Replacement Parts for Life Fitness Optima Single Station Vertical Dumbbell Rack Commercial Strength Equipment

Life Fitness - Optima Single Station Vertical Dumbbell Rack

Repair Parts for Life Fitness Optima Single Station Vertical Dumbbell Rack OSDBV

Brand: Life Fitness

Category: Commercial Strength Equipment

Type: Strength Systems

Model Number:

Model Numbers are Unique Identifiers, they are important because they lead you to access diagrams and part lists specific to the version of a given model equipment you own. Bottom line, they help you get the right part. Note: Sometimes we put a serial prefix in this field to elicit versioning, and if this field is blank that means the model name alone will suffice for part selection.

OSDBV

Model Name: Optima Single Station Vertical Dumbbell Rack

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

OSDBV.PDF

VIEWS

Catalog #	MPN	Part List Key	Part Description	Available Used	Model Compatibility List	New price
506172	3102514	1J	Hardware: Flat Washer 3/8" ID	No	Model Compatibility List	$1.88 / Each	2
506393	3237403	46	Plug 1" Hole	No	Model Compatibility List	$1.88 / Each	1
506411	3239101	38	Hardware: Phillips Pan Screw	No	Model Compatibility List	$1.88 / Each	2
506499	3251712	4	Hardware: Screw 75MM	No	Model Compatibility List	$3.84 / Each	2
506504	3251719	10	Hardware: Screw 120MM	No	Model Compatibility List	$3.84 / Each	2
506554	3264101	3	Hardware: Washer	No	Model Compatibility List	$1.88 / Each	2
508534	7571301	8	Label Serial Number	No	Model Compatibility List	$1.88 / Each	1
509164	7810801	6	Rubber Foot Pad	No	Model Compatibility List	$11.76 / Each	9,12,13,14
509301	8012901	3	End Cap FLOV	No	Model Compatibility List	$9.78 / Each	9
509397	8106101	6	Label Life Fitness	No	Model Compatibility List	$11.76 / Each	1
509530	8137701	9	Warning Label - Multi-Language Horizontal	No	Model Compatibility List	$31.55 / Each	1
509773	8343101	13	Tag - Bolt To Floor	No	Model Compatibility List	$2.24 / Each	2
510085	8635102	1	Weldment, OSDBV, Frame-Plate	No	Model Compatibility List	$213.50 / Each	3
510086	8635202	1	Tube, OSDBV-PLT	No	Model Compatibility List	$52.45 / Each	3
510087	8635302	3	Assembly, OSDBV, Frame- Plate	No	Model Compatibility List	$135.61 / Each	3
510088	8635401	-	Channel, OSDBV	No	Model Compatibility List	$194.10 / Each	1
510093	8653802	1	Assembly, OSDBV, Frame- Plate	No	Model Compatibility List	$246.14 / Each	3
510118	8667002	2	Assembly, OSDBV, Base-Plate	No	Model Compatibility List	$206.48 / Each	3
510119	8669101	-	NLA: MANUAL, OSDBV, ASSY. INST.	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
510120	8670001	-	NLA: MANUAL, OS, OWNERS	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
517136	LEA3242002	10	Hardware: Hex Nut 10MM D	No	Model Compatibility List	$1.88 / Each	2
517516	OSDBV-HDWR	-	Assembly, OSDBV Hardware Bag	No	Model Compatibility List	$67.69 / Each	1
517517	OSDBV-KIT	-	Hardware: Assembly, OSDBV Component Kit	No	Model Compatibility List	$508.00 / Each	1
