Horizon Fitness - RB1 - 2004

Repair Parts for Horizon Fitness RB1 CB42C

Brand: Horizon Fitness

Category: Recumbent

Type: Stationary Bikes

Model Name: RB1

Version: 2004

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

Search on this page by part name

Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
L 700009 000014-00 L02 Transport Wheel Yes Model Compatibility List $9.57 / Each

8
Q 700033 000130-F Q02 Side Cover;Right Yes Model Compatibility List $49.71 / Each

9
700132 000485-00 B28 Leveler;Rubber;W3/8-16UNC Yes Model Compatibility List $9.09 / Each

3
B 700135 000491-B B29 Wing Nut;Leveler;W3/8-16UNC;BED BL SPC No Model Compatibility List $2.47 / Each

2,3
G 700191 000609-A G16 Foam Grip;Handlebar;31.8x28x3.0tx500L No Model Compatibility List $9.57 / Each

4
D 700333 000993-E D06 Sleeve;Seat Post No Model Compatibility List $3.82 / Each

3,12,13,14
Q 700376 001161-C Q05 Plate;Power Socket Yes Model Compatibility List $5.00 / Each

3,4,5,6
Q 700455 001412-A Q07 End Cap;Crank Cover No Model Compatibility List $1.77 / Each
Out Of Stock 		8,9
D 700597 001722-AA D03 Seat Bottom; LOGO LS-B36 No Model Compatibility List $29.56 / Each

12,13,14
P 700722 002028-D P02 Console Cable Yes Model Compatibility List $57.49 / Each

7,4,5,6
P 700770 002231-B P01 Speed Sensor Wire;2 Prong;280mm Yes Model Compatibility List $9.57 / Each

4,5,6
700893 002671-A KIT Audio Wire;Three-D Earphone Yes Model Compatibility List $9.99 / Each

P 700901 002703-A P06 Zero Switch Cable; 100 OMRON + 2.5-2P No Model Compatibility List $9.57 / Each

4,5,6
T 701042 003413-00 T06 Magnet;Crank Wheel;15x7t No Model Compatibility List $4.00 / Each

8
P 701051 003486-A2 P05 Power Adapter;14.5Volts;2M 120V/60Hz 14.5V/1A No Model Compatibility List $76.65 / Each

4,5,6
701055 003511-C S26 ECB Plate; HORIZON No Model Compatibility List $0.00 / Each
Out Of Stock 		3
701154 004072-A2 R12 Ball Bearing;Flywheel;6002ZZ No Model Compatibility List $11.60 / Each

8
701156 004074-A4 G06 Bearing;Ball;6003ZZ;17x35x10T;TPI; Yes Model Compatibility List $17.58 / Each

8
T 701159 004077-A2 T12 Ball Bearing;6004ZZ;20X42X12T;;SKF;;; No Model Compatibility List $20.05 / Each

R 701207 004162-00 R03 Drive Belt;Poly-V;400-J8 Yes Model Compatibility List $57.49 / Each

15,10
Q 701294 004359-00 Q11 Screw;Phillip;BH;M4x0.7Px10L;Gap; No Model Compatibility List $1.79 / Each

701308 004369-00 N24 Screw;Phillip;BH;M5x0.8Px15L;BED; No Model Compatibility List $2.00 / Each

701577 004612-00 S55 Screw;Phillip;BH;Tapped;3x8L No Model Compatibility List $2.00 / Each

701586 004617-00 Q08 Screw;Console Case;Oval Tapping;4x15L No Model Compatibility List $2.00 / Each

701591 004620-00 Q13 Screw;Self Tapping;4x12L No Model Compatibility List $2.00 / Each

701699 004724-00 C04 Bolt;M8x1.25Px15L Yes Model Compatibility List $2.00 / Each

701731 004757-00 G26 Screw;Oval;Hex Socket;M8x1.25Px12L No Model Compatibility List $2.00 / Each

J 701794 004810-A J03 Screw;Hex Socket;Umbrella;M8x1.25Px90L No Model Compatibility List $2.00 / Each

2
701848 004865-00 T20 Screw;Self Tapping;4x10L No Model Compatibility List $2.00 / Each

Q 701851 004870-00 Q14 Screw;Plain Tapping;Rail Lock;5x15L No Model Compatibility List $1.59 / Each

701858 004880-00 P08 Nut;Zero Switch Cable;M3x0.5Px3H No Model Compatibility List $2.00 / Each

2,4,5,6
701869 004891-00 R10 Nut;Hex;3/8-26UNCX9H No Model Compatibility List $2.00 / Each

R 701870 004892-00 R11 Nut;Hex;3/8-26UNCX4H No Model Compatibility List $2.00 / Each

2
701893 004925-00 S17 Nut;Nylon;M6x1.0P;Zinc No Model Compatibility List $2.00 / Each

701897 004926-00 G28 Nut;Nylon;M8x1.25P No Model Compatibility List $2.00 / Each

S 701904 004931-00 S11 Nut;Locking;Nylon;1/4"--20UNC No Model Compatibility List $1.59 / Each

701927 004964-00 T09 Nut;Hex;Flange;M10x1.25P;Black Zinc No Model Compatibility List $2.00 / Each

C 701937 004973-00 C08 Insert Nut;Brass;ALS7-580-3.3(0.5-3.3) No Model Compatibility List $1.90 / Each

2
701964 005005-00 D04 Washer;Spring;Lock;8.2x15.4x2.0t No Model Compatibility List $1.59 / Each

G 701988 005026-00 G19 Washer;Flat;25.5x35.0x1.0T No Model Compatibility List $2.00 / Each

2
702018 005053-00 G22 Washer;Flat;8.2x27.0x2.0T No Model Compatibility List $2.00 / Each

2
702040 005070-00 S21 Washer;Flat;6.5x14x1.0T;Black Zinc No Model Compatibility List $2.00 / Each

2,4,5,6
Q 702063 005091-00 Q12 Washer;Flat;4.2X10.0X1.2T;BAN No Model Compatibility List $2.00 / Each

702066 005094-00 S54 Washer;Flat;3.2x8.0x1.0T;Black Zinc No Model Compatibility List $2.00 / Each

G 702078 005110-00 G12 Washer;Flat;8.2x35x2.0T;Black Zinc Yes Model Compatibility List $9.99 / Each

2,4,5,6
702135 005163-00 C05 Washer;Arc;8.4x17x1.0T No Model Compatibility List $2.57 / Each

2
J 702138 005169-00 J05 Washer;Arc;8.4x20.0x1.5T No Model Compatibility List $2.00 / Each

2
702161 005198-00 G20 Washer;Teflon;15.9x28.4x1.0T No Model Compatibility List $2.00 / Each

2
G 702163 005200-A G25 Washer;Teflon;18.2X30.0X1.0T No Model Compatibility List $2.00 / Each

702193 005239-00 T18 Washer;Lock;10.0x20.0x1.0T No Model Compatibility List $2.00 / Each

702236 005361-00 R13 C-Clip;External;S-15 No Model Compatibility List $2.00 / Each

2
T 702240 005365-00 T13 C-Clip;External;S-20 No Model Compatibility List $1.79 / Each

702260 005400-Z KIT Wrench;Multi-Hole;13,14,15mm - D/C, NO REPL Part will show as orderable until stock is depleted No Model Compatibility List $4.00 / Each

2
K 702264 005412-00 KIT Wrench;L-Type;5mm;With Screwdriver No Model Compatibility List $2.00 / Each

702483 007964-00 B24 Connecting Plate;Side Cover Yes Model Compatibility List $1.90 / Each

9,3
R 702512 008394-00 R15 Fix Plate;Eye Bolt;;SPC;1.3t;;;AB01 No Model Compatibility List $1.51 / Each

G 702607 008969-D G21 Bushing;Inner Yes Model Compatibility List $1.90 / Each

8
S 702869 012962-Z S25 DC Motor Set w/Zero Switch Cable; No Model Compatibility List $172.46 / Each

4,5,6,10
A 703559 015383-AA AT1 Crank;Right No Model Compatibility List $52.05 / Each

8
705141 038132-BBX N83 Heart Rate Receiver Yes Model Compatibility List $54.39 / Each

12,13,14
705700 055204-A S14 Screw;SelfTapping;4x10L No Model Compatibility List $2.00 / Each

G 725257 103297 G09 Bushing;Copper No Model Compatibility List $28.42 / Each

8
725259 103299 G10 Bushing;Pedal Arm No Model Compatibility List $10.01 / Each

8,9,3
R 1000633 004162-00 R03 Pulley Drive Belt 8 Rib High Strength Yes Model Compatibility List $44.99 / Each

15,10
G 936823 004074-A4 G06 Stepper Step Sealed Bearing (New) Yes Model Compatibility List $32.99 / Each

8
Q 911968 004620-00 Q13 Self Tapping Screw 4X12L (New) No Model Compatibility List $12.99 / Each

G 976932 004926-00 G28 Nylon Lock Nut M8x1.25P (New) No Model Compatibility List $12.99 / Each
