Matrix Commercial - VY-D821-02 - 2013

Repair Parts for Matrix Commercial VY-D821-02 VYTS19

Brand: Matrix Commercial

Category: Multi Station

Type: Strength Systems

Model Number:

Model Numbers are Unique Identifiers, they are important because they lead you to access diagrams and part lists specific to the version of a given model equipment you own. Bottom line, they help you get the right part. Note: Sometimes we put a serial prefix in this field to elicit versioning, and if this field is blank that means the model name alone will suffice for part selection.

VYTS19

Model Name: VY-D821-02

Version: 2013

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

17168.0-base.pdf

VIEWS

Catalog #	MPN	Part List Key	Part Description	Available Used	Model Compatibility List	New price
713806	1000308417	B22	2" x 2" END CAP	No	Model Compatibility List	$5.46 / Each
713811	1000308424	B1	SPRING PIN ASSEMBLY	No	Model Compatibility List	$45.60 / Each
713818	1000308436	Z7	WASHER;FLT;USS;Diam.0.344XDiam.0.875X.06	No	Model Compatibility List	$1.43 / Each
713821	1000308439	Z18	NUT;NLK;.375-16;ZN;	No	Model Compatibility List	$1.43 / Each	2
713826	1000308444	Z12	WASHER;FLT;USS;Diam.0.406XDiam.1.000X.06	No	Model Compatibility List	$1.43 / Each
713828	1000308446	Z13	WASHER;FLT;USS;Diam.0.281XDiam.0.734X.06	No	Model Compatibility List	$1.43 / Each
713830	1000308448	Z8	5/16" X 1 1/2" BOLT	No	Model Compatibility List	$1.43 / Each
713834	1000308452	B36	7" RUBBER FOOT	No	Model Compatibility List	$14.59 / Each	9,3
713841	1000308472	V25	Lable, Olympic Bench	No	Model Compatibility List	$6.73 / Each	1
713842	1000308473	V27	Lable, hand pinch	No	Model Compatibility List	$3.02 / Each
713941	1000309848	Z14	SCREW;HH;.500-13 x 3.50;ZN;	No	Model Compatibility List	$5.04 / Each	2
713943	1000309851	Z15	SCREW;HH;.375-16 x 2.25;ZN;	No	Model Compatibility List	$2.18 / Each
713975	1000310008	Not Shown	ROUND LEVELER BOOT	No	Model Compatibility List	$5.04 / Each	3
713996	1000310095	B20	1/2" OD x 1/4" ID Plastic Spacer - 1"	No	Model Compatibility List	$1.33 / Each
713998	1000310097	Z16	SCREW;HH;.250-20 x 2.00;ZN;	No	Model Compatibility List	$1.33 / Each
714014	1000310211	Z19	1/4" HEX HEAD NUT	No	Model Compatibility List	$1.33 / Each	2
714017	1000310270	B21	1"OD x 5/8"ID NYLON PIPE - 3 1/2"	No	Model Compatibility List	$21.94 / Each	1
714018	1000310273	B30	4" FOOT (SHORT)	No	Model Compatibility List	$20.05 / Each
714038	1000310334	Weight Stack 1	6000 TOP PLATE	No	Model Compatibility List	$78.47 / Each
714040	1000310339	B35	ROUND WEIGHT STACK BUMPER	No	Model Compatibility List	$5.90 / Each Out Of Stock
714041	1000310343	Weight Stack 2	Orange SELECTOR PIN w/ 6 1/2" CORD	No	Model Compatibility List	$25.53 / Each
714118	1000312127	Weight Stack 4	BHS 5/16" - 1"	No	Model Compatibility List	$5.46 / Each
714127	1000312161	Z17	NUT;NLK;.500-13;ZN;TALL;	No	Model Compatibility List	$1.43 / Each
714193	1000312342	V26	DECAL,WARNING: BOLT DOWN;English	No	Model Compatibility List	$0.00 / Each Out Of Stock
714235	1000312700	Z11	7/16" FLAT WASHER	No	Model Compatibility List	$2.44 / Each
714240	1000312817	Weight Stack 3	5/16" SPLIT LOCK WASHER	No	Model Compatibility List	$1.33 / Each
714249	1000312880	Weight Stack 8	CAST IRON	No	Model Compatibility List	$104.75 / Each
714253	1000312893	B10	3/8" SAFETY CLIP	No	Model Compatibility List	$16.82 / Each
714332	1000313746	B5	Cable Assembly D821	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6
714333	1000313747	B34	5/8" CRR - 81 1/2"	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
714334	1000313766	B9	HARD CHROME 48" LAT BAR	No	Model Compatibility List	$339.66 / Each
714465	1000315136	V32	6000 STACK DECALS, MEDIUM	No	Model Compatibility List	$30.39 / Each
714484	1000315356	V31	6000 STACK DECALS, HEAVY	No	Model Compatibility List	$0.00 / Each Out Of Stock	7,3,4,5,6
714538	1000315894	V24	DECAL MATRIX 11X1 - Black for Blue Moon, Iced Silver, Blood Red, White, Sunburst Orange, Fence Green, or Yellow frame	No	Model Compatibility List	$6.73 / Each
714592	1000316304	V25	DECAL OLY BENCH;French	No	Model Compatibility List	$8.42 / Each	7,3
714593	1000316305	V25	DECAL,WARNING: OLY BENCH;German	No	Model Compatibility List	$0.00 / Each Out Of Stock	7,3
714594	1000316306	V25	DECAL,WARNING: OLY BENCH;Italian	No	Model Compatibility List	$0.00 / Each Out Of Stock	7,3
714595	1000316307	V25	DECAL,WARNING: OLY BENCH;Portuguese	No	Model Compatibility List	$0.00 / Each Out Of Stock	7,3
714596	1000316308	V25	DECAL,WARNING: OLY BENCH;Japanese	No	Model Compatibility List	$0.00 / Each Out Of Stock	7,3
714915	1000319630	V26	DECAL,WARNING: BOLT DOWN;French	No	Model Compatibility List	$0.00 / Each Out Of Stock	7,2,3
714916	1000319631	V26	DECAL,WARNING: BOLT DOWN;German	No	Model Compatibility List	$0.00 / Each Out Of Stock	7,2,3
714917	1000319632	V26	DECAL,WARNING: BOLT DOWN;Italian	No	Model Compatibility List	$13.49 / Each	7,2,3
714918	1000319633	V26	DECAL,WARNING: BOLT DOWN;Portuguese	No	Model Compatibility List	$5.04 / Each	7,2,3
714919	1000319634	V26	DECAL,WARNING: BOLT DOWN;Japanese	No	Model Compatibility List	$5.04 / Each	7,2,3
716520	1000337073	AB2	Weldment,Frame,D821;Iced Silver	No	Model Compatibility List	$0.00 / Each Out Of Stock	3
716521	1000337074	AB2	Weldment,Frame,D821;Black Glossy	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6
716522	1000337075	AB2	Weldment,Frame,D821;Lace White	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6
717377	1000344562	V24	Decal;Matrix;Grey for Black Matte, Black Ridge, Black Glossy, Moss Green, or Blue Streak frame	No	Model Compatibility List	$15.18 / Each
717500	1000345600	B3	5/8# Single Split Collar	No	Model Compatibility List	$10.92 / Each
717779	1000347532	B6	4.5" Pulley for Rope / Cable	No	Model Compatibility List	$18.56 / Each
717825	1000347900	AB28	339-701 w/ ROM Decal	No	Model Compatibility List	$0.00 / Each Out Of Stock	7,3
719871	1000366538	Weight Stack 7	Weldment;Center Stick;	No	Model Compatibility List	$0.00 / Each Out Of Stock	3
719878	1000366571	Weight Stack Set	WEIGHT STACK 190# 20+1 CRIMP CABLE	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6
721552	1000384006	V23	Serial Number Label;4" x 1.5";3M;	No	Model Compatibility List	$0.00 / Each Out Of Stock
729261	See Pad Matrix	J4	Elbow Pad;;PU;Black;;FW213-KM;	No	Model Compatibility List	$0.00 / Each Out Of Stock
