Matrix Fitness - Matrix CXV Virtual Training Cycle - FC27 - FC31 - 2021 - 2021-2030

Repair Parts for Matrix Fitness Matrix CXV Virtual Training Cycle - FC27 - FC31 - 2021 FC31, FC27

Brand: Matrix Fitness

Category: Single Station

Type: Strength Systems

Model Number:

Model Numbers are Unique Identifiers, they are important because they lead you to access diagrams and part lists specific to the version of a given model equipment you own. Bottom line, they help you get the right part. Note: Sometimes we put a serial prefix in this field to elicit versioning, and if this field is blank that means the model name alone will suffice for part selection.

FC31, FC27

Model Name: Matrix CXV Virtual Training Cycle - FC27 - FC31 - 2021

Serial Number Prefix: FC31, FC27

Version: 2021-2030

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

diag_424_CXV Parts List.pdf

VIEWS

Catalog #	MPN	Part List Key	Part Description	Available Used	Model Compatibility List	New price
1020604	004483-00		Front Roller Screw M8-1.25"x25mm	Yes	Model Compatibility List	$11.99 / Each
730132	001678-A	P33	Cable Fix Button;KSS/UC-2	No	Model Compatibility List	$1.28 / Each
730481	1000438725	P30	Adapter;;100-240V/50-60Hz;12.6V/7.6A;	No	Model Compatibility List	$111.78 / Each
730482	1000414854	P31	Extensionernal Power Wire;US/CA;;;;;;600	No	Model Compatibility List	$6.48 / Each
730823	1000466031	13	Stabilizer Tube Set;;back;;FC27;;	No	Model Compatibility List	$140.38 / Each
730824	1000448603	2	Adjustable Handle Group;Cushions;;;FC27;	No	Model Compatibility List	$63.68 / Each
730825	1000441505	5	Pedal set;;;;;VP-S5;;FC23;	No	Model Compatibility List	$120.88 / Each
730826	1000466032	AJ2	stabilizer set;;Rear;painting;;Black Mat	No	Model Compatibility List	$0.00 / Each Out Of Stock
730827	1000444810	AR2	Fly Wheel Set;;;;FC20-US;;	No	Model Compatibility List	$0.00 / Each Out Of Stock
730828	1000441870	AR4	Pully Set;;Small;Include Axle;FC27;;	No	Model Compatibility List	$0.00 / Each Out Of Stock
730829	1000441673	AY1	Controller;;;H001;;;FC27;Athena Quadratu	No	Model Compatibility List	$0.00 / Each Out Of Stock
730830	1000441667	AY2	Controller;Generator;;H001;V1.16;;FC27;	No	Model Compatibility List	$0.00 / Each Out Of Stock
730831	1000456189	B32	Shim;Support Tube;;SUS304;1.6T;;FC27;	No	Model Compatibility List	$0.00 / Each Out Of Stock
730832	1000454903	C08	Shim;Console Mast2;;SPHC;3.0T;BED;FC27;	No	Model Compatibility List	$0.00 / Each Out Of Stock
730833	1000448604	D23	Adjustable Grip;;;PC 510;137C/80395;;FC2	No	Model Compatibility List	$11.68 / Each
730834	1000436663	Flywheel 001	Bearing;Ball;6800ZZ;Diam.10xDiam.19x5T;;	No	Model Compatibility List	$5.18 / Each
730835	1000448606	G02	Fixing Plate;Handlebar Tube;;S45C;3.0T;W	No	Model Compatibility List	$2.32 / Each
730836	1000441728	G15	Mobile Phone Holder;;;ABS PA746+TPU;BL/B	No	Model Compatibility List	$0.00 / Each Out Of Stock
730837	1000448617	G75	Adjustable Base;;;;Anti-rust oil coating	No	Model Compatibility List	$15.58 / Each
730838	1000448608	G76	Location Pin;;;S45C;Zinc;FC27;;	No	Model Compatibility List	$3.88 / Each
730839	1000448698	G80	Location Pin;Handlebar;Up;S45C;White Zin	No	Model Compatibility List	$3.88 / Each
730840	1000448699	G81	Location Pin;Handlebar;Down;S45C;White Z	No	Model Compatibility List	$2.32 / Each
730841	1000456774	G84	Spacer;;;Powder metallurgy;Anti-rust oil	No	Model Compatibility List	$2.32 / Each
730842	1000441657	P02	Console Wire;;;;;;;1800(MOLEX,50-57-9408	No	Model Compatibility List	$0.00 / Each Out Of Stock
730843	1000441658	P03	Switch Wire;;;;;;;300(Taiway,YVM-04C07x2	No	Model Compatibility List	$0.00 / Each Out Of Stock
730844	1000441680	P04	Signal ConnectN Wire;;;;;;;60(TKP,H20J2-	No	Model Compatibility List	$0.00 / Each Out Of Stock
730845	1000448516	P09	Hall Connect Wire;;;;;;;450(hall+TKP,H20	No	Model Compatibility List	$0.00 / Each Out Of Stock
730846	1000441659	P13	Power wire;;;;;;;450(SCD-554DCS103B00G+T	No	Model Compatibility List	$0.00 / Each Out Of Stock
730847	1000441660	P14	Network Signal Wire;;;;;;;1700(3203A2242	No	Model Compatibility List	$0.00 / Each Out Of Stock
730848	003379-00	P35	WIRE FERRITE CORE	No	Model Compatibility List	$2.58 / Each
730849	0000086225	P50	Screw;BH;M3X0.5PX15L;;PH;;BAN;;	No	Model Compatibility List	$1.28 / Each
730850	1000448590	Q02	Cover;;left;ABS PA746;BL/Black C;;FC27;	No	Model Compatibility List	$0.00 / Each Out Of Stock
730851	1000448591	Q03	Cover;;right;ABS PA746;BL/Black C;;FC27;	No	Model Compatibility List	$0.00 / Each Out Of Stock
730852	1000455963	Q11	Power Socket;;;ABS/PA757;BL/Black C;;FC2	No	Model Compatibility List	$0.00 / Each Out Of Stock
730853	1000455961	Q15	Cover;Handlebar;back;ABS/PA757;BL/Black	No	Model Compatibility List	$0.00 / Each Out Of Stock
730854	1000455962	Q16	Cover;Handlebar;down;ABS/PA757;BL/Black	No	Model Compatibility List	$0.00 / Each Out Of Stock
730855	0000081745	Q53	Screw;Umbrella Cross;M5x0.8Px8L;Stainless	No	Model Compatibility List	$1.28 / Each
730856	1000441875	S06	Gear;Transmission;;;Prevent-rust-oil;;FN	No	Model Compatibility List	$0.00 / Each Out Of Stock
730857	1000441543	T14	Toe cage;;;VP-S5(VP-792);	No	Model Compatibility List	$3.88 / Each
730858	1000435139	Z01	Screw;Socket Head;M12x1.75Px25L;;Hex Soc	No	Model Compatibility List	$2.32 / Each
730859	1000435218	Z02	Washer;Flat;Diam.12.0xDiam.26.0x2.0T;Sta	No	Model Compatibility List	$1.02 / Each
730860	1000441877	9	flywheel set;ECB;;;FC27;;	No	Model Compatibility List	$0.00 / Each Out Of Stock
730861	1000448580	12	Stabilizer Tube Set;;front;;FC27;;	No	Model Compatibility List	$0.00 / Each Out Of Stock
730862	1000441884	14	Transmission system Set;;;;FC27;;	No	Model Compatibility List	$0.00 / Each Out Of Stock
730863	1000448549	AB1	Frame Set;;;painting;BP-9A85S;DM328;FC27	No	Model Compatibility List	$0.00 / Each Out Of Stock
730864	1000456096	AB5	Frame Support Rack Set;;;painting;;;FC27	No	Model Compatibility List	$0.00 / Each Out Of Stock
730865	1000441790	AC1	Console Support Tube Set;;;painting;BP-9	No	Model Compatibility List	$0.00 / Each Out Of Stock
730866	1000444251	AD6	Connect base-Extrawork;Seat tube ADJ Han	No	Model Compatibility List	$0.00 / Each Out Of Stock
730867	1000448594	AG3	Grip Set-Extrawork;;;Dipping PVC;Black;F	No	Model Compatibility List	$0.00 / Each Out Of Stock
730868	1000448581	AJ1	stabilizer set;;F;painting;;Black Matte;	No	Model Compatibility List	$0.00 / Each Out Of Stock
730869	1000466034	AJ6	grip-Extrawork;;;Dipping PVC;Black;FC27;	No	Model Compatibility List	$0.00 / Each Out Of Stock
730870	1000441833	AP1	Motor Set;;;.;FC27;;	No	Model Compatibility List	$0.00 / Each Out Of Stock
730871	1000448588	AQ1	shield set;;up;;FC27;;	No	Model Compatibility List	$0.00 / Each Out Of Stock
730872	1000441883	AR1	Center Axle Sleeve Set;;;;FC27;;	No	Model Compatibility List	$0.00 / Each Out Of Stock
730873	1000434992	B14	Pillar;Cover;;;Anti-rust oil coating;FC2	No	Model Compatibility List	$0.00 / Each Out Of Stock
730874	1000456986	P60	Screw;Round Head;M4x0.7Px6L;;Phillip;;Bl	No	Model Compatibility List	$0.00 / Each Out Of Stock
730875	1000405569	Z11	Screw;Round Head;M6x1.0Px40L-20L;Partial	No	Model Compatibility List	$0.00 / Each Out Of Stock
730876	1000451680	Z12	Screw;Oval Head;M8x1.25Px40L;;Hex Socket	No	Model Compatibility List	$0.00 / Each Out Of Stock
730877	1000460056	Not Shown	Hardware Assembly;;;For Service;FC27;;	No	Model Compatibility List	$0.00 / Each Out Of Stock
730878	0000086251	Seat Adj 003	NUT;NLK;M5X0.8P;SS41;BAN;;	No	Model Compatibility List	$0.00 / Each Out Of Stock
730879	020084-00	B50	SCREW;SH;M8X1.25PX40L;;HS;;;;	No	Model Compatibility List	$0.00 / Each Out Of Stock
730880	020113-A	Z13	SCREW;SH;M6X1.0PX55L-20L ;;HS;;;;P-T	No	Model Compatibility List	$0.00 / Each Out Of Stock
976932	004926-00		Nylon Lock Nut M8x1.25P (New)	No	Model Compatibility List	$12.99 / Each

View Drawing
