Matrix Commercial - MG-SUP-02 - 2013

Repair Parts for Matrix Commercial MG-SUP-02 MGAS1078

Brand: Matrix Commercial

Category: Freeweight

Type: Strength Systems

Model Number:

Model Numbers are Unique Identifiers, they are important because they lead you to access diagrams and part lists specific to the version of a given model equipment you own. Bottom line, they help you get the right part. Note: Sometimes we put a serial prefix in this field to elicit versioning, and if this field is blank that means the model name alone will suffice for part selection.

MGAS1078

Model Name: MG-SUP-02

Version: 2013

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

16524.0-base.pdf

VIEWS

Catalog #	MPN	Part List Key	Part Description	Available Used	Model Compatibility List	New price
713806	1000308417	B8	2" x 2" END CAP	No	Model Compatibility List	$5.46 / Each
713821	1000308439	Z6	NUT;NLK;.375-16;ZN;	No	Model Compatibility List	$1.43 / Each	2
713826	1000308444	Z5	WASHER;FLT;USS;Diam.0.406XDiam.1.000X.06	No	Model Compatibility List	$1.43 / Each
713833	1000308451	Not Shown	5" RUBBER FOOT	No	Model Compatibility List	$14.59 / Each	9,3
714032	1000310308	B9	4" FOOT (LONG)	No	Model Compatibility List	$18.23 / Each	9,3
714152	1000312231	B15	1 1/2" Round End Cap	No	Model Compatibility List	$2.18 / Each	9
714246	1000312876	Z7	SCREW;HH;.375-16 x 3.25;ZN;	No	Model Compatibility List	$3.74 / Each
714349	1000313917	B11	1 1/4" ID - 20 1/2" Rubber Grip (9" With	No	Model Compatibility List	$36.48 / Each	11
714538	1000315894	V13	DECAL MATRIX 11X1 - Black for Blue Moon, Iced Silver, Blood Red, White, Sunburst Orange, Fence Green, or Yellow frame	No	Model Compatibility List	$6.73 / Each
715959	1000329507	B3	D-plate	No	Model Compatibility List	$0.00 / Each Out Of Stock	3
716249	1000334853	AB1	Main Frame;Iced Silver	No	Model Compatibility List	$0.00 / Each Out Of Stock	3
716250	1000334854	AB1	Main Frame;Black Glossy	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6
716251	1000334855	AB1	Main Frame;Lace White	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6
717377	1000344562	V13	Decal;Matrix;Grey for Black Matte, Black Ridge, Black Glossy, Moss Green, or Blue Streak frame	No	Model Compatibility List	$15.18 / Each
720070	1000368439	V14	Warning Label;Plate Loaded;	No	Model Compatibility List	$0.00 / Each Out Of Stock	3
720071	1000368441	V14	Warning Label;Plate Loaded;French	No	Model Compatibility List	$0.00 / Each Out Of Stock	3
720298	1000371230	Z4	Screw;HH;.375-16 x 3;ZN	No	Model Compatibility List	$0.00 / Each Out Of Stock
721552	1000384006	V12	Serial Number Label;4" x 1.5";3M;	No	Model Compatibility List	$0.00 / Each Out Of Stock
724938	1000429916	AB2	SUP Handle Assy;Iced Silver	No	Model Compatibility List	$537.39 / Each	11
724939	1000429917	AB2	WELDMENT;Black Glossy	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6
724940	1000429918	AB2	WELDMENT;Lace White	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6
724941	1000429930	AB2	Weldment;Planet Fitness Purple	No	Model Compatibility List	$0.00 / Each Out Of Stock	3

View Drawing
