Matrix Commercial - MG-404-02 - 2013

Repair Parts for Matrix Commercial MG-404-02 MGPL66

Brand: Matrix Commercial

Category: Plate Loaded

Type: Strength Systems

Model Number:

Model Numbers are Unique Identifiers, they are important because they lead you to access diagrams and part lists specific to the version of a given model equipment you own. Bottom line, they help you get the right part. Note: Sometimes we put a serial prefix in this field to elicit versioning, and if this field is blank that means the model name alone will suffice for part selection.

MGPL66

Model Name: MG-404-02

Version: 2013

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

16980.0-base.pdf

VIEWS

Catalog #	MPN	Part List Key	Part Description	Available Used	Model Compatibility List	New price
713802	1000308395	B37	FLANGE BEARING - 1"	No	Model Compatibility List	$21.89 / Each
713805	1000308416	Z38	1" Ext. SNAP RING	No	Model Compatibility List	$2.37 / Each	2
713806	1000308417	B9	2" x 2" END CAP	No	Model Compatibility List	$5.46 / Each
713807	1000308418	B8	1 1/2" x 3" END CAP	No	Model Compatibility List	$5.46 / Each
713808	1000308419	B15	1" Vinyl Cap	No	Model Compatibility List	$2.18 / Each	9
713811	1000308424	B4	SPRING PIN ASSEMBLY	No	Model Compatibility List	$45.60 / Each
713816	1000308434	Z14	1 1/64"ID MACHINE BUSHING	No	Model Compatibility List	$1.43 / Each	8,4,5,6
713818	1000308436	Z42	WASHER;FLT;USS;Diam.0.344XDiam.0.875X.06	No	Model Compatibility List	$1.43 / Each
713823	1000308441	Z40	SCREW;FH;.500-13 x 1.00;ZN;	No	Model Compatibility List	$0.00 / Each Out Of Stock
713838	1000308466	B21	Flat Bumper - Weight Horn	No	Model Compatibility List	$3.02 / Each
713839	1000308467	B28	End cap - weight horn	No	Model Compatibility List	$5.90 / Each
713842	1000308473	V32	Lable, hand pinch	No	Model Compatibility List	$3.02 / Each
713935	1000309773	Z1	Screw Set;M6x1.0Px5L;BP;POT	No	Model Compatibility List	$3.28 / Each
713940	1000309847	Z13	WASHER, .50 OD X .38 ID X .05	No	Model Compatibility List	$1.43 / Each
713961	1000309945	B12	8" CRR - 3 1/4"	No	Model Compatibility List	$174.04 / Each	1
713967	1000309953	Z16	SCREW;HH;.313-18 x 1.25;ZN;	No	Model Compatibility List	$2.37 / Each
713971	1000309993	J5	Seat Pad	No	Model Compatibility List	$463.03 / Each	12,13,14
713972	1000309997	J6	Neck Pad	No	Model Compatibility List	$278.82 / Each	12,13,14
713973	1000310004	B11	1" CRR - 3 1/2"	No	Model Compatibility List	$50.67 / Each	1
713974	1000310007	B19	Round Leveler	No	Model Compatibility List	$20.05 / Each	3
713975	1000310008	B20	ROUND LEVELER BOOT	No	Model Compatibility List	$5.04 / Each	3
713976	1000310009	K2	CAP, END TUBE, 31.8MM	No	Model Compatibility List	$7.28 / Each
713977	1000310010	K1	COLLAR, TUBE, 31.8MM	No	Model Compatibility List	$15.18 / Each
713978	1000310011	K10	Teardrop Boot	No	Model Compatibility List	$6.73 / Each	1
713979	1000310012	K9	Plastic Footpad	No	Model Compatibility List	$6.73 / Each
713980	1000310013	B26	Coped Bumper - Weight Horn	No	Model Compatibility List	$10.11 / Each	3
713981	1000310014	B27	End Cap	No	Model Compatibility List	$5.90 / Each
713984	1000310019	Z43	SCREW;HH;.500-13 x 2.00;ZN;	No	Model Compatibility List	$3.02 / Each
713985	1000310020	Z41	SCREW;FH;.313-18 x 1.25;ZN;	No	Model Compatibility List	$3.35 / Each	2
714005	1000310107	B17	1" ID x 1 1/4" OD Black Nylon Tube - 1.5" Long	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6
714008	1000310115	KZ2	FHSCS 1/4"-20 X 1/2"	No	Model Compatibility List	$1.33 / Each
714302	1000313470	V29	Decal, ROM	No	Model Compatibility List	$5.04 / Each	7,3
714305	1000313512	V30	Label;3lb Starting Resistance;Rev B	No	Model Compatibility List	$5.04 / Each	10
714538	1000315894	V34	DECAL MATRIX 11X1 - Black for Blue Moon, Iced Silver, Blood Red, White, Sunburst Orange, Fence Green, or Yellow frame	No	Model Compatibility List	$6.73 / Each
714683	1000317116	B18	1" ID x 1 1/4" OD Black Nylon Tube - 2.0	No	Model Compatibility List	$25.32 / Each	3,4,5,6
714766	1000318109	1	HAND GRIP 1.25 DIA 0-12"LONG	No	Model Compatibility List	$48.98 / Each
714772	1000318166	2	KIT TEARDROP FOOT	No	Model Compatibility List	$33.77 / Each	9,3
717377	1000344562	V34	Decal;Matrix;Grey for Black Matte, Black Ridge, Black Glossy, Moss Green, or Blue Streak frame	No	Model Compatibility List	$15.18 / Each
718749	1000353136	K3	1.25" Grip;Order by 1" increments;	No	Model Compatibility List	$0.00 / Each Out Of Stock
719680	1000363753	V31	Warning Label;Plate Loaded;	No	Model Compatibility List	$0.00 / Each Out Of Stock
719681	1000363756	V31	Warning Label;Plate Loaded;French	No	Model Compatibility List	$0.00 / Each Out Of Stock
720484	1000373163	AB1	WELDMENT, MAIN FRAME, M404;Iced Silver	No	Model Compatibility List	$0.00 / Each Out Of Stock	3
720485	1000373164	AB1	WELDMENT, MAIN FRAME, M404;Black Glossy	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6
720486	1000373165	AB1	WELDMENT, MAIN FRAME, M404;Lace White	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6
720487	1000373177	B7	Chrome Tube Assy;404;	No	Model Compatibility List	$0.00 / Each Out Of Stock	7,3,12,13,14
720488	1000373179	AB2	Weight Arm;Iced Silver	No	Model Compatibility List	$0.00 / Each Out Of Stock	3
720489	1000373180	AB2	Weight Arm;Black Glossy	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6
720490	1000373181	AB2	Weight Arm;Lace White	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6
720491	1000373194	AB3	Neck Pad Frame;Iced Silver	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,12,13,14
720492	1000373195	AB3	Neck Pad Frame;Black Glossy	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6,12,13,14
720493	1000373196	AB3	Neck Pad Frame;Lace White	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6,12,13,14
721552	1000384006	V35	Serial Number Label;4" x 1.5";3M;	No	Model Compatibility List	$0.00 / Each Out Of Stock
