatibility List	$0.38 / Each Out Of Stock
119875	013424	72		M5 X 12MM SCREW	No	Model Compatibility List	$3.77 / Each
100657	139703	31		BEARING	Yes	Model Compatibility List	$24.46 / Each	1
101370	014003	75		M6 WASHER	No	Model Compatibility List	$1.55 / Each
101800	014061	69		M10 WASHER	No	Model Compatibility List	$1.51 / Each
100654	143742	30		LARGE SNAP RING	Yes	Model Compatibility List	$1.84 / Each	1
106039	144379	67		M10 X 25MM BUTTON BOLT	No	Model Compatibility List	$1.44 / Each	2
100668	144985	52		M4 X 16MM SCREW	No	Model Compatibility List	$0.22 / Each	2
106314	144995	34		M10 X 74MM CARRIAGE BOLT	No	Model Compatibility List	$15.20 / Each	2
100540	148710	33		M10 LOCKNUT	No	Model Compatibility List	$1.57 / Each	2
102047	153770	50		M8 X 40MM BUTTON SCREW	Yes	Model Compatibility List	$10.57 / Each	2
101799	154848	64		M4 X 52MM SCREW	No	Model Compatibility List	$1.23 / Each	2
115000	158068	19		DRIVE BELT	Yes	Model Compatibility List	$104.64 / Each	23
100386	158332	#		JACK	Yes	Model Compatibility List	$7.66 / Each	1
100706	165288	#		IFIT SPLITTER	No	Model Compatibility List	$11.26 / Each	1
100385	167079	#		AUDIO CABLE	Yes	Model Compatibility List	$17.61 / Each	1
119860	174916	20		REAR ENDCAP	Yes	Model Compatibility List	$18.16 / Each	9,4,5,6
119855	175586	13		LEFT PEDAL	Yes	Model Compatibility List	$99.14 / Each	8,9
119856	175587	14		RIGHT PEDAL	Yes	Model Compatibility List	$103.91 / Each	8,9
115027	175592	60		FRONT PEDAL ARM BUSHING	No	Model Compatibility List	$37.39 / Each	8,9,3
102040	175904	44		UPPER WIRE HARNESS	No	Model Compatibility List	$76.57 / Each	1
119859	176342	18		SIDESHIELD BRACKET	No	Model Compatibility List	$6.42 / Each	2,3,4,5,6
119864	176348	32		PEDAL AXLE	No	Model Compatibility List	$44.86 / Each Out Of Stock	8,9
119857	176350	15		PEDAL DISC	No	Model Compatibility List	$140.98 / Each Out Of Stock	8,9
119879	176564	#		CUP HOLDER	No	Model Compatibility List	$20.45 / Each	1
119880	176565	#		BOOK RACK	Yes	Model Compatibility List	$4.37 / Each	4,5,6
119847	177032	3		LEFT SIDESHIELD	No	Model Compatibility List	$103.44 / Each	3
119848	177033	4		RIGHT SIDESHIELD	No	Model Compatibility List	$103.44 / Each	3
119858	177057	16		DISC CROSSBAR	No	Model Compatibility List	$112.79 / Each Out Of Stock	1
116071	177515	55		FAN WASHER	No	Model Compatibility List	$1.95 / Each	2,8
119876	178260	76		FRONT SPRING BRACKET	Yes	Model Compatibility List	$61.46 / Each	2,3,4,5,6
119873	179855	65		UPRIGHT BUSHING	No	Model Compatibility List	$18.48 / Each	8,3
119862	180527	26		PEDAL KNOB	Yes	Model Compatibility List	$21.00 / Each	8,9
115035	181250	#		RESISTANCE CABLE	Yes	Model Compatibility List	$18.29 / Each	5
100829	181563	#		CHEST PULSE KIT	No	Model Compatibility List	$176.56 / Each	12,13,14
106032	181786	68		M8-1.25 X 22MM COUNTERSUNK BOLT-SCREW	Yes	Model Compatibility List	$2.97 / Each	2
119867	181787	41		M6 X 72MM BOLT	No	Model Compatibility List	$2.06 / Each	2
115442	181792	57		FLYWHEEL AXLE	No	Model Compatibility List	$20.95 / Each	8
115446	181908	25		IDLER	No	Model Compatibility List	$49.71 / Each	8
119872	181919	63		SPRING SPACER	No	Model Compatibility List	$13.59 / Each Out Of Stock	2,3,4,5,6
119853	181996	10		FRONT STABILIZER	No	Model Compatibility List	$36.64 / Each	1
119852	181997	9		REAR STABILIZER	No	Model Compatibility List	$36.64 / Each	1
119850	181998	6		LEFT HANDLEBAR	No	Model Compatibility List	$39.88 / Each	11
119878	182068			CN-ASSY UPATE, #63	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
119849	182090	5		HANDLEBAR LEG	No	Model Compatibility List	$32.33 / Each	11
119846	182091	2		UPRIGHT	No	Model Compatibility List	$103.44 / Each	3
120370	182106	#		USER-S MANUAL	No	Model Compatibility List	$9.07 / Each	1
119877	182394	78		M5 X 14MM FLWH BKT SCREW	No	Model Compatibility List	$0.52 / Each	2
119865	183631	36		M6 X 33.5MM BOLT	No	Model Compatibility List	$5.20 / Each	2
119866	183632	40		M10 X 27MM PATCH SCREW	No	Model Compatibility List	$4.47 / Each	2
100691	183633	42		M5 WASHER	No	Model Compatibility List	$0.23 / Each	2
119851	183634	7		M6 X 25MM SCREW	No	Model Compatibility List	$2.08 / Each	2
119870	183635	51		M6 X 30MM SCREW	No	Model Compatibility List	$4.84 / Each	2
119863	183636	27		M10 X 27MM PEDAL BOLT	No	Model Compatibility List	$8.22 / Each	2,8,9
101368	183637	74		M10 X 65MM BOLT SET	Yes	Model Compatibility List	$13.75 / Each	2
100709	183757	#		CD, ROCK 20 MIN, LVL 1	Yes	Model Compatibility List	$19.96 / Each Out Of Stock	1
100710	183759	#		CD, ROCK 45 MIN, LVL 3	No	Model Compatibility List	$52.43 / Each Out Of Stock	1
100711	183760	#		CD, WORLDBEAT, 20MIN,LVL1	No	Model Compatibility List	$19.96 / Each	1
100712	183762	#		CD, WORLDBEAT, 45MIN,LVL3	No	Model Compatibility List	$19.96 / Each Out Of Stock	1
100714	183764	#		VIDEO, HAWAII, LVL 1	No	Model Compatibility List	$19.10 / Each	1
100713	183972	#		VIDEO, COAST/COAST, LVL 2	No	Model Compatibility List	$21.04 / Each	1
119871	190384	56		M8 X 25MM BUTTON SCREW	No	Model Compatibility List	$3.82 / Each Out Of Stock	2
119869	193356	45		RESISTANCE CONTROL MOTOR	Yes	Model Compatibility List	$93.07 / Each	1
115450	195929	39		M10 WASHER	No	Model Compatibility List	$0.52 / Each	2
119861	197916	24		HANDGRIP	No	Model Compatibility List	$87.15 / Each	11
115306	199986	77		M6 X 18MM BOLT	No	Model Compatibility List	$0.52 / Each	2
119854	201418	12		LEFT REAR SPRING BRACKET	No	Model Compatibility List	$95.56 / Each Out Of Stock	2,3,4,5,6
119874	201419	70		RIGHT REAR SPRING BKT	No	Model Compatibility List	$38.81 / Each Out Of Stock	2
101362	204489	#		WAVE WASHER	No	Model Compatibility List	$2.99 / Each	2,4,5,6
119868	212220	43		UPRIGHT KNOB	No	Model Compatibility List	$34.50 / Each	3
112958	220047	#		M3 X 12MM SCREW	No	Model Compatibility List	$2.13 / Each	2
101392	256295	49		LIFT BUSHING	No	Model Compatibility List	$4.64 / Each	8,10
100604	045008	#		5MM ALLEN WRENCH	Yes	Model Compatibility List	$3.85 / Each
100541	045021	#		6MM ALLEN WRENCH	Yes	Model Compatibility List	$5.28 / Each
1022562	175580	25		Cover Handlebar (Used)	No	Model Compatibility List	$14.04 / Each	9
1023079	127898	53	1	Speed Sensor (Used)	No	Model Compatibility List	$23.30 / Each	1
1023065	151265	21	1	Endcap Round External (Used)	No	Model Compatibility List	$23.36 / Each	1
1023066	175905	79	1	Wire harness (Used)	No	Model Compatibility List	$73.21 / Each	1,4
1023092	176718	1006	1	Cover Battery Console (Used)	No	Model Compatibility List	$7.81 / Each Out Of Stock	1
1023051	178256	23	1	Console Display (Used)	No	Model Compatibility List	$129.00 / Each	1
000022	175904	42	1	Upper Wire Harness	No	Model Compatibility List	$83.99 / Each	1
1000049	193356	0	1	Resistance Motor Brake Tensioner	Yes	Model Compatibility List	$52.99 / Each	1
nt610R6	158068	90	1	Belt Drive 61"	Yes	Model Compatibility List	$59.00 / Each	23
1004211	204489	0	1	Wave Washer	No	Model Compatibility List	$10.99 / Each	2,4,5,6
1005195	148710	53	1	M10 Locknut	No	Model Compatibility List	$1.57 / Each	2
1009452	113842	137	1	Magnet	Yes	Model Compatibility List	$1.10 / Each	8,1
1031371	127898	20	1	Speed Sensor (Used)	No	Model Compatibility List	$10.00 / Each Out Of Stock	1
1011772	012042	102B	1	M8 Locknut	Yes	Model Compatibility List	$11.99 / Each
1011798	131090	114	1	Reed Switch Cable Retainer Clamp	Yes	Model Compatibility List	$0.46 / Each	4,5,6,2,1,47
1003396	139703			Large Bearing (New)	Yes	Model Compatibility List	$29.99 / Each	1

View Drawing
