Life Fitness - Signature Arm Curl Bench

Repair Parts for Life Fitness Signature Arm Curl Bench SAC

Brand: Life Fitness

Category: Commercial Strength Equipment

Type: Strength Systems

Model Number:

Model Numbers are Unique Identifiers, they are important because they lead you to access diagrams and part lists specific to the version of a given model equipment you own. Bottom line, they help you get the right part. Note: Sometimes we put a serial prefix in this field to elicit versioning, and if this field is blank that means the model name alone will suffice for part selection.

SAC

Model Name: Signature Arm Curl Bench

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

SAC.PDF

VIEWS

Catalog #	MPN	Part List Key	Part Description	Available Used	Model Compatibility List	New price
506172	3102514	1J	Hardware: Flat Washer 3/8" ID	No	Model Compatibility List	$1.88 / Each	2
506220	3114407	7	Hardware: Flat Washer	No	Model Compatibility List	$1.88 / Each	2
506393	3237403	46	Plug 1" Hole	No	Model Compatibility List	$1.88 / Each	1
506526	3256201	13	Hardware: Screw 20MM	No	Model Compatibility List	$7.25 / Each	2
506535	3256221	2	Hardware: Screw 135MM	No	Model Compatibility List	$9.00 / Each	2
507400	7094101	15	NLA: LABEL, SERIAL NUMBER	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
509145	7800401	8	Large Cap	No	Model Compatibility List	$51.31 / Each	9
509147	7800501	7	Small Cap	No	Model Compatibility List	$19.40 / Each	9
509164	7810801	6	Rubber Foot Pad	No	Model Compatibility List	$11.76 / Each	9,12,13,14
509177	7821701	6	Short Guard	No	Model Compatibility List	$49.34 / Each	9,3
509194	7865201	7	Label Life Fitness Logo	No	Model Compatibility List	$15.72 / Each	1
509202	7878702	2	Guard Bar Rest	No	Model Compatibility List	$187.20 / Each	9,3
509227	7904199	1	Painted Assembly, SAC, Frame Side Right Custom	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6
509228	7904299	1	Painted Assembly, SAC, Frame Side Left Custom	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6
509229	7904599	1	Weldment, SAC, Brace Custom	No	Model Compatibility List	$205.10 / Each	3,4,5,6
509230	7904699	11	Painted Assembly, SAC, Upper Cross Brace Custom	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6
509231	7904799	12	Weldment, SAC, Arm Support Custom	No	Model Compatibility List	$514.06 / Each	3,4,5,6
509232	7905599	1	Tube, SAC, Custom	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6
509233	7905799	10	Painted Assembly, SAC, Lower Cross Brace Custom	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6
509234	7906099	1	Pad, Angle, Long Custom	No	Model Compatibility List	$377.21 / Each	12,13,14
509318	8033299	14	Wear Cover, Custom	No	Model Compatibility List	$43.76 / Each	9
509380	8101501	5	Bumper Sleeve	No	Model Compatibility List	$3.84 / Each	3
509530	8137701	9	Warning Label - Multi-Language Horizontal	No	Model Compatibility List	$31.55 / Each	1
517135	LEA3239102	5	Hardware: Screw	No	Model Compatibility List	$1.82 / Each	2
517136	LEA3242002	10	Hardware: Hex Nut 10MM D	No	Model Compatibility List	$1.88 / Each	2
517149	LEA3256202	10	Hardware: Screw 25MM	No	Model Compatibility List	$4.24 / Each	2
517161	LEA7002501	21	Warning Label Horizontal	No	Model Compatibility List	$3.70 / Each	1

View Drawing
