Phone : 847-309-2818 M-F 10am-5pm

Matrix Commercial - VY-6044-02 - 2013

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

Search on this page by part name

Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
D 713811 1000308424 DP 9 SPRING PIN ASSEMBLY No Model Compatibility List $45.60 / Each

Z 713814 1000308428 Z28 3/8" NUT No Model Compatibility List $1.43 / Each

713820 1000308438 Z36 SCREW;HH;.375-16 x 3.00;ZN; No Model Compatibility List $3.02 / Each

Z 713826 1000308444 Z38 WASHER;FLT;USS;Diam.0.406XDiam.1.000X.06 No Model Compatibility List $1.43 / Each

D 713842 1000308473 DP 12 Lable, hand pinch No Model Compatibility List $3.02 / Each

Z 713935 1000309773 Z1 Screw Set;M6x1.0Px5L;BP;POT No Model Compatibility List $3.28 / Each

P 713939 1000309846 Pulley 7 1/2" JAM NUT No Model Compatibility List $1.43 / Each

P 713940 1000309847 Pulley 11 WASHER, .50 OD X .38 ID X .05 No Model Compatibility List $1.43 / Each

713943 1000309851 Pulley 4 SCREW;HH;.375-16 x 2.25;ZN; No Model Compatibility List $2.18 / Each

P 713946 1000309854 Pulley 5 NUT;NLK;.250-20;ZN; No Model Compatibility List $1.43 / Each

P 713950 1000309858 Pulley 10 3/4" FLAT WASHER No Model Compatibility List $1.33 / Each

713953 1000309871 Z35 SCREW;HH;.375-16 x 2.00;ZN; No Model Compatibility List $2.18 / Each

N 713975 1000310008 Not Shown ROUND LEVELER BOOT No Model Compatibility List $5.04 / Each

3
713976 1000310009 K2 CAP, END TUBE, 31.8MM No Model Compatibility List $7.28 / Each

713977 1000310010 K1 COLLAR, TUBE, 31.8MM No Model Compatibility List $15.18 / Each

713978 1000310011 K10 Teardrop Boot No Model Compatibility List $6.73 / Each

1
713979 1000310012 K9 Plastic Footpad No Model Compatibility List $6.73 / Each

Z 713991 1000310088 Z30 Washer, Curved, 1/2" No Model Compatibility List $3.02 / Each

713997 1000310096 Pulley 9 1/4" SPLIT LOCK WASHER No Model Compatibility List $1.33 / Each

K 714008 1000310115 KZ2 FHSCS 1/4"-20 X 1/2" No Model Compatibility List $1.33 / Each

D 714016 1000310219 DP 15 SCREW;HH;.250-20 x 0.75;ZN; No Model Compatibility List $1.33 / Each

714017 1000310270 B17 1"OD x 5/8"ID NYLON PIPE - 3 1/2" No Model Compatibility List $21.94 / Each

1
B 714018 1000310273 B25 4" FOOT (SHORT) No Model Compatibility List $20.05 / Each

Z 714033 1000310313 Z31 1/4" BLACK FLAT WASHER No Model Compatibility List $1.43 / Each

Z 714034 1000310314 Z32 BHSCS - 5 1/6-18 x 3/4" No Model Compatibility List $2.37 / Each

714038 1000310334 Weight Stack 1 6000 TOP PLATE No Model Compatibility List $78.47 / Each

B 714040 1000310339 B63 ROUND WEIGHT STACK BUMPER No Model Compatibility List $5.90 / Each
Out Of Stock
714041 1000310343 Weight Stack 2 Orange SELECTOR PIN w/ 6 1/2" CORD No Model Compatibility List $25.53 / Each

714079 1000311963 Z34 Screw;HH;.375-16x1.25;Zinc No Model Compatibility List $0.00 / Each
Out Of Stock
714109 1000312099 Z33 HCS 1/2-13 x 4 1/4" No Model Compatibility List $5.04 / Each

W 714118 1000312127 Weight Stack 4 BHS 5/16" - 1" No Model Compatibility List $5.46 / Each

714126 1000312159 Pulley 8 1/2 - 13 NUT No Model Compatibility List $1.33 / Each

Z 714127 1000312161 Z27 NUT;NLK;.500-13;ZN;TALL; No Model Compatibility List $1.43 / Each

B 714152 1000312231 B44 1 1/2" Round End Cap No Model Compatibility List $2.18 / Each

9
D 714175 1000312296 DP 10 Flange Bushing - 3/4"OD x 1/2"ID No Model Compatibility List $10.92 / Each

8
P 714189 1000312326 Pulley 12 4" CABLE PULLEY - 3/8" HOLE No Model Compatibility List $27.01 / Each

714193 1000312342 V57 DECAL,WARNING: BOLT DOWN;English No Model Compatibility List $0.00 / Each
Out Of Stock
714240 1000312817 Weight Stack 3 5/16" SPLIT LOCK WASHER No Model Compatibility List $1.33 / Each

714246 1000312876 Z37 SCREW;HH;.375-16 x 3.25;ZN; No Model Compatibility List $3.74 / Each

714247 1000312877 B26 6000 Top Plastic No Model Compatibility List $170.66 / Each

9
714249 1000312880 Weight Stack 8 CAST IRON No Model Compatibility List $104.75 / Each

714253 1000312893 B45 3/8" SAFETY CLIP No Model Compatibility List $16.82 / Each

714259 1000312963 B11 1/4" PLASMA No Model Compatibility List $0.00 / Each
Out Of Stock
1
714260 1000312969 B15 5/8" GUIDE ROD - 64.25" No Model Compatibility List $184.18 / Each

3
714261 1000312970 B16 5/8" GUIDE ROD - 70 1/2" No Model Compatibility List $0.00 / Each
Out Of Stock
3
714263 1000312973 B23 Rope - 312" No Model Compatibility List $6.37 / Each

1
714264 1000312974 B39 1/2" RUBBER BUMPER No Model Compatibility List $6.73 / Each

1
B 714266 1000312976 B46 HANDLE W-STRAP D-RING (SHORT) No Model Compatibility List $25.98 / Each

714339 1000313809 DP 11 7/8" OD x 1/2" ID Flat Washer No Model Compatibility List $0.00 / Each
Out Of Stock
2
714465 1000315136 V65 6000 STACK DECALS, MEDIUM No Model Compatibility List $30.39 / Each

714538 1000315894 V64 DECAL MATRIX 11X1 - Black for Blue Moon, Iced Silver, Blood Red, White, Sunburst Orange, Fence Green, or Yellow frame No Model Compatibility List $6.73 / Each

K 714766 1000318109 Kit 1 HAND GRIP 1.25 DIA 0-12"LONG No Model Compatibility List $48.98 / Each

714772 1000318166 Kit 2 KIT TEARDROP FOOT No Model Compatibility List $33.77 / Each

9,3
714903 1000319579 V63 6044/6047 PLACARD;English No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
714904 1000319580 V63 6044/6047 PLACARD;French No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
714905 1000319589 Weight Stack Set WEIGHT STACK 12+1 6024 single pulley perpendicular No Model Compatibility List $0.00 / Each
Out Of Stock
8,9,3,4,5,6
716313 1000335318 DP 13 CLAMP - COVER No Model Compatibility List $0.00 / Each
Out Of Stock
717156 1000342316 B21 Rubber Stopper;Cable Ball;Drilled 3/8" f No Model Compatibility List $23.71 / Each

4,5,6
717462 1000345333 V52 Decal;Hi-low ROM No Model Compatibility List $0.00 / Each
Out Of Stock
717463 1000345334 V53 Decal;Hi-low ROM 17 No Model Compatibility List $0.00 / Each
Out Of Stock
717500 1000345600 B18 5/8# Single Split Collar No Model Compatibility List $10.92 / Each

717639 1000346400 DP Right Set Double Pulley Set;Right;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock
8
717640 1000346401 DP Right Set Double Pulley Set;Right;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock
8,4,5,6
717641 1000346402 DP Right Set Double Pulley Set;Right;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock
8,4,5,6
717642 1000346413 DP Left Set Double Pulley Set;Left;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock
8
717643 1000346414 DP Left Set Double Pulley Set;Left;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock
8,4,5,6
717644 1000346415 DP Left Set Double Pulley Set;Left;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock
8,4,5,6
717779 1000347532 DP 3 4.5" Pulley for Rope / Cable No Model Compatibility List $18.56 / Each

718749 1000353136 K3 1.25" Grip;Order by 1" increments; No Model Compatibility List $0.00 / Each
Out Of Stock
719579 1000362648 B57 GUARD - 6044/6047 LEFT FRONT;Charcoal Metallic No Model Compatibility List $0.00 / Each
Out Of Stock
9,3
719682 1000363760 V60 Warning Label;Frame;;;PC;;English; No Model Compatibility List $0.00 / Each
Out Of Stock
719683 1000363766 V60 Warning Label;Frame;;;PC;;French;GM40 No Model Compatibility List $5.04 / Each

719753 1000365174 B60 D Ring;Purchased; No Model Compatibility List $13.49 / Each

1
719795 1000365701 AB12 6044/6047 REAR SUPPORT;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock
3
719796 1000365702 AB12 6044/6047 REAR SUPPORT;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
719797 1000365703 AB12 6044/6047 REAR SUPPORT;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
719798 1000365716 AB3 Accessory Hooks;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
719799 1000365717 AB3 Accessory Hooks;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
719800 1000365718 AB3 Accessory Hooks;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
720307 1000371307 DP Left 1 Slide Assy;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock
1
720308 1000371308 DP Left 1 Slide Assy;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
720309 1000371309 DP Left 1 Slide Assy;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
720310 1000371320 DP 2 Slide Assy;6044;Metallic Flat Black No Model Compatibility List $527.25 / Each

3,4,5,6
720465 1000372992 DP 1 Slide Assy;Iced Silver No Model Compatibility List $527.25 / Each

1
720466 1000372993 DP Right 1 Slide Assy;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
720467 1000372994 DP Right 1 Slide Assy;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
720468 1000372995 DP 1 Slide Assy;Blood Red No Model Compatibility List $527.25 / Each

1
720469 1000373005 DP 1 Slide Assy;Metallic Flat Black No Model Compatibility List $527.25 / Each

3,4,5,6
720667 1000374560 B6 2" x 2" TUBE - 75";Chrome No Model Compatibility List $0.00 / Each
Out Of Stock
7,3,12,13,14
720668 1000374562 AB10 Chin Up Bar - 6044/6047;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock
1
720669 1000374563 AB10 Chin Up Bar - 6044/6047;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
720670 1000374564 AB10 Chin Up Bar - 6044/6047;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
720671 1000374578 B56 16ga Sheet Metal Guard;Charcoal Metallic. No Model Compatibility List $0.00 / Each
Out Of Stock
9,3
720672 1000374579 B58 GUARD - 6044/6047 RIGHT, BACK;Charcoal Metalic No Model Compatibility List $0.00 / Each
Out Of Stock
9,3,4,5,6
720673 1000374580 B59 GUARD - 6044/6047 RIGHT, FRONT;Charcoal Metallic No Model Compatibility List $0.00 / Each
Out Of Stock
9,3
720674 1000374582 DP2 Pulley Housing Assy;Iced Silver No Model Compatibility List $397.12 / Each

8
720675 1000374583 DP 2 Swivel Pulley Assy;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock
8,4,5,6
720676 1000374584 DP 2 Swivel Pulley Assy;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock
8,4,5,6
720677 1000374596 B4 1/4" PLASMA;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock
1
720678 1000374597 B4 1/4" PLASMA;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
720679 1000374598 B4 1/4" PLASMA;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
720680 1000374610 B5 1/4" PLASMA;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock
1
720681 1000374611 B5 1/4" PLASMA;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
720682 1000374612 B5 1/4" PLASMA;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
720683 1000374624 B13 1 1/2" x 2" TUBE - 3";Black Ridge No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
720684 1000374626 AB1 Main Frame - Left;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock
3
720685 1000374627 AB1 Main Frame - Left;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
720686 1000374628 AB1 Main Frame - Left;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
720687 1000374641 AB2 Main Frame - Right;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock
3
720688 1000374642 AB2 Main Frame - Right;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
720689 1000374643 AB2 Main Frame - Right;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
720690 1000374655 Weight Stack 7 WELDMENT 12X CENTER STICK WITH COLLAR;Black Ridge No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
720691 1000374657 B20 3/4"OD x 7/16"ID PIPE - 1";Black Ridge No Model Compatibility List $0.00 / Each
Out Of Stock
1
721552 1000384006 V58 Serial Number Label;4" x 1.5";3M; No Model Compatibility List $0.00 / Each
Out Of Stock
721920 1000386596 Pulley Set WEIGHT STACK PULLEY ASSEMBLY No Model Compatibility List $217.98 / Each

721921 1000386597 Pulley 2 HCS 1/4"-20 x 3.00" Zinc No Model Compatibility List $0.00 / Each
Out Of Stock
723268 1000406013 Pulley 1 Weldment; Head Plate Pulley;Black Ridge No Model Compatibility List $0.00 / Each
Out Of Stock
723853 1000412711 DP 16 Decal;Warning Pull Pin No Model Compatibility List $0.00 / Each
Out Of Stock
724500 1000421116 DP 1 Slide Assy;Silver Metallic No Model Compatibility List $667.52 / Each

3
View Drawing
