Matrix Commercial - VY-D842-02 - 2013

Repair Parts for Matrix Commercial VY-D842-02 VYTS22

Brand: Matrix Commercial

Category: Multi Station

Type: Strength Systems

Model Number:

Model Numbers are Unique Identifiers, they are important because they lead you to access diagrams and part lists specific to the version of a given model equipment you own. Bottom line, they help you get the right part. Note: Sometimes we put a serial prefix in this field to elicit versioning, and if this field is blank that means the model name alone will suffice for part selection.

VYTS22

Model Name: VY-D842-02

Version: 2013

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

17172.0-base.pdf

VIEWS

Catalog #	MPN	Part List Key	Part Description	Available Used	Model Compatibility List	New price
713806	1000308417	B8	2" x 2" END CAP	No	Model Compatibility List	$5.46 / Each
713814	1000308428	Z16	3/8" NUT	No	Model Compatibility List	$1.43 / Each
713818	1000308436	Z14	WASHER;FLT;USS;Diam.0.344XDiam.0.875X.06	No	Model Compatibility List	$1.43 / Each
713826	1000308444	Z12	WASHER;FLT;USS;Diam.0.406XDiam.1.000X.06	No	Model Compatibility List	$1.43 / Each
713827	1000308445	Z19	5/16" - 3" BOLT	No	Model Compatibility List	$2.18 / Each
713828	1000308446	Z13	WASHER;FLT;USS;Diam.0.281XDiam.0.734X.06	No	Model Compatibility List	$1.43 / Each
713834	1000308452	B31	7" RUBBER FOOT	No	Model Compatibility List	$14.59 / Each	9,3
713841	1000308472	V27	Lable, Olympic Bench	No	Model Compatibility List	$6.73 / Each	1
713842	1000308473	V26	Lable, hand pinch	No	Model Compatibility List	$3.02 / Each
713943	1000309851	Z20	SCREW;HH;.375-16 x 2.25;ZN;	No	Model Compatibility List	$2.18 / Each
713996	1000310095	B9	1/2" OD x 1/4" ID Plastic Spacer - 1"	No	Model Compatibility List	$1.33 / Each
713998	1000310097	Z21	SCREW;HH;.250-20 x 2.00;ZN;	No	Model Compatibility List	$1.33 / Each
714013	1000310208	Z33	1/2" Split Lock Washer	No	Model Compatibility List	$0.00 / Each Out Of Stock	2
714014	1000310211	Z17	1/4" HEX HEAD NUT	No	Model Compatibility List	$1.33 / Each	2
714016	1000310219	Z34	SCREW;HH;.250-20 x 0.75;ZN;	No	Model Compatibility List	$1.33 / Each
714017	1000310270	B5	1"OD x 5/8"ID NYLON PIPE - 3 1/2"	No	Model Compatibility List	$21.94 / Each	1
714038	1000310334	Weight Stack 1	6000 TOP PLATE	No	Model Compatibility List	$78.47 / Each
714040	1000310339	B23	ROUND WEIGHT STACK BUMPER	No	Model Compatibility List	$5.90 / Each Out Of Stock
714041	1000310343	Weight Stack 2	Orange SELECTOR PIN w/ 6 1/2" CORD	No	Model Compatibility List	$25.53 / Each
714107	1000312095	Z18	SCREW;HH;.500-13 x 3.25;ZN;	No	Model Compatibility List	$5.04 / Each
714118	1000312127	Weight Stack 4	BHS 5/16" - 1"	No	Model Compatibility List	$5.46 / Each
714127	1000312161	Z15	NUT;NLK;.500-13;ZN;TALL;	No	Model Compatibility List	$1.43 / Each
714193	1000312342	V29	DECAL,WARNING: BOLT DOWN;English	No	Model Compatibility List	$0.00 / Each Out Of Stock
714235	1000312700	Z11	7/16" FLAT WASHER	No	Model Compatibility List	$2.44 / Each
714240	1000312817	Weight Stack 3	5/16" SPLIT LOCK WASHER	No	Model Compatibility List	$1.33 / Each
714249	1000312880	Weight Stack 8	CAST IRON	No	Model Compatibility List	$104.75 / Each
714253	1000312893	B7	3/8" SAFETY CLIP	No	Model Compatibility List	$16.82 / Each
714333	1000313747	B22	5/8" CRR - 81 1/2"	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
714343	1000313862	B3	Cable,D842	No	Model Compatibility List	$0.00 / Each Out Of Stock	4,5,6
714344	1000313871	B10	TRICEP ROPE (MA-TA)	No	Model Compatibility List	$213.54 / Each
714465	1000315136	V25	6000 STACK DECALS, MEDIUM	No	Model Compatibility List	$30.39 / Each
714538	1000315894	V28	DECAL MATRIX 11X1 - Black for Blue Moon, Iced Silver, Blood Red, White, Sunburst Orange, Fence Green, or Yellow frame	No	Model Compatibility List	$6.73 / Each
714592	1000316304	V27	DECAL OLY BENCH;French	No	Model Compatibility List	$8.42 / Each	7,3
714915	1000319630	V29	DECAL,WARNING: BOLT DOWN;French	No	Model Compatibility List	$0.00 / Each Out Of Stock	7,2,3
715964	1000329669	Weight Stack 7	Weldment;Center Stick;	No	Model Compatibility List	$0.00 / Each Out Of Stock	3
716237	1000334773	AB1	Weldment,Frame,D842;Iced Silver	No	Model Compatibility List	$0.00 / Each Out Of Stock	3
716238	1000334774	AB1	Weldment,Frame,D842;Black Glossy	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6
716239	1000334775	AB1	Weldment,Frame,D842;Lace White	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6
716313	1000335318	B32	CLAMP - COVER	No	Model Compatibility List	$0.00 / Each Out Of Stock
717377	1000344562	V28	Decal;Matrix;Grey for Black Matte, Black Ridge, Black Glossy, Moss Green, or Blue Streak frame	No	Model Compatibility List	$15.18 / Each
717500	1000345600	B2	5/8# Single Split Collar	No	Model Compatibility List	$10.92 / Each
717779	1000347532	B6	4.5" Pulley for Rope / Cable	No	Model Compatibility List	$18.56 / Each
719881	1000366574	Weight Stack Set	WEIGHT STACK 12+1 156# CRIMP CABLE	No	Model Compatibility List	$0.00 / Each Out Of Stock	3,4,5,6
721552	1000384006	V30	Serial Number Label;4" x 1.5";3M;	No	Model Compatibility List	$0.00 / Each Out Of Stock
729261	See Pad Matrix	J4	Elbow Pad;;PU;Black;;FW213-KM;	No	Model Compatibility List	$0.00 / Each Out Of Stock
