Horizon Fitness - 7.0AE - EP703 - EP284 - 2018 - 2018

Repair Parts for Horizon Fitness 7.0AE - EP703 - EP284 - 2018 EP703, EP284

Brand: Horizon Fitness

Category: Folding

Type: Folding Treadmill

Model Name: 7.0AE - EP703 - EP284 - 2018

Serial Number Prefix: EP703, EP284

Version: 2018

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

Search on this page by part name

Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
Ground Wire;Pulse;200L 709992 1000205707 N29 Ground Wire;Pulse;200L No Model Compatibility List $3.82 / Each

Power Switch on Off 040695-A 040695-A 0 1 Power Switch on Off Yes Model Compatibility List $41.59 / Each

Power Switch 1000730 040695-A 0 1 Power Switch Yes Model Compatibility List $31.99 / Each

Screw 3/8-16-1.65 (Used) 1026732 004595-B 0 1 Screw 3/8-16-1.65 (Used) No Model Compatibility List $5.99 / Each

1
Control Board Wire Harness (Used) 1029459 1000205893 P02 1 Control Board Wire Harness (Used) No Model Compatibility List $5.00 / Each

Transport Wheel 1010997 078380 0 1 Transport Wheel Yes Model Compatibility List $15.99 / Each

Right Handgrip Hand Sensor 1000733 1000337708 Right Handgrip Hand Sensor Yes Model Compatibility List $19.99 / Each
Out Of Stock 		4,5,6
Console Wire Harness 1033013 1000101658 Console Wire Harness Yes Model Compatibility List $22.50 / Each

4,5,6,7
Warning Sticker;overlay;remove protectiv D/C, NO REPL: Part will show as orderable until stock is depleted. 731600 1000106875 V15 Warning Sticker;overlay;remove protectiv D/C, NO REPL: Part will show as orderable until stock is depleted. No Model Compatibility List $0.00 / Each
Out Of Stock
Cable Tie;250 M/ROL 732531 066090-A C15 Cable Tie;250 M/ROL No Model Compatibility List $0.00 / Each
Out Of Stock
Console set;Semi-Assy;;;;;EP703-1US; 733355 1000378540 2 Console set;Semi-Assy;;;;;EP703-1US; No Model Compatibility List $1181.42 / Each

Link Arm Set;Semi-Assy;left;;;;EP284-1US 733356 1000454768 3 Link Arm Set;Semi-Assy;left;;;;EP284-1US No Model Compatibility List $218.14 / Each

Link Arm Set;Semi-Assy;right;;;;EP284-1U 733357 1000454770 4 Link Arm Set;Semi-Assy;right;;;;EP284-1U No Model Compatibility List $218.02 / Each

Pedal Arm set;Semi-Assy;left;;;;EP284-1U 733358 1000454773 AE01 Pedal Arm set;Semi-Assy;left;;;;EP284-1U No Model Compatibility List $109.90 / Each

Pedal Arm set;Semi-Assy;right;;;;EP284-1 733359 1000454772 AE02 Pedal Arm set;Semi-Assy;right;;;;EP284-1 No Model Compatibility List $109.90 / Each

Arm Rest Set;Semi-Assy;left down;;;;EP28 733360 1000462669 AG01 Arm Rest Set;Semi-Assy;left down;;;;EP28 No Model Compatibility List $91.56 / Each

Arm Rest Set;Semi-Assy;right down;;;;EP2 733361 1000462667 AG02 Arm Rest Set;Semi-Assy;right down;;;;EP2 No Model Compatibility List $91.56 / Each

Arm Rest Set;Semi-Assy;left up;;;;EP284- 733362 1000462668 AG03 Arm Rest Set;Semi-Assy;left up;;;;EP284- No Model Compatibility List $0.00 / Each
Out Of Stock
Arm Rest Set;Semi-Assy;right up;;;;EP284 733363 1000462666 AG04 Arm Rest Set;Semi-Assy;right up;;;;EP284 No Model Compatibility List $0.00 / Each
Out Of Stock
Link Arm Set;;left;;Pressure with bearin 733364 1000454769 AH01 Link Arm Set;;left;;Pressure with bearin No Model Compatibility List $0.00 / Each
Out Of Stock
Link Arm Set;;right;;Pressure with beari 733365 1000454771 AH02 Link Arm Set;;right;;Pressure with beari No Model Compatibility List $0.00 / Each
Out Of Stock
Stabilizer set;Semi-Assy;;;;;EP283-1US; 733366 1000454767 AL01 Stabilizer set;Semi-Assy;;;;;EP283-1US; No Model Compatibility List $0.00 / Each
Out Of Stock
Magic Wire;;250m/Roll;;; 733367 1000459277 C44 Magic Wire;;250m/Roll;;; No Model Compatibility List $0.00 / Each
Out Of Stock
CTRL Board Power Wire;;;White;;16AWG;200 733368 1000209750 P06 CTRL Board Power Wire;;;White;;16AWG;200 No Model Compatibility List $0.00 / Each
Out Of Stock
Belt;POLY-V;Rubber;490 J10;; 733369 1000469277 R06 Belt;POLY-V;Rubber;490 J10;; No Model Compatibility List $0.00 / Each
Out Of Stock
Heart Sensor Set;arm rest;Left/Front;;EP 733370 1000374795 AC4 Heart Sensor Set;arm rest;Left/Front;;EP No Model Compatibility List $0.00 / Each
Out Of Stock
Heart Sensor Set;arm rest;right;;EP596-1 733371 1000374797 AC6 Heart Sensor Set;arm rest;right;;EP596-1 No Model Compatibility List $0.00 / Each
Out Of Stock
Plastic Cover;Grip;Left-Rear;ABS/PA757K; 733372 1000374796 C15 Plastic Cover;Grip;Left-Rear;ABS/PA757K; No Model Compatibility List $0.00 / Each
Out Of Stock
Plastic Cover;Hand Pulse;Right-Rear;ABS/ 733373 1000374799 C19 Plastic Cover;Hand Pulse;Right-Rear;ABS/ No Model Compatibility List $0.00 / Each
Out Of Stock
733374 1000101696 D06 Guide Rail Ornament;Nickel;EP520-1US No Model Compatibility List $0.00 / Each
Out Of Stock
Warning Label;Console Mast;38x54;-;-;-;- 733375 1000300808 V13 Warning Label;Console Mast;38x54;-;-;-;- No Model Compatibility List $0.00 / Each
Out Of Stock
Manual;APP;;EN/FR/ES;;TM704-1US 733611 1000424544 Not Shown Manual;APP;;EN/FR/ES;;TM704-1US No Model Compatibility List $12.88 / Each

Nut Locking Nylon 3/8 912107 1000465333 Nut Locking Nylon 3/8 No Model Compatibility List $11.99 / Each

Nylon Lock Nut M8x1.25P (New) 976932 004926-00 Nylon Lock Nut M8x1.25P (New) No Model Compatibility List $12.99 / Each

Gear Rower Retainer Clip (New) 957398 005330-00 Gear Rower Retainer Clip (New) Yes Model Compatibility List $11.99 / Each
