Life Fitness - Signature Abdominal Crunch

Repair Parts for Life Fitness Signature Abdominal Crunch SABC

Brand: Life Fitness

Category: Commercial Strength Equipment

Type: Strength Systems

Model Number:

Model Numbers are Unique Identifiers, they are important because they lead you to access diagrams and part lists specific to the version of a given model equipment you own. Bottom line, they help you get the right part. Note: Sometimes we put a serial prefix in this field to elicit versioning, and if this field is blank that means the model name alone will suffice for part selection.

SABC

Model Name: Signature Abdominal Crunch

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

SABC.PDF

VIEWS

Catalog #	MPN	Part List Key	Quantity On Model	Part Description	Available Used	Model Compatibility List	New price
506172	3102514	1J		Hardware: Flat Washer 3/8" ID	No	Model Compatibility List	$1.88 / Each	2
506200	3104903	4E		Bearing 1" ID 1.25-" OD	No	Model Compatibility List	$5.11 / Each	1
506232	3119304	9		End Cap	No	Model Compatibility List	$1.88 / Each	9
506348	3235601	17		Ball Bearing	No	Model Compatibility List	$9.78 / Each	1
506393	3237403	46		Plug 1" Hole	No	Model Compatibility List	$1.88 / Each	1
506486	3251202	40		Hardware: Screw 25MM	No	Model Compatibility List	$1.88 / Each	2
506492	3251704	8		Hardware: Screw 35MM	No	Model Compatibility List	$4.45 / Each	2
507400	7094101	15		NLA: LABEL, SERIAL NUMBER	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
507519	7308701	13		Cap Bearing Housing	No	Model Compatibility List	$3.84 / Each	9
507628	7340201	34		Cover Foot - Straight	No	Model Compatibility List	$13.74 / Each	9
507749	7393399	26		PAD, ARM REST Custom	No	Model Compatibility List	$103.49 / Each	3,12,13,14
508058	7468999	65		ASSY, PAD 18 X 9 CONVEX Custom	No	Model Compatibility List	$186.07 / Each	12,13,14
508078	7474199	36		ASSY, LARGE BACK PAD Custom	No	Model Compatibility List	$230.92 / Each	4,5,6,12,13,14
508759	7662801	3		Grip Ring 1.25"	No	Model Compatibility List	$9.78 / Each	11
508761	7662901	4		Grip Cap	No	Model Compatibility List	$17.70 / Each	9,11
509045	7764301	5		Shaft	No	Model Compatibility List	$55.26 / Each	1
509143	7800101	5		Grip 1.50 ID Foot	No	Model Compatibility List	$15.72 / Each	9,11
509145	7800401	8		Large Cap	No	Model Compatibility List	$51.31 / Each	9
509147	7800501	7		Small Cap	No	Model Compatibility List	$19.40 / Each	9
509163	7809599	2		Painted Assembly, Back Support SABC Custom	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6
509176	7821501	4		Flange Spacer	No	Model Compatibility List	$7.52 / Each	2,3,4,5,6
509194	7865201	7		Label Life Fitness Logo	No	Model Compatibility List	$15.72 / Each	1
509203	7882801	24		Shim	No	Model Compatibility List	$9.78 / Each	1
509331	8039501	16		Label Warning Triangle 10-0099-067 BNR	No	Model Compatibility List	$1.82 / Each	1
509531	8137801	11		Warning Label - Multi-Language Vertical	No	Model Compatibility List	$94.68 / Each	1
510316	8770899	7		Painted Assembly, Work Arm SABC Custom	No	Model Compatibility List	$716.39 / Each	3
510317	8770999	2		Weldment, AB Pivot Arm Custom	No	Model Compatibility List	$0.00 / Each Out Of Stock	8,3
510987	8975401	5		SHROUD, FZAB CAM	No	Model Compatibility List	$68.64 / Each	12,13,14
513319	AK58-00245-0000	20		Bug Medallion	No	Model Compatibility List	$7.81 / Each	1
517136	LEA3242002	10		Hardware: Hex Nut 10MM D	No	Model Compatibility List	$1.88 / Each	2
517139	LEA3247701	20		Hardware: Screw	No	Model Compatibility List	$1.88 / Each	2
517145	LEA3251702	19		Screw; M10 X1.5 25MM	No	Model Compatibility List	$3.84 / Each	2
517146	LEA3251706	8		Hardware: Screw; M10 X1.5 45MM	No	Model Compatibility List	$6.28 / Each	2
517147	LEA3251721	14		Hardware: Screw 135MM	No	Model Compatibility List	$9.78 / Each	2
517148	LEA3252001	11		Hardware: Fender Washer 3/8" ID	No	Model Compatibility List	$1.88 / Each	2
517160	LEA7002401	10		Warning Label Vertical	No	Model Compatibility List	$31.69 / Each	1
517194	LEA7763001	4		Foot	No	Model Compatibility List	$193.20 / Each	9
517195	LEA7797999	1		Weldment, AB Cam Follower Custom	No	Model Compatibility List	$0.00 / Each Out Of Stock	3
517196	LEA7799401	8		Hand Grip	No	Model Compatibility List	$9.78 / Each	11
517197	LEA7799501	12		Hardware: Internal Spacer	No	Model Compatibility List	$23.84 / Each	2,3,4,5,6
517198	LEA7799799	14		Weldment, AB Weight Horn Custom	No	Model Compatibility List	$0.00 / Each Out Of Stock	3
517199	LEA7800201	8		Ring; Weight Horn	No	Model Compatibility List	$3.84 / Each	3
517200	LEA7800301	7		Plug; Weight Horn	No	Model Compatibility List	$3.84 / Each	3
517202	LEA7809399	6		Painted Assembly, Cam Follower SABC Custom	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
517203	LEA7809499	1		Painted Assembly, Foot Rest SABC - Custom	No	Model Compatibility List	$0.00 / Each Out Of Stock	9
517204	LEA7809699	1		Painted Assembly, Lower Support SABC - Custom	No	Model Compatibility List	$0.00 / Each Out Of Stock	3
517205	LEA7809799	1		Painted Assembly, Cross Member SABC - Plate	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
517206	LEA7809999	1		Painted Assembly, Work Arm Stop SABC - Custom	No	Model Compatibility List	$0.00 / Each Out Of Stock	3
517207	LEA7810701	2		Cam; Follower SABC	No	Model Compatibility List	$381.56 / Each	1
517208	LEA7821401	7		Hardware: Nut	No	Model Compatibility List	$11.76 / Each	2
517209	LEA7821603	6		Hardware: Spacer	No	Model Compatibility List	$21.12 / Each	2,3,4,5,6
517210	LEA7847101	11		Placard; SABC	No	Model Compatibility List	$9.78 / Each	4,5,6
517223	LEA8060299	1		Weldment, AB Work Arm	No	Model Compatibility List	$0.00 / Each Out Of Stock	3
20000053	LEA3102514	28-pg4	1	.375 HXS SOC CS ST ZN X 1.00	No	Model Compatibility List	$2.54 / Each
20000072	LEA6433001	5-pg6	1	LABEL, SERIAL NUMBER	No	Model Compatibility List	$4.78 / Each
20000088	LEA7308701	7-pg9	1	CAP, BEARING HOUSING	No	Model Compatibility List	$7.56 / Each
20000151	3242002	38-pg4	25	NUT, M10 X 1.5 HEX NYLOCK	No	Model Compatibility List	$3.41 / Each
