Matrix Commercial - U7xe-03 - 2013

Repair Parts for Matrix Commercial U7xe-03 CB75B,EP613

Brand: Matrix Commercial

Category: Upright

Type: Stationary Bikes

Model Name: U7xe-03

Version: 2013

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

Search on this page by part name

Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
L 700005 000007-B L01 Transport Wheel;Nylon+30%FIBER;74;BL;CB32 Yes Model Compatibility List $9.10 / Each

8
Q 700040 000169-BA Q04 Boot;Seat Post Yes Model Compatibility List $14.61 / Each

12,13,14
Q 700058 000222-AA Q03 Boot;Console Mast Yes Model Compatibility List $15.99 / Each

7
Q 700072 000252-CA Q07 Cover;Handlebar Yes Model Compatibility List $3.64 / Each

9,11
700111 0004356-AB Not Shown No Model Compatibility List $0.00 / Each
Out Of Stock 		1
Cap;C-Safe;Black;CB32 D/C, NO REPL: Part will show as orderable until stock is depleted. 700313 000932-E 181 Cap;C-Safe;Black;CB32 D/C, NO REPL: Part will show as orderable until stock is depleted. No Model Compatibility List $1.66 / Each

D 700357 001126-C D70 End Cap;Pulse Grips;Inner No Model Compatibility List $1.90 / Each

D 700358 001127-C D57 End Cap;Pulse Grips;Outer Yes Model Compatibility List $4.00 / Each

T 700360 001130-00 T109 Cover;Crank Arm No Model Compatibility List $1.90 / Each

Q 700370 001143-B Q06 Cover;Crank;PVC;BL;RB70 No Model Compatibility List $9.10 / Each

8,9
P 700394 001221-00 P36 Clamp;Cable;KSS UC-1;PD02UC100 No Model Compatibility List $1.66 / Each

Rubber Pad;TV Rack;Rubber;EP68-C10B 700446 001399-BA Not Shown Rubber Pad;TV Rack;Rubber;EP68-C10B No Model Compatibility List $8.42 / Each

4,5,6,12,13,14
700570 001679-00 P13 Tie Strap;Adhesive;Nylon;66;HC-101;W No Model Compatibility List $2.81 / Each

D 700599 001728-BA D06 Seat Pad;Self-Skin;Black;3MM Steel Plate Yes Model Compatibility List $167.00 / Each

3,4,5,6,12,13,14
P 700899 002685-CR P02 Generator Wire;150L;3.96-5P;CB62; Yes Model Compatibility List $9.99 / Each

8,4,5,6
P 700919 002758-B P06 TV Signal Wire;1450L;5CFx2 GF-075;CB62; Yes Model Compatibility List $21.19 / Each

4,5,6
N 700924 002782-C Not Shown Power Cord;External(USA);3000,14AWG;110V(non-nema) Yes Model Compatibility List $72.98 / Each

N 700925 002787-C Not Shown Power Cord;External(USA);3000,14AWG;110V(nema) No Model Compatibility List $72.98 / Each

4,5,6
P 701031 003378-00 P15 Ferrite Core No Model Compatibility List $13.10 / Each

Ferrite Choke;FH0900B-2;Lian Ci;TM38 701032 003383-A P20 Ferrite Choke;FH0900B-2;Lian Ci;TM38 No Model Compatibility List $9.10 / Each

Ferrite Core;T31x16x19-C 701033 003386-A M17 Ferrite Core;T31x16x19-C No Model Compatibility List $13.26 / Each

1
P 701035 003393-A P21 Ferrite Core;FH1500B;TM87 K1 RH12.5x12.5x8 No Model Compatibility List $3.64 / Each

P 701069 003561-C P04 Power Resistance;With Wire;400W 10;VH3. Yes Model Compatibility List $79.99 / Each

4,5,6,10
R 701122 003911-E R03 Transmission Wheel;60;One-Way Bearing;HFL-2530 Yes Model Compatibility List $27.38 / Each

8
T 701146 004050-A T09 Pedal Strap Set(includes both sides);Rub No Model Compatibility List $36.48 / Each

R 701159 004077-A2 R19 Ball Bearing;6004ZZ;20X42X12T;;SKF;;; No Model Compatibility List $20.05 / Each

U 701165 004081-A2 U07 Ball Bearing;6204ZZ;20x47x14t;TPI Yes Model Compatibility List $15.89 / Each

T 701166 004082-A2 T105 Ball Bearing;6205ZZ;25X52X15T;;TPI;;; No Model Compatibility List $21.89 / Each

8
R 701172 004092-00 R20 Bearing;One-Way;;HFL2530;INA Yes Model Compatibility List $84.11 / Each

8
R 701198 004151-00 R08 Drive Belt;Poly-V;450-J6 Yes Model Compatibility List $54.73 / Each

15,10
R 701209 004165-00 R09 Drive Belt;Poly-V;490-J8 Yes Model Compatibility List $54.73 / Each

Screw;RND;M3X0.5PX10L;;PH;;BZN;; 701272 004336-00 N56 Screw;RND;M3X0.5PX10L;;PH;;BZN;; No Model Compatibility List $1.66 / Each

701286 004355-00 H09 Screw;Oval;PH; M4X0.7PX10L No Model Compatibility List $2.00 / Each

701300 004364-00 P58 Screw;Oval Head;M5x0.8Px12L No Model Compatibility List $2.00 / Each

701308 004369-00 P64 Screw;Phillip;BH;M5x0.8Px15L;BED; No Model Compatibility List $2.00 / Each

Z 701312 004370-00 Z13 Screw;Phillip;BH;M5x0.8Px10L;;Zn-BL No Model Compatibility List $2.00 / Each

Q 701321 004375-AC Q21 Screw;Phillip;BH;Stainess;M5x0.8Px15L;BE No Model Compatibility List $1.79 / Each

Screw;BH;M5X0.8PX12L;;PH;;BAN;; 701332 004385-00 E60 Screw;BH;M5X0.8PX12L;;PH;;BAN;; Yes Model Compatibility List $1.79 / Each

D 701346 004393-00 D11 Screw;Phillip;BH;M6x1.0Px50L(Tooth10L);; No Model Compatibility List $1.66 / Each

2
701390 004447-AB S10 Screw;Hex Socket;Round;M5x0.8Px12L;Adher No Model Compatibility List $1.43 / Each

SCREW;SH;M8X1.25PX15L;;HS;;BZN;; 701426 004475-00 M11 SCREW;SH;M8X1.25PX15L;;HS;;BZN;; No Model Compatibility List $0.52 / Each

U 701490 004533-AB U12 Screw;Hex Socket;Round;M8x1.25Px65L Yes Model Compatibility List $1.79 / Each

2
Z 701504 004539-AC Z34 Screw;Round;Hex Socket;M8X1.25PX25L Yes Model Compatibility List $3.64 / Each

701595 004620-AF B55 Screw;Umbrella Cross Tapped;4x12L;Gap No Model Compatibility List $2.00 / Each

701605 004627-00 N40 Screw;Phillip;BH;Tapped;5x12L No Model Compatibility List $2.00 / Each

P 701606 004627-AB P37 Screw;Phillip;BH;Tapped;5x12L;BED;Gap; No Model Compatibility List $2.00 / Each

G 701626 004647-00 G22 Screw;Phillip;Round;3x12L No Model Compatibility List $1.79 / Each

C 701661 004697-AD C33 Screw;Flat Hex Socket;M8x1.25Px25L No Model Compatibility List $3.64 / Each

2
Z 701694 004720-AH Z41 Screw;Hex Socket;Oval;M8X1.25PX20L No Model Compatibility List $2.00 / Each

Z 701730 004756-00 Z31 Screw;Hex Socket;BH;M8x1.25Px20L No Model Compatibility List $1.79 / Each

701737 004762-00 Z05 Screw;Hex Socket;BH;M8x1.25Px70L No Model Compatibility List $2.00 / Each

2
L 701743 004767-00 L02 Screw;Hex Socket;BH;M8x1.25Px70L(Tooth12) No Model Compatibility List $1.79 / Each

2
701781 004796-00 R26 Bol;M8x1.25Px20L Yes Model Compatibility List $2.00 / Each

1
T 701843 004860-00 T17 Screw;Phillip;Large Oval Head;M4X0.7PX8L No Model Compatibility List $1.79 / Each

2
701862 004884-00 U10 Nut;Hex;M8X1.25P No Model Compatibility List $1.79 / Each

S 701870 004892-00 S08 Nut;Hex;3/8-26UNCX4H No Model Compatibility List $2.00 / Each

2
R 701886 004916-C R27 Nut;Hex;M50X1.0P;Zinc Plated No Model Compatibility List $1.79 / Each

2,3
P 701891 004924-00 P60 Nut;Nylon;M5x0.8P;Black Zinc No Model Compatibility List $2.00 / Each

701897 004926-00 D34 Nut;Nylon;M8x1.25P No Model Compatibility List $2.00 / Each

L 701905 004932-00 L03 Nut;Nylon;M8X1.25P(BED) No Model Compatibility List $1.66 / Each

2
S 701907 004933-00 S06 Nut;Nylon;1/4"--20UNC;BED No Model Compatibility List $1.79 / Each

D 701910 004935-AB D12 Nut;Nylon;M6x1.0P;BED(Black); No Model Compatibility List $1.66 / Each

2,4,5,6
701920 004951-A P53 Nut;M5;Chromed No Model Compatibility List $1.66 / Each

7,2,12,13,14
701927 004964-00 T108 Nut;Hex;Flange;M10x1.25P;Black Zinc No Model Compatibility List $2.00 / Each

S 701931 004968-00 S04 Nut;Hex;Flange;3/8-26UNF;Black Zinc No Model Compatibility List $1.79 / Each

2,4,5,6
Insert Nut;Hex;NHS-8125-3.0(M8x1.25P) 701944 004979-00 B39 Insert Nut;Hex;NHS-8125-3.0(M8x1.25P) No Model Compatibility List $1.79 / Each

C 701947 004983-A C21 Insert Nut;Hex;NKHS-8125-2.5(M8x1.25P) No Model Compatibility List $1.79 / Each

B 701948 004984-A B52 Insert Nut;Hex;NKHS-580-2.5(M5x0.8P) No Model Compatibility List $1.66 / Each

R 701951 004987-00 R22 Key;Round;Dual End;6X6X12L No Model Compatibility List $1.66 / Each

701964 005005-00 H04 Washer;Spring;Lock;8.2x15.4x2.0t No Model Compatibility List $1.59 / Each

Z 701978 005015-00 Z32 Washer;Spring;SW8 8.2X13.5X2.0T Yes Model Compatibility List $2.00 / Each

R 701993 005032-00 R30 Washer;Flat;20.2x35.0x1.0T;Black Zinc No Model Compatibility List $1.79 / Each

2,4,5,6
L 701997 005035-00 L04 Washer;Flat;8.2x18x1.4T No Model Compatibility List $2.00 / Each

S 702037 005067-00 S03 Washer;Flat;10.2X15.0X1.5T;Black Zinc No Model Compatibility List $1.59 / Each

S 702050 005078-00 S11 Washer;Flat;5.3x10x1.0T;Black Zinc No Model Compatibility List $2.00 / Each

702066 005094-00 N21 Washer;Flat;3.2x8.0x1.0T;Black Zinc No Model Compatibility List $2.00 / Each

S 702070 005102-00 S07 Washer;Flat;1/4"x15.0x1.0T;Black Zinc No Model Compatibility List $1.79 / Each

2,4,5,6
702076 005109-00 U17 Washer;Flat;8.5x25x1.5T;Black Zinc No Model Compatibility List $1.59 / Each

2,4,5,6
Z 702098 005130-00 Z42 Washer;Flat;8.4x15.5x1.6T;Chromed No Model Compatibility List $2.00 / Each

702105 005134-00 Z33 Washer;Flat;8.2x14.0x1.5T;BAN; No Model Compatibility List $2.00 / Each

Washer;Flat;4.3x12.0x1.0T;Black Zinc 702131 005157-A N153 Washer;Flat;4.3x12.0x1.0T;Black Zinc No Model Compatibility List $1.79 / Each

R 702148 005182-00 R28 Washer;Teflon;25.3X40X1.0T No Model Compatibility List $3.64 / Each

2
U 702151 005186-00 U14 Washer;Teflon;20.3X30X1.0T No Model Compatibility List $1.79 / Each

2
702193 005239-00 T107 Washer;Lock;10.0x20.0x1.0T No Model Compatibility List $2.00 / Each

U 702240 005365-00 U08 C-Clip;External;S-20 No Model Compatibility List $1.79 / Each

702241 005366-00 T106 C-Clip;External;S-25 No Model Compatibility List $1.59 / Each

V 702296 005499-00 V19 Insert Nail;1/8-X7.5L(4-1); No Model Compatibility List $1.66 / Each

1
702325 006078-00 P61 Decal;Grounding;TM08 No Model Compatibility List $1.90 / Each

V 702416 006675-C V13 Decal;Aperture;TV Rack Yes Model Compatibility List $21.48 / Each

7,3,4,5,6
S 702470 007768-D S05 Fix Plate;Eye Bolt No Model Compatibility List $1.79 / Each

702484 007970-B Q09 Connecting Plate;Side Cover;2 Hole No Model Compatibility List $1.79 / Each

9,3
T 702575 008706-C T14 Nut;Crank ;Right;SS41;%32;;;;CB32 No Model Compatibility List $3.64 / Each

2,8
T 702576 008708-D T18 Nut;Rim;;SS41;%32;;;;CB32 No Model Compatibility List $9.96 / Each

2
T 702577 008721-J T15 Ring;Pedal Assembly;Front;SS41;31.8;;;;CB32 SS41(ZINC PLATING) No Model Compatibility List $8.42 / Each

8,9,3
T 702578 008722-G T16 Ring;Pedal Assembly;Rear;SS41;31.8 No Model Compatibility List $8.42 / Each

8,9,3
R 702579 008723-C R06 Ring;26x10L;CB61 No Model Compatibility List $3.35 / Each

1
Screw;Special;Round;2.9x1.06Px7L(Hi-Lo) 702589 008864-A N50 Screw;Special;Round;2.9x1.06Px7L(Hi-Lo) No Model Compatibility List $1.79 / Each

Screw;Special;Round;2.9x1.06Px12L(Hi-Lo 702590 008865-B N154 Screw;Special;Round;2.9x1.06Px12L(Hi-Lo No Model Compatibility List $1.79 / Each

Screw;Special;Round;4.0x1.34Px12L(Hi-Lo 702591 008866-A N152 Screw;Special;Round;4.0x1.34Px12L(Hi-Lo No Model Compatibility List $1.66 / Each

SCREW;RND;Diam.4.0X1.34PX25L;;PH;1022;BZ 702592 008867-A N158 SCREW;RND;Diam.4.0X1.34PX25L;;PH;1022;BZ No Model Compatibility List $1.66 / Each

2
Copper Pillar;M3x12L 702795 010515-00 W19 Copper Pillar;M3x12L No Model Compatibility List $1.66 / Each

1
U 702833 011192-B U11 Spring;Stretch;SWPB;2.0x16.0x95.0Lx26N Yes Model Compatibility List $10.40 / Each

2
S 702856 012818-00 S01 Generator;ECB;190 CE CB/RB MX/600;400W;JM07 Yes Model Compatibility List $602.29 / Each

8
T 703449 014724-A T110 Pedal Set;With Strap Yes Model Compatibility List $72.98 / Each

8,9
Fixing Plate;Right TV 703550 015267-AE Not Shown Fixing Plate;Right TV No Model Compatibility List $17.86 / Each

3,4,5,6
Fixing Plate;TV;Left 703823 018141-AE Not Shown Fixing Plate;TV;Left No Model Compatibility List $16.74 / Each

3,4,5,6
R 703851 018650-E R05 Fix Pass axle Cover A;66x48.5L SS41(Pai No Model Compatibility List $34.16 / Each

8,9
B 703852 018652-B B53 Screw;SH;M6X1.0PX16.5L-8L;;HS;CRMO;BAN;; No Model Compatibility List $3.64 / Each

A 703857 018717-AA AD1 Seat Post Set Yes Model Compatibility List $154.96 / Each

12,13,14
Screw;Phillip;Round;M3x6L;;Zn-BL 703962 020005-00 P02 Screw;Phillip;Round;M3x6L;;Zn-BL No Model Compatibility List $1.79 / Each

T 704222 020641-00 T20 Clip;Internal;C-Shaped;R-52; No Model Compatibility List $1.79 / Each

Pin;Spring;M3X10L 704295 022311-A Not Shown Pin;Spring;M3X10L No Model Compatibility List $1.66 / Each

2,12,13,14
Q 704977 027982-B Q10 Decal;Side Cover;EP68-US;EP68 No Model Compatibility List $25.30 / Each

7,9,3
B 704990 028545-A B42 Side Cover Fix Plate;SPHC;2.0t ;;;CB62 No Model Compatibility List $3.35 / Each

9,3
TV Signal Wire 800 (5CFx2 EP68-P21B-2940 U5X 704993 028601-BR Not Shown TV Signal Wire 800 (5CFx2 EP68-P21B-2940 U5X Yes Model Compatibility List $19.40 / Each

4,5,6
Q 705003 028999-BA Q05 Seat Sleeve No Model Compatibility List $10.63 / Each

3,12,13,14
C 705078 035701-AA C12 Console Fix Plate;Silver Gray; Yes Model Compatibility List $94.72 / Each

7,3
R 705125 037906-A R07 Sleeve;Center Tube;B;SS41;55x2.1L;CB61; No Model Compatibility List $9.10 / Each

3
J 705126 037907-AA J21 Leveler;Foot Pad Yes Model Compatibility List $9.10 / Each
9,3,12,13,14
J 705127 037908-AA J22 Leveler;Foot Pad;Adjustic No Model Compatibility List $9.10 / Each

9,3,12,13,14
R 705213 039153-A R10 Ring;;;;26x10L ;;;;CB61 No Model Compatibility List $8.42 / Each

1
U 705484 049286-A U16 Nut;Hex;Flange;M8x1.25P; No Model Compatibility List $1.85 / Each

2
P 705749 056005-A P11 Ground Wire;Pulse;1100L Yes Model Compatibility List $8.42 / Each

4,5,6,12,13,14
Ground Wire;Pulse Grip;100L;(KST FDFNYD2-250-1 HSG 705752 056008-A W37 Ground Wire;Pulse Grip;100L;(KST FDFNYD2-250-1 HSG No Model Compatibility List $3.35 / Each

4,5,6,12,13,14,11
P 705765 056096-A P32 Fix Plate;Wheel;;SPHC;3.0t ;;;CB61 No Model Compatibility List $1.66 / Each

8,3
705776 056200-BA P33 Rubber Pad No Model Compatibility List $3.35 / Each

12,13,14
P 705777 056225-A P19 Ferrite;PART OF #79 CABLE;NOT ORDERABLE; No Model Compatibility List $8.42 / Each

P 705778 056226-A P18 Resistor Cord;FH0900W;Lian Ci;EP68 No Model Compatibility List $8.42 / Each

4,5,6
P 706177 059907-A P34 Bolt;Eye Hook;1/4"-20UNCx135 No Model Compatibility List $3.35 / Each

2
Fan;DC12V/0.3A PMB1297PYB3-AY;EP70 706354 061339-B W56 Fan;DC12V/0.3A PMB1297PYB3-AY;EP70 Yes Model Compatibility List $117.29 / Each

Q 706476 062619-A Q08 Connection Plate;Side Cover; SPC;2t;Zn Plate;;RB41 No Model Compatibility List $3.35 / Each

9,3
P 706478 062621-A P35 Nut;Wing;1/4"-20UNC;SS41;BZN;; No Model Compatibility List $1.66 / Each

Screw;Hex Socket;Round;M8x1.25Px15L;Adhe 706696 064626-00 Z03 Screw;Hex Socket;Round;M8x1.25Px15L;Adhe No Model Compatibility List $2.00 / Each

2
P 706753 065247-A P16 TV Exchange Connector;;F HDR Into F HSG 9 No Model Compatibility List $9.41 / Each

706754 065248-A P17 TV Coax Adaptor;Female;F-A028-NBX7-C Yes Model Compatibility List $7.00 / Each

Exchange connectorl; KST DWTSFSOLR; 709609 1000201693 W102 Exchange connectorl; KST DWTSFSOLR; No Model Compatibility List $1.01 / Each

1
Program Keypad;19KEY;EP603 710096 1000206771 N07 Program Keypad;19KEY;EP603 No Model Compatibility List $95.08 / Each

9,12,13,14
710099 1000206774 P01 Hand Pulse Sensor Wire;250(TKP,2510A-06+ No Model Compatibility List $19.58 / Each

4,5,6,12,13,14
C Safe+TV Connect Wire;200(TKP H20J2-15x 710100 1000206777 P32 C Safe+TV Connect Wire;200(TKP H20J2-15x No Model Compatibility List $40.51 / Each

Console Cable;250(MOLEX,50-57-9408+MOLEX, 710102 1000206779 P33 Console Cable;250(MOLEX,50-57-9408+MOLEX, No Model Compatibility List $56.58 / Each

E-ORT CONNECT WIRE;400(AMP569532x2); 710103 1000206783 Not Shown E-ORT CONNECT WIRE;400(AMP569532x2); No Model Compatibility List $47.87 / Each

4,5,6
710107 1000206787 P03 USB Connect Wire;A;200(JST,XAP-06V-1x2); No Model Compatibility List $18.46 / Each

4,5,6
Hand Pulse Sensor Wire;350L(2510A-06,TKP 710108 1000206790 W45 Hand Pulse Sensor Wire;350L(2510A-06,TKP No Model Compatibility List $26.68 / Each

4,5,6,12,13,14
Service Cover;Console;PAINTING;MATRIX SL 710155 1000206973 N04 Service Cover;Console;PAINTING;MATRIX SL No Model Compatibility List $73.53 / Each

7,9
Control Board;C-SAFE;H001;Coating;EP 710160 1000207028 W52 Control Board;C-SAFE;H001;Coating;EP No Model Compatibility List $63.52 / Each

7
Control Board;H001;COATING;EP93C; 710161 1000207029 W53 Control Board;H001;COATING;EP93C; No Model Compatibility List $57.04 / Each

7
710164 1000207104 P38 LI Battery;2200MA/H;EP606; No Model Compatibility List $0.00 / Each
Out Of Stock 		1
Battery Con Wire;200(TKP H110-03S+TKP H6 710166 1000207108 P36 Battery Con Wire;200(TKP H110-03S+TKP H6 No Model Compatibility List $14.14 / Each

4,5,6
Console Set;H001S001;EP603;-;EN; 710169 1000207112 21 Console Set;H001S001;EP603;-;EN; Yes Model Compatibility List $2.60 / Each

7
Inverter Board Set;TM503;T7xe; 710268 1000208207 W18 Inverter Board Set;TM503;T7xe; No Model Compatibility List $220.27 / Each

1
Console Set;ENG;H001S001;EP90B; 710275 1000208234 1 Console Set;ENG;H001S001;EP90B; No Model Compatibility List $1.30 / Each

7
Cover;Console;Back;Printing;EP 710276 1000208238 AN15 Cover;Console;Back;Printing;EP Yes Model Compatibility List $88.63 / Each

7,9,4,5,6
Cover;Overlay;15 INCH;PR;OV;EP92F; 710277 1000208248 AN4 Cover;Overlay;15 INCH;PR;OV;EP92F; No Model Compatibility List $138.66 / Each

9
Overlay Set;TV;ENGLISH;EP92F; 710278 1000208250 AN32 Overlay Set;TV;ENGLISH;EP92F; No Model Compatibility List $127.74 / Each

4,5,6
Quick Key Con Wire;250(TKP,H6630R1-06+TK 710288 1000208534 P05 Quick Key Con Wire;250(TKP,H6630R1-06+TK No Model Compatibility List $18.85 / Each

9,4,5,6
Heart Rate Board Set;SALUTRON 8600;EP93C; 710289 1000208535 AN51 Heart Rate Board Set;SALUTRON 8600;EP93C; No Model Compatibility List $300.61 / Each

Wire;QUICK CONNECT;200(HRS HIF3BA-20D-2. 710291 1000208539 W58 Wire;QUICK CONNECT;200(HRS HIF3BA-20D-2. No Model Compatibility List $65.10 / Each

7,4,5,6,12,13,14
Power Wire;200(JST VHR-3NX2);EP93C; 710292 1000208547 W57 Power Wire;200(JST VHR-3NX2);EP93C; No Model Compatibility List $10.14 / Each

7,4,5,6,12,13,14
Plastic BASE;U;ABS/PA746;PA:60461;T7x-03 710307 1000208781 N15 Plastic BASE;U;ABS/PA746;PA:60461;T7x-03 No Model Compatibility List $3.35 / Each

9,3
NET WIRE;400(TKP H6630R1-08,AMP 569532); 710313 1000209244 Not Shown NET WIRE;400(TKP H6630R1-08,AMP 569532); No Model Compatibility List $32.08 / Each

Wire;Connect;USB;250(JST,XAP-06V-1)x2; 710454 1000210330 P03 Wire;Connect;USB;250(JST,XAP-06V-1)x2; No Model Compatibility List $19.16 / Each

Overlay;Manipulate;Upper;ENGLISH;EP603; 710480 1000210495 N10 Overlay;Manipulate;Upper;ENGLISH;EP603; No Model Compatibility List $45.11 / Each

1
PC Spacer;205x60x1.6mm;EP605 710482 1000210497 N38 PC Spacer;205x60x1.6mm;EP605 No Model Compatibility List $9.44 / Each

2,3,4,5,6
USB;EP90B 710483 1000210553 N16 USB;EP90B No Model Compatibility List $14.40 / Each

1
Plastic Cover;ABS/PA746;DG/80435;EP604; 710485 1000210573 Not Shown Plastic Cover;ABS/PA746;DG/80435;EP604; No Model Compatibility List $38.04 / Each

9
710486 1000210574 N12 Rubber;A;NBR;BLACK;EP603 No Model Compatibility List $1.66 / Each

4,5,6
710487 1000210575 N13 Rubber;B;NBR;BLACK;EP603; No Model Compatibility List $1.66 / Each

4,5,6
WIRE;NETWORK SIGNAL;1000(TKP H6630R1-08+ 710569 1000211037 Not Shown WIRE;NETWORK SIGNAL;1000(TKP H6630R1-08+ No Model Compatibility List $53.77 / Each

4,5,6
WIRE;TV PWR EXT;1000(TKP H6630R1-04 DC2 710570 1000211038 Not Shown WIRE;TV PWR EXT;1000(TKP H6630R1-04 DC2 No Model Compatibility List $26.57 / Each

4,5,6
WIRE;E-PORT PWR;1150(AMP569532)x2;H5x-F; 710571 1000211039 Not Shown WIRE;E-PORT PWR;1150(AMP569532)x2;H5x-F; No Model Compatibility List $54.03 / Each

4,5,6
Screw;SH;M5X0.8PX12L;-;HS;SSTSUS304;BED; 710585 1000211111 Z41 Screw;SH;M5X0.8PX12L;-;HS;SSTSUS304;BED; No Model Compatibility List $1.66 / Each

Screw;FH;M3X0.5PX30L;-;PH;BZN; 710607 1000211294 N98 Screw;FH;M3X0.5PX30L;-;PH;BZN; No Model Compatibility List $1.66 / Each

2
Wire;GND;-;-;-;EP93C; 710620 1000211323 W70 Wire;GND;-;-;-;EP93C; No Model Compatibility List $8.42 / Each

4,5,6
Shim;Rubber;D;NBR;BLACK;TM507C; 710678 1000212322 N25 Shim;Rubber;D;NBR;BLACK;TM507C; No Model Compatibility List $1.66 / Each

4,5,6
P 710777 1000213549 P38 Wire;1450(3205615600 8P+TKP,H6630P1 No Model Compatibility List $84.47 / Each

4,5,6
UCB;DISPLAYLCM;H001S015;TM521;Coating; 710794 1000213669 W02 UCB;DISPLAYLCM;H001S015;TM521;Coating; No Model Compatibility List $365.01 / Each

1
Control Board;USB;H001;U10CA1; 710798 1000213752 W04 Control Board;USB;H001;U10CA1; No Model Compatibility List $27.69 / Each

P 710879 1000214923 P30 Wire;Battery;650(FDFNYD2-187)X2+VHR-2N+F Yes Model Compatibility List $36.04 / Each

7,4,5,6,12,13,14
1 711084 1000216401 1 Console Mast Set;U-3x/5x/7x-03-F;CB75B; No Model Compatibility List $358.23 / Each

7
E-Port Fix Plate Set;CB75B;U-3x/5x/7x-03 711085 1000216406 21 E-Port Fix Plate Set;CB75B;U-3x/5x/7x-03 No Model Compatibility List $134.78 / Each

3
1 711086 1000216408 10 Side Cover Set;Left;CN/GY;U-3x/5x/7x-03-F; No Model Compatibility List $305.29 / Each

9
3 711088 1000216411 30 Side Cover Set;Right;CN/GY;U-3x/5x/7x-03-F; No Model Compatibility List $282.67 / Each

9
711125 1000216905 N14 Cover;USB;PAINT;EP603; No Model Compatibility List $16.22 / Each

9
WIFI Antenna;250(WPB105 MINI 1.13 2.4GHz 711129 1000216927 W12 WIFI Antenna;250(WPB105 MINI 1.13 2.4GHz No Model Compatibility List $18.67 / Each

1
Wire;CONNECT;WIFI;200(JS-1253-06+JST,XAP 711141 1000217073 W11 Wire;CONNECT;WIFI;200(JS-1253-06+JST,XAP No Model Compatibility List $19.60 / Each

4,5,6
Wire;NET;550(TKP,H6630R1-08AMP 569532) 711146 1000217094 W16 Wire;NET;550(TKP,H6630R1-08AMP 569532) Yes Model Compatibility List $3.35 / Each

4,5,6
Overly Cover Set;with USB Cover;HURE-5x- D/C, NO REPL: Part will show as orderable until stock is depleted. 711214 1000217803 AN4 Overly Cover Set;with USB Cover;HURE-5x- D/C, NO REPL: Part will show as orderable until stock is depleted. No Model Compatibility List $162.89 / Each

9
CONTROL BOARD SET;LMM REPLACE;EP92;NON V 711254 1000218549 W20 CONTROL BOARD SET;LMM REPLACE;EP92;NON V No Model Compatibility List $999.00 / Each
Out Of Stock 		4,5,6,7
Control Board;Console;H002;S005;EP90B 711268 1000219287 W51 Control Board;Console;H002;S005;EP90B No Model Compatibility List $1182.97 / Each

7
Z 711269 1000219292 Z51 Screw;BH;M5X0.8PX12L;-;HS;BP;BAN; No Model Compatibility List $1.66 / Each

2
15 Inch TFT LCD Module Set;TM503;T7xe; D/C, NO REPL: Part will show as orderable until stock is depleted. 711995 1000224777 W07 15 Inch TFT LCD Module Set;TM503;T7xe; D/C, NO REPL: Part will show as orderable until stock is depleted. Yes Model Compatibility List $2.60 / Each
1
712006 1000224909 AB1 Extrawork;Base Set;Console;BED;EP603 No Model Compatibility List $108.13 / Each

7,3
Control Board;USB;Extra-work;H001;;;TM52 712072 1000226494 W04 Control Board;USB;Extra-work;H001;;;TM52 No Model Compatibility List $23.63 / Each

Torsional Spring;-;USB;SUS304;TM521 712079 1000226524 N27 Torsional Spring;-;USB;SUS304;TM521 No Model Compatibility List $3.35 / Each

Documentation;Overlay;TV;English;PET/A18 712091 1000226590 AN8 Documentation;Overlay;TV;English;PET/A18 No Model Compatibility List $36.48 / Each

4,5,6
Key;TV;20key;Picard; 712092 1000226591 W05 Key;TV;20key;Picard; No Model Compatibility List $127.74 / Each

9,4,5,6
CONTROL BOARD;CONSOLE;H001S001;EP612; 712096 1000226646 W51 CONTROL BOARD;CONSOLE;H001S001;EP612; No Model Compatibility List $1103.54 / Each

7
CONSOLE Reinforce Tube;PAINTING;BLACK;EP 712097 1000226648 AB1 CONSOLE Reinforce Tube;PAINTING;BLACK;EP No Model Compatibility List $164.24 / Each

7,3,4,5,6
Extrawork;COVER;OVERLAY;PR;EP612; 712098 1000226659 AN4 Extrawork;COVER;OVERLAY;PR;EP612; No Model Compatibility List $101.37 / Each

9
OVERLAY;PROGRAM;ENG;EP612; 712099 1000226662 N61 OVERLAY;PROGRAM;ENG;EP612; No Model Compatibility List $118.27 / Each

1
KEYPAD;PROGRAM;EP612; 712100 1000226663 W63 KEYPAD;PROGRAM;EP612; No Model Compatibility List $168.97 / Each

9,12,13,14
OVERLAY;HEART RATE ZONE;ENG;EP612; 712101 1000226665 N62 OVERLAY;HEART RATE ZONE;ENG;EP612; No Model Compatibility List $50.67 / Each

12,13,14
COVER;CONSOLE;U;ABS/PA746;DG/80435;EP612 712102 1000226667 N55 COVER;CONSOLE;U;ABS/PA746;DG/80435;EP612 No Model Compatibility List $67.57 / Each

7,9
COVER;CONSOLE;RE;ABS/PA746;DG/80435;EP61 712107 1000226718 N54 COVER;CONSOLE;RE;ABS/PA746;DG/80435;EP61 No Model Compatibility List $33.77 / Each

7,9
TV PWR EXT;400(H6630R1-04 ##DC##?2. 712270 1000228043 Not Shown TV PWR EXT;400(H6630R1-04 ##DC##?2. No Model Compatibility List $23.71 / Each

4,5,6
P 712271 1000228044 P20 WIRE;TV POWER;1450(SCD-554DCS103BB1G+TKP No Model Compatibility List $38.97 / Each

4,5,6
WIRE;TV PWR EXT;1000(H6630R1-04+DC 2.5x5 712274 1000228049 Not Shown WIRE;TV PWR EXT;1000(H6630R1-04+DC 2.5x5 No Model Compatibility List $18.56 / Each

4,5,6
MO;WIFI WIRE;TM503F/TM503G/TM502D/TM502E 712299 1000228298 W10 MO;WIFI WIRE;TM503F/TM503G/TM502D/TM502E No Model Compatibility List $91.23 / Each

4,5,6
MO;WIFI WIRE;EP90B/EP93C/CS14B;- 712300 1000228299 W10 MO;WIFI WIRE;EP90B/EP93C/CS14B;- No Model Compatibility List $346.76 / Each

4,5,6
Control Board;INVERTER;;TDK TBD584NR-1;; 712376 1000228647 W92 Control Board;INVERTER;;TDK TBD584NR-1;; No Model Compatibility List $337.97 / Each

7
Face Plate Cover;;;PC510;Gray/80435;15.6 712377 1000228648 N51 Face Plate Cover;;;PC510;Gray/80435;15.6 No Model Compatibility List $93.57 / Each

9,3,4,5,6
712378 1000228650 W95 Tape;singleside;3M VHB;1.6T;EP614;- No Model Compatibility List $0.00 / Each
Out Of Stock 		1
BOOK RACK;-;PR;-;EP614; 712379 1000228651 AN36 BOOK RACK;-;PR;-;EP614; No Model Compatibility List $27.01 / Each

Cover;IPOD JACK;;ABS/PA746;Gray/80435;;E 712380 1000228653 N18 Cover;IPOD JACK;;ABS/PA746;Gray/80435;;E No Model Compatibility List $1.66 / Each

9,4,5,6
CONNECT;TV KEY;400(H6630R1-08+H6630R1-10 712382 1000228655 W61 CONNECT;TV KEY;400(H6630R1-08+H6630R1-10 No Model Compatibility List $15.18 / Each

TFT LCD Set;15.6 inch;;;;;EP614; 712383 1000228657 W93 TFT LCD Set;15.6 inch;;;;;EP614; No Model Compatibility List $1.30 / Each

1
712384 1000228659 3 Overlay Set;Touch panel;;15.6 Inch;EP614 No Model Compatibility List $0.00 / Each
Out Of Stock 		7
LVDS Wire;;;;;;;15.6 inch;EP614 712385 1000228660 W101 LVDS Wire;;;;;;;15.6 inch;EP614 No Model Compatibility List $92.92 / Each

4,5,6
WIFI Aerial;;Left;;;;;IVX0035-A225BX;EP6 712386 1000228662 W97 WIFI Aerial;;Left;;;;;IVX0035-A225BX;EP6 No Model Compatibility List $33.77 / Each

1
WIFI Aerial;;Right;;;;;IVX0035-A405WX;EP 712387 1000228663 W98 WIFI Aerial;;Right;;;;;IVX0035-A405WX;EP No Model Compatibility List $33.77 / Each

1
SCREW;BH;M5X0.8PX12L;PH;BAN; 712391 1000228688 N82 SCREW;BH;M5X0.8PX12L;PH;BAN; No Model Compatibility List $1.66 / Each

712398 1000228705 W52 CONTROL BOARD;C-SAFE;U11AA2;H001;COATING No Model Compatibility List $33.77 / Each

7
Fan;;12VDC;0.2A;AFB0512HHB 712425 1000228809 W104 Fan;;12VDC;0.2A;AFB0512HHB No Model Compatibility List $92.92 / Each

8,4,5,6
Isloation Plate;Inverter;;SECC;0.5T;;EP6 712426 1000228810 W99 Isloation Plate;Inverter;;SECC;0.5T;;EP6 No Model Compatibility List $59.12 / Each

3
Tuner Signal Wire;200;(TKP,H20J2-6+Mini 712427 1000228811 W79 Tuner Signal Wire;200;(TKP,H20J2-6+Mini No Model Compatibility List $18.56 / Each

4,5,6
TUNER CONTROL WIRE;250;(JST,XAP-06V-1+US 712428 1000228812 W47 TUNER CONTROL WIRE;250;(JST,XAP-06V-1+US No Model Compatibility List $15.18 / Each

7,4,5,6
Wire;Inverter;100(JST PAP-02V-S+ACES,872 712429 1000228813 W45 Wire;Inverter;100(JST PAP-02V-S+ACES,872 No Model Compatibility List $10.11 / Each

4,5,6
HEART RATE RECEIVER BOARD;SALUTRON 8600 712430 1000228814 W27 HEART RATE RECEIVER BOARD;SALUTRON 8600 No Model Compatibility List $182.49 / Each

Pulse CON;300mm;(2510A-03+XAP-03) 712431 1000228815 W66 Pulse CON;300mm;(2510A-03+XAP-03) No Model Compatibility List $8.42 / Each

Wire;Ipod;500(JAM RJW20-18MP+TKP,H20J2-1 712433 1000228817 W68 Wire;Ipod;500(JAM RJW20-18MP+TKP,H20J2-1 No Model Compatibility List $33.77 / Each

4,5,6
OVERLAY SET;TV;EP604;-; 712477 1000229037 Not Shown OVERLAY SET;TV;EP604;-; No Model Compatibility List $182.49 / Each

4,5,6
LCM Wire;170;(HRS DF13-30DS-1.25CX2) 712519 1000229325 W83 LCM Wire;170;(HRS DF13-30DS-1.25CX2) No Model Compatibility List $20.25 / Each

7,4,5,6,12,13,14
USB Ground Wire;50;(GEM,99471BS-2+GEM,99 712520 1000229327 W85 USB Ground Wire;50;(GEM,99471BS-2+GEM,99 No Model Compatibility List $15.18 / Each

CONSOLE CONTROL BOARD;H001;COATING;EP611 712551 1000229467 W53 CONSOLE CONTROL BOARD;H001;COATING;EP611 No Model Compatibility List $32.84 / Each

7
Network signal extend wire;600;(TKP H663 712659 1000230081 Not Shown Network signal extend wire;600;(TKP H663 Yes Model Compatibility List $38.97 / Each

9,4,5,6
OVERLAY SET;TV;EP612;-; 712660 1000230083 N62 OVERLAY SET;TV;EP612;-; No Model Compatibility List $182.49 / Each

4,5,6
TV PWR EXT;600;(TKP H6630R1-04(PITCH 3.0 712661 1000230086 Not Shown TV PWR EXT;600;(TKP H6630R1-04(PITCH 3.0 No Model Compatibility List $38.97 / Each

4,5,6
2 712798 1000230702 21 E-PORT Fix Plate Set;For PCTV;U-3x/5x/7x Yes Model Compatibility List $109.49 / Each

3,4,5,6
SCREW;BH;?X5X1.6PX12L(HI-LO);PH;BZN; 712866 1000231078 N85 SCREW;BH;?X5X1.6PX12L(HI-LO);PH;BZN; No Model Compatibility List $1.66 / Each

Wire;Ipod;550(JST XADR-16+PAP-06/-10);T7 712867 1000231080 W27 Wire;Ipod;550(JST XADR-16+PAP-06/-10);T7 No Model Compatibility List $32.84 / Each

4,5,6
SCREW;BH;(##10.5);M5X0.8PX15L;-;PH;-;BAN 712869 1000231121 N86 SCREW;BH;(##10.5);M5X0.8PX15L;-;PH;-;BAN No Model Compatibility List $1.66 / Each

2
Nut;Hex;3/8 Inch-32UNEF-2B,2.4T;;; 712881 1000231182 W107 Nut;Hex;3/8 Inch-32UNEF-2B,2.4T;;; No Model Compatibility List $1.66 / Each

2
SCREW;BH;M3X0.5PX6L;CT;PH;SST;BAN; 712940 1000231589 Not Shown SCREW;BH;M3X0.5PX6L;CT;PH;SST;BAN; No Model Compatibility List $1.66 / Each

2
712941 1000231590 N75 Fixing Plate;15.6 inch;;SPCC;1.5T;;EP614 No Model Compatibility List $0.00 / Each
Out Of Stock 		3
GND;-;-;Yellow/Green1;I-POD;18AWG;200mm; 713008 1000232274 W47 GND;-;-;Yellow/Green1;I-POD;18AWG;200mm; No Model Compatibility List $8.42 / Each

1
S 713082 1000232960 S02 Control Board;Generator;;H001;ErP-S100;; Yes Model Compatibility List $547.53 / Each

cover-Extrawork;console;back;Print;PR;EP 713302 1000300861 AN15 cover-Extrawork;console;back;Print;PR;EP No Model Compatibility List $47.29 / Each

Touch Switch;;;;;;;ADV1700021122-01;EP61 713325 1000301559 W89 Touch Switch;;;;;;;ADV1700021122-01;EP61 No Model Compatibility List $21.94 / Each

4,5,6
SDRAM;;SO-DIMM DDR2 2G;Adventech; D/C, NO REPL: Part will show as orderable until stock is depleted. 713328 1000301587 W87 SDRAM;;SO-DIMM DDR2 2G;Adventech; D/C, NO REPL: Part will show as orderable until stock is depleted. No Model Compatibility List $414.02 / Each

1
Connect;;;;;150(TKP,H20J2-15+JST,XAP-08V 713419 1000302343 W63 Connect;;;;;150(TKP,H20J2-15+JST,XAP-08V No Model Compatibility List $11.80 / Each

713433 1000303128 N29 Foam;-;48x5x3.0t;Black;-;TM524 No Model Compatibility List $1.66 / Each

GND;;;;;;150;(GEM,99492BS-2+KST,FDFNYD2- 713591 1000305367 W90 GND;;;;;;150;(GEM,99492BS-2+KST,FDFNYD2- No Model Compatibility List $8.42 / Each

1
Fixed chipset;;;CF;EP614;; 713672 1000306357 W100 Fixed chipset;;;CF;EP614;; No Model Compatibility List $42.22 / Each

1
Controller;Touch Sensor;;EXC208056TAG;;; 713771 1000307911 N31 Controller;Touch Sensor;;EXC208056TAG;;; No Model Compatibility List $506.97 / Each

7,8
Head Phone Board;;;;;;;300L(TKP H20Y1-08 713870 1000309034 W49 Head Phone Board;;;;;;;300L(TKP H20Y1-08 No Model Compatibility List $33.77 / Each

1
P 713881 1000309219 P31 Battery WP1.2-12;12V 1.2Ah; Yes Model Compatibility List $72.98 / Each

713908 1000309510 W82 Cable clamp;;PL-3-V0;;;pingood No Model Compatibility List $0.00 / Each
Out Of Stock 		4,5,6,12,13,14
VA Module;;;;S001;USB2.0;;EP614; 713909 1000309511 W31 VA Module;;;;S001;USB2.0;;EP614; No Model Compatibility List $337.97 / Each

1
H/P;;;;;;;350(TKP,2510A-06+TKP,H6630R1-0 714457 1000315067 W48 H/P;;;;;;;350(TKP,2510A-06+TKP,H6630R1-0 No Model Compatibility List $16.87 / Each

Console GND;;;;;;;200(KST,FDFNYD2-250-1+ 714458 1000315068 W36 Console GND;;;;;;;200(KST,FDFNYD2-250-1+ No Model Compatibility List $8.42 / Each

Console GND;;;;;;;(KST,FDFNYD5-250+KST,F 714780 1000318254 W35 Console GND;;;;;;;(KST,FDFNYD5-250+KST,F No Model Compatibility List $8.42 / Each

7
Exchange Board;Console;;U115A4/H001;;;E 714781 1000318255 W53 Exchange Board;Console;;U115A4/H001;;;E Yes Model Compatibility List $50.67 / Each

Connect Board;C-SAFE;;H002;;;EP614; 714785 1000318272 W52 Connect Board;C-SAFE;;H002;;;EP614; No Model Compatibility List $42.22 / Each

IPOD Wire Cover;;;;;;;I-POD wire used 715895 1000329072 Not Shown IPOD Wire Cover;;;;;;;I-POD wire used No Model Compatibility List $1.79 / Each

9,4,5,6
716106 1000332745 W111 Heat Sink;;;117.5x113.5x21;AL; No Model Compatibility List $0.00 / Each
Out Of Stock 		1
716107 1000332747 W112 Heat sink;;25x25x2t;TM521; No Model Compatibility List $0.00 / Each
Out Of Stock 		1
716108 1000332748 W113 Heat sink;;10x10x2t;TM521; No Model Compatibility List $0.00 / Each
Out Of Stock 		1
716109 1000332749 W114 Heat sink;;8x8x2t;TM521; No Model Compatibility List $0.00 / Each
Out Of Stock 		1
716111 1000332751 2 Heat Sink;;;HEAT SINK SET;TM521;;; No Model Compatibility List $0.00 / Each
Out Of Stock 		1
Overlay;ENTAERTAINMENT;;English;;EP612B 716488 1000336897 N62 Overlay;ENTAERTAINMENT;;English;;EP612B No Model Compatibility List $101.37 / Each

1
Overlay Set;TV;;English;EP612B;; 716489 1000336898 N62 Overlay Set;TV;;English;EP612B;; No Model Compatibility List $127.74 / Each

4,5,6
Manual;Assembly;;English;;EP617 716629 1000337906 Not Shown Manual;Assembly;;English;;EP617 No Model Compatibility List $16.87 / Each

3
WiFi;EWM-W135H01E;Adventech;; 716641 1000338307 W88 WiFi;EWM-W135H01E;Adventech;; No Model Compatibility List $163.90 / Each

1
Overlay;Program;;English;;EP612B 717145 1000341910 N61 Overlay;Program;;English;;EP612B No Model Compatibility List $135.17 / Each

1
Tuner Signal Wire;;;;;;;200(TKP,H20J2-6+ 717796 1000347710 W79 Tuner Signal Wire;;;;;;;200(TKP,H20J2-6+ No Model Compatibility List $31.02 / Each

4,5,6
Ipod Extend Wire;;;;;;300(MF1512S0017+JA 718757 1000353342 W28 Ipod Extend Wire;;;;;;300(MF1512S0017+JA No Model Compatibility List $72.98 / Each

9,4,5,6
Ipod Extend Wire;;;;;;;;300(MFI512S0017+ 718758 1000353343 W28 Ipod Extend Wire;;;;;;;;300(MFI512S0017+ No Model Compatibility List $91.23 / Each

9,4,5,6
Fixing Plate;TV Tuner;;Zinc Plate;;;TM52 719170 1000356656 W108 Fixing Plate;TV Tuner;;Zinc Plate;;;TM52 No Model Compatibility List $3.35 / Each

Quickly Key Wire;;;;;;;200+250(TKP,H254M 719182 1000356740 Not Shown Quickly Key Wire;;;;;;;200+250(TKP,H254M No Model Compatibility List $18.56 / Each

9,4,5,6
719183 1000356740* Not Shown No Model Compatibility List $0.00 / Each
Out Of Stock 		1
RFID SET;Semi-Assy;;;;EP614D;; 719421 1000361164 Not Shown RFID SET;Semi-Assy;;;;EP614D;; No Model Compatibility List $1.30 / Each

1
T 719731 1000364363 T111/T112 crank set;;;RB85-SBOM;Clear coat;RB85;; Yes Model Compatibility List $168.97 / Each

8
Earphone board set;;;;EP91;; 719804 1000365782 W11 Earphone board set;;;;EP91;; No Model Compatibility List $29.17 / Each

Earphone board set;;;;EP620; 719870 1000366515 9 Earphone board set;;;;EP620; No Model Compatibility List $42.22 / Each

Memory Card;;TS8GCF220I;8GB;Transcend;; 721130 1000380801 W110 Memory Card;;TS8GCF220I;8GB;Transcend;; No Model Compatibility List $1137.08 / Each

9
TV Stick Set;;;US / KITS - SBOM;EP620;; 722510 1000393224 W106 TV Stick Set;;;US / KITS - SBOM;EP620;; No Model Compatibility List $392.05 / Each

Earphone board set;;;;Earphone board set 723181 1000404540 W24/W58 Earphone board set;;;;Earphone board set No Model Compatibility List $67.57 / Each

1
723628 1000410717 7 PCB;;;Second hand;;;T7xi(TM521); No Model Compatibility List $3.90 / Each

1
Tuner Module;;;REV 2.0;S20170417;;US for 724734 1000425274 AW31 Tuner Module;;;REV 2.0;S20170417;;US for No Model Compatibility List $588.09 / Each

1
U 725257 103297 U06 Bushing;Copper No Model Compatibility List $28.42 / Each

8
Console TV Cable Extended Wire;250L(FM-0086-N 725318 069851 W33 Console TV Cable Extended Wire;250L(FM-0086-N Yes Model Compatibility List $10.14 / Each

Filter Board 725319 069859 AP1 Filter Board Yes Model Compatibility List $55.95 / Each

Screw;Eye Bolt;1/4 725504 072171 S12 Screw;Eye Bolt;1/4"-20UNCX65L(25L)Eye10;ZN-BL No Model Compatibility List $1.66 / Each

Connect Wire;Console;2.0AR;RB123 726121 080124 P05 Connect Wire;Console;2.0AR;RB123 No Model Compatibility List $31.85 / Each

Pulse Wire;AL Rail;2.0AR;RB123 726122 080125 P11 Pulse Wire;AL Rail;2.0AR;RB123 No Model Compatibility List $29.09 / Each

726224 0000080784 C25 Cover;Screw;PVC;BL;CB62; No Model Compatibility List $1.66 / Each

Pulse Wire;150(FDFNYD2-250-1+546BS-2);TM 726397 0000081594 W101 Pulse Wire;150(FDFNYD2-250-1+546BS-2);TM No Model Compatibility List $3.64 / Each

726549 082734 P59 Washer;Senated;M5.3X10X0.6;Zinc Plate No Model Compatibility List $1.79 / Each

726562 082875 D60 Screw;BH;M3X0.5PX20L;;PH;;BZN;; No Model Compatibility List $1.79 / Each

726594 0000083278 Z22 USB Cover;USB-03 No Model Compatibility List $1.90 / Each

726607 083458 Z62 Washer;Lock;8.2x13.5x2.0t No Model Compatibility List $2.00 / Each

Screw;Phillip;Round;M3x0.5Px30L;;Zn-BL 726738 084533 G21 Screw;Phillip;Round;M3x0.5Px30L;;Zn-BL No Model Compatibility List $1.79 / Each

726832 085415 W33 LVDS Wire;15 Inch TFT LCD;410(HRS DF14H-20P+D No Model Compatibility List $27.59 / Each

Wire;Hand Pulse;250(2510A-03+XAP-03);TM5 726882 0000085776 W44 Wire;Hand Pulse;250(2510A-03+XAP-03);TM5 Yes Model Compatibility List $14.99 / Each

726885 085779 AM1 Elevator Motor;AC;110V/123mm;JM03;only Yes Model Compatibility List $354.87 / Each

Cover;Console;Right;ABS/PA-746;BL;TM501; 726928 0000086064 N33 Cover;Console;Right;ABS/PA-746;BL;TM501; No Model Compatibility List $3.35 / Each

726929 0000086065 N34 Cover;Console;Left;ABS/PA-746;BL;TM501; Yes Model Compatibility List $3.35 / Each

726991 086531 N45 Fix Plate;PCB;1.0t;TM502; No Model Compatibility List $30.94 / Each

Fix Plate;15 Inch;0.8t;TM503; 726992 086532 N46 Fix Plate;15 Inch;0.8t;TM503; No Model Compatibility List $40.64 / Each

726993 086533 N47 Bracket;Isolation Board Cover;0.6t;TM503 No Model Compatibility List $8.42 / Each

Speaker Set;AK-402808BC-3T+280+XAP-02;TM 727017 0000086684 W13 Speaker Set;AK-402808BC-3T+280+XAP-02;TM No Model Compatibility List $17.65 / Each

Cover;Console Display;TV Rack;Printing;T 727025 0000086724 N35 Cover;Console Display;TV Rack;Printing;T No Model Compatibility List $47.63 / Each

727041 086852 W38 Rubber Ring;GM-5 No Model Compatibility List $1.01 / Each

Vent;Fan;ABS/PA-746;Pantone:877C;TM501; 727076 0000087056 N13 Vent;Fan;ABS/PA-746;Pantone:877C;TM501; No Model Compatibility List $45.24 / Each

727194 087672 Z41 Screw;Hex Socket;Round;M5x0.8Px8L No Model Compatibility List $1.79 / Each

727213 087846 N49 Foam;Overlay;1;315.5x4.0x1.0t;Rubber/BL; No Model Compatibility List $1.66 / Each

727214 087847 V01 No Model Compatibility List $0.00 / Each
Out Of Stock
727215 087848 V09 No Model Compatibility List $0.00 / Each
Out Of Stock
727225 087912 5 Handle Bar Set;U5x-F; No Model Compatibility List $602.21 / Each

727234 088009 P14 Filter Power Wire;450L(KST FLDNY2-250x2 No Model Compatibility List $91.68 / Each

727289 088387 G12 Pulse Sensor Wire;800L(TKP H66030R1-06); No Model Compatibility List $23.50 / Each

Screw;TRH;M3x.5Px6L;MT;PH;CST;ZNC;F-T 727351 0000088743 N81 Screw;TRH;M3x.5Px6L;MT;PH;CST;ZNC;F-T No Model Compatibility List $1.79 / Each

Anti-Slippery Pad;TPR+30%PP;BL;MX-E5XC-F 727358 0000088790 N52 Anti-Slippery Pad;TPR+30%PP;BL;MX-E5XC-F No Model Compatibility List $9.10 / Each

TV Earphone Wire Cover;ABS/PA746;80435 727359 0000088791 N53 TV Earphone Wire Cover;ABS/PA746;80435 No Model Compatibility List $3.64 / Each

727360 088795 AN12 Overlay Set;PROGRAM;ENG;MX-E5X-C;US;EP90 No Model Compatibility List $273.75 / Each

727361 088799 N62 Overlay;Down;Console;ENG;MX-E5X-C;US;EP90 No Model Compatibility List $36.48 / Each

727371 088888 N42 insulation Plate;INVETER;PC;8B35;3M-467; No Model Compatibility List $1.82 / Each

Bottle Holder Set;Console Mast;ABS/PA746;BL 727375 0000088923 C11 Bottle Holder Set;Console Mast;ABS/PA746;BL Yes Model Compatibility List $15.52 / Each

727424 089112 W28 Spacer;Support;MEA-05;PINGOOD; No Model Compatibility List $1.66 / Each

727425 089113 W29 Fix Plate;SPHC;1.6t;BED;T5x-02; No Model Compatibility List $8.42 / Each

Cover;IPOD Fixing;ABS/PA746;Deep Grey 80 727442 0000089261 N18 Cover;IPOD Fixing;ABS/PA746;Deep Grey 80 No Model Compatibility List $3.64 / Each

727469 089486 N12 Bushing;KSS Moveable;KG-008;10M/Reel; No Model Compatibility List $23.63 / Each

727474 089506 Not Shown No Model Compatibility List $0.00 / Each
Out Of Stock
727514 089691 W02 TV Control Board Set;TM503;T7xe; No Model Compatibility List $400.17 / Each

727523 089758 P13 Pushbutton Switch;R13-513B2B;H5x-F; No Model Compatibility List $20.36 / Each

727531 089819 R31 Washer;FLT;25.3X40.0X2.0T;TFN;S2MO;; No Model Compatibility List $1.79 / Each

727534 089835 Not Shown No Model Compatibility List $0.00 / Each
Out Of Stock
727540 089846 P01 Console Cable;1700L;MOLEX,50-57-9408 No Model Compatibility List $84.47 / Each

Wire;Hand Pulse Sensor;350L(2510A-06,TKP 727543 0000089849 W45 Wire;Hand Pulse Sensor;350L(2510A-06,TKP No Model Compatibility List $20.90 / Each

727544 089851 Not Shown No Model Compatibility List $0.00 / Each
Out Of Stock
727545 089852 P12 AC Power Switch Set;550L(KST FLDNY2-250x No Model Compatibility List $36.48 / Each

727559 089923 15 Hand Pulse Grip;No Quick Key;U5x-F; No Model Compatibility List $36.48 / Each

727560 089924 G13 Pulse Sensor Wire;Up;650L(TKP H6630R1-10 No Model Compatibility List $28.65 / Each

727561 089925 G14 Pulse Sensor Wire;Down;850L(TKP H6630P1- No Model Compatibility List $20.93 / Each

Pedal Set 727707 0000090518 66 Pedal Set Yes Model Compatibility List $72.98 / Each

727714 090551 P56 Ferrite Choke;FH0850B;T7xe; No Model Compatibility List $8.42 / Each

Control Board;Quick Key 727748 0000090779 N24 Control Board;Quick Key Yes Model Compatibility List $9.99 / Each

727757 090809 17 Stabilizer Set;Rear;H5x-F; No Model Compatibility List $653.33 / Each

727758 090810 16 Stabilizer Set;Front;H5x-F; No Model Compatibility List $411.19 / Each

727765 090873 3 Pulley Axle Set;U5x-F; No Model Compatibility List $530.43 / Each

LCM Wire;130L(H6630R1-18)x2 727795 0000091027 W25 LCM Wire;130L(H6630R1-18)x2 No Model Compatibility List $26.05 / Each

727796 091028 W30 TV Key Wire;160L(H6630R1-14)x2 No Model Compatibility List $8.42 / Each

727858 091621 N41 Fix Plate;Tuner;MX-E7X-C;US;EP91 No Model Compatibility List $16.64 / Each

727948 092145 W30 Signal Wire;Tuner;350L(PAP-12V-Sx2) No Model Compatibility List $27.20 / Each

Heart Rate Power Wire;250L(2510A-03+XAP- 727961 0000092217 W75 Heart Rate Power Wire;250L(2510A-03+XAP- No Model Compatibility List $9.13 / Each

Wire;Ipod;500(JST XADR-16+PAP-06/-10) 727973 0000092303 W27 Wire;Ipod;500(JST XADR-16+PAP-06/-10) No Model Compatibility List $64.74 / Each

727988 092381 W69 Console Ground Wire;130+220+250(KST FDFN No Model Compatibility List $8.42 / Each

Fixing Plate;Fan;0.8t;T5x-02; 728026 0000092696 N202 Fixing Plate;Fan;0.8t;T5x-02; No Model Compatibility List $9.10 / Each

728032 092776 W85 Screw;Phillip;Round;M2x0.5Px8L;Adhere; No Model Compatibility List $8.42 / Each

728099 093132 7 Pulse Sensor Set No Model Compatibility List $127.74 / Each

728132 093219 AB1 RIGHT MAIN FRAME SET No Model Compatibility List $589.11 / Each

Screw;Hex Socket;Round;M8x1.25Px20.0L;Ad 728172 093382 Z21 Screw;Hex Socket;Round;M8x1.25Px20.0L;Ad No Model Compatibility List $1.66 / Each

728188 093508 P03 GND Wire;Filter;200(KST FLDNY2-250kz+GE No Model Compatibility List $3.35 / Each

728371 094425 Not Shown No Model Compatibility List $0.00 / Each
Out Of Stock
728376 094434 Not Shown No Model Compatibility List $0.00 / Each
Out Of Stock
Seat Pad Pull Pin Set;M16;Orange Knob 728395 0000094530 AD3 Seat Pad Pull Pin Set;M16;Orange Knob Yes Model Compatibility List $57.93 / Each
728506 095125 N01 Console Front Cover;Faceplate;ABS/PA746;DG/80435;EP60 No Model Compatibility List $93.52 / Each

Console Rear Cover;ABS/PA746;DG/80435;EP603 728507 095126 N02 Console Rear Cover;ABS/PA746;DG/80435;EP603 No Model Compatibility List $75.14 / Each

728541 095229 W05 Pulse Receiver Set;Salutron 4600;EP603 No Model Compatibility List $305.11 / Each

Control Board;USB;H001;U105A5;EP603; 728542 0000095231 W04 Control Board;USB;H001;U105A5;EP603; No Model Compatibility List $28.29 / Each

728544 095247 W52 C-Safe;E LEAD;3P00DMJE001-0A;EP92F; No Model Compatibility List $104.83 / Each

728548 095281 Not Shown No Model Compatibility List $0.00 / Each
Out Of Stock
728550 095295 N03 Cover;Overlay;ABS/PA746;80435;EP603 No Model Compatibility List $41.08 / Each

728561 095323 N06 Overlay;Manipulate;Lower;ENGLISH;EP603; No Model Compatibility List $36.48 / Each

728579 095386 U15 Screw;TH;M8X1.25PX65L(33L);;HS;;;;BP;BL No Model Compatibility List $3.35 / Each

728581 095397 2 Idler Set;U5x-F;CB75-AU3 No Model Compatibility List $171.65 / Each

728588 095430 U27 Washer;FLT;9.3X23.0X2.0T;;BZN; No Model Compatibility List $1.66 / Each

Tape;Foam;One-Sided;50x15x1.5T; 728600 0000095575 N203 Tape;Foam;One-Sided;50x15x1.5T; No Model Compatibility List $1.66 / Each

728616 095641 N157 SCREW;RND;#X4.0X1.34PX8L(HI-LO);PH;BZN; No Model Compatibility List $1.66 / Each

729011 Order Kit AT101 Pedal Axle No Model Compatibility List $0.00 / Each
Out Of Stock
729052 Order Parts Separately A01 Frame Assembly No Model Compatibility List $0.00 / Each
Out Of Stock
729099 Part of Console Set W94 Overlay;Touch panel;;;15.6#T:9PCT TF1-TP No Model Compatibility List $0.00 / Each
Out Of Stock 		7
729118 Part of Kit 1 AC1 Stabilizer Frame;Rear;B;Panting;MM330;EP212 No Model Compatibility List $0.00 / Each
Out Of Stock
729120 Part of Kit 10 Q01 Lower Handlebar Set;Right;Panting;MM330;EP212 No Model Compatibility List $0.00 / Each
Out Of Stock
729133 Part of Kit 16 AJ1 Stabilizer;Front;Panting;MM330;EP212 No Model Compatibility List $0.00 / Each
Out Of Stock
729135 Part of Kit 17 AJ2 Transmission Axle;42CrMo;EP217 No Model Compatibility List $0.00 / Each
Out Of Stock
729138 Part of Kit 2 U03 Console Mast;Painting;MM330;6027-45- No Model Compatibility List $0.00 / Each
Out Of Stock
729141 Part of Kit 21 B41 Axle;Transmission;42CRMO;-;-; No Model Compatibility List $0.00 / Each
Out Of Stock
729152 Part of Kit 3 R02 Pedal Arm;Right;EP212 No Model Compatibility List $0.00 / Each
Out Of Stock
729156 Part of Kit 30 Q02 AC Generator;480RPM;350W;50.6VA; No Model Compatibility List $0.00 / Each
Out Of Stock 		8,4,5,6
729165 Part of Kit 4 T02 Pedal Arm;Left;EP212 No Model Compatibility List $0.00 / Each
Out Of Stock
729172 Part of Kit 5 AG1 Swing Arm Set;Panting;MM330;EP212 No Model Compatibility List $0.00 / Each
Out Of Stock 		3
729191 Part of Kit 6 AD9 Vertical Stabilizer Arm;Panting;MM330;EP212 No Model Compatibility List $0.00 / Each
Out Of Stock
729228 Part of Kit AG5 N202 Grip;Sensor;U;ABS/PA746;BL;C8000; No Model Compatibility List $0.00 / Each
Out Of Stock 		11
729249 Part of W07 W16 Backlight Panel;TOUCH PANEL; No Model Compatibility List $0.00 / Each
Out Of Stock 		7,4,5,6
729277 ZMF4000335 1 Console Set,WIFI-Universal 7XE No Model Compatibility List $0.00 / Each
Out Of Stock 		7
729291 ZMF4000356 1 Console,H,U,R7XE,10pk VA,WIFI,RC No Model Compatibility List $0.00 / Each
Out Of Stock 		7
729292 ZMF4000357 1 Console,H,U,R7XE,20pk VA,WIFI,RC No Model Compatibility List $0.00 / Each
Out Of Stock 		7
729295 ZMF4000364 1 Console,H,U,R7XE,10pk VA,RF,RC No Model Compatibility List $0.00 / Each
Out Of Stock 		7
729296 ZMF4000376 1 Console-HURESA7XE,RF,RC No Model Compatibility List $0.00 / Each
Out Of Stock 		7
729518 ZMS4000947 Not Shown VA KIT-10 ASCENTS/TREADS No Model Compatibility List $1009.32 / Each

1
729519 ZMS4000948 Not Shown BIKES - Virtual Active Board Kit (10 Map Pack) No Model Compatibility List $0.00 / Each
Out Of Stock 		4,5,6
729520 ZMS4000949 Not Shown EP / STEPPER - Virtual Active Board Kit (10 Map Pack) No Model Compatibility List $0.00 / Each
Out Of Stock 		4,5,6
729524 ZMS4001139 Not Shown Ascents/EP/Stepper-Virtual Active Board Kit (20 Map Pack) No Model Compatibility List $0.00 / Each
Out Of Stock 		4,5,6
729525 ZMS4001140 Not Shown Bikes-Virtual Active Board Kit (20 Map Pack) No Model Compatibility List $0.00 / Each
Out Of Stock 		4,5,6
Connection Cable for 900MZ Wireless Modu 729539 ZMS4001266 Not Shown Connection Cable for 900MZ Wireless Modu No Model Compatibility List $0.00 / Each
Out Of Stock 		4,5,6
Velcro pads (1 pair) for 900MHZ Receiver 729540 ZMS4001285 Not Shown Velcro pads (1 pair) for 900MHZ Receiver No Model Compatibility List $10.11 / Each

12,13,14
Silicon Plug, 0.25 729777 ZMS4004742 Not Shown Silicon Plug, 0.25"0.125"0.75" Black No Model Compatibility List $2.29 / Each

4,5,6
Display Console - Used Only 1006461 1000226658 Display Console - Used Only No Model Compatibility List $585.00 / Each
Out Of Stock 		7
Display Console - Used Only 1007104 huresac-7XE Display Console - Used Only No Model Compatibility List $960.70 / Each

7
Washer U3X U5X 7X-05-F (Used) 1020694 U3X-W 0 2 Washer U3X U5X 7X-05-F (Used) No Model Compatibility List $2.70 / Each

2
R 1003253 004165-00 R09 1 Belt Drive 8 Ribbed Yes Model Compatibility List $32.99 / Each

712381 1000228654 W62 CONNECT;USB;150(JST,XAP-06V-1)X2;EP614; No Model Compatibility List $8.42 / Each

Foot Pedal Set w/Strap 9/16” 1004804 0000090518 0 1 Foot Pedal Set w/Strap 9/16” Yes Model Compatibility List $56.99 / Each

T 1004805 014724-A T110 1 Foot Pedal Set w/Strap 1/2” Yes Model Compatibility List $56.99 / Each

8,9
Lower Motor Control Board Controller 1009196-R 0000090779 0 1 Lower Motor Control Board Controller Yes Model Compatibility List $399.00 / Each

Filter Board Set 1003980 069859 Filter Board Set Yes Model Compatibility List $27.99 / Each

Holder, Cup without Bracket (Used) 1035694 0000088923 C11 1 Holder, Cup without Bracket (Used) Yes Model Compatibility List $14.99 / Each

Q 1036645 007970-B Q09 PLATE CONNECTING COVER FRONT Yes Model Compatibility List $5.00 / Each

9,3
734667 0000087912 5 Handle Bar Set;U5x-F; Yes Model Compatibility List $375.68 / Each

Nylon Lock Nut M8x1.25P (New) 976932 004926-00 Nylon Lock Nut M8x1.25P (New) No Model Compatibility List $12.99 / Each

Z 941989 004370-00 Z13 Screw (New) No Model Compatibility List $12.00 / Each

View Drawing

general Info

Customer Service

About us

Address

6114 Madison Ct.
Morton Grove, IL 60053
847-309-2818

Hydra Fitness Exchange © 2024. All Rights Reserved.

Payment options
