Matrix Fitness - MG-946-06 - MG-FS946-06 - Lat Pulldown / Low Row - 2018 - 2018

Repair Parts for Matrix Fitness MG-946-06 - MG-FS946-06 - Lat Pulldown / Low Row - 2018 MGPTS72, MGPTS71

Brand: Matrix Fitness

Category: Single Station

Type: Strength Systems

Model Number:

Model Numbers are Unique Identifiers, they are important because they lead you to access diagrams and part lists specific to the version of a given model equipment you own. Bottom line, they help you get the right part. Note: Sometimes we put a serial prefix in this field to elicit versioning, and if this field is blank that means the model name alone will suffice for part selection.

MGPTS72, MGPTS71

Model Name: MG-946-06 - MG-FS946-06 - Lat Pulldown / Low Row - 2018

Serial Number Prefix: MGPTS72, MGPTS71

Version: 2018

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

diag_46_Clamp Set Parts List.pdf

VIEWS

Catalog #	MPN	Part List Key	Part Description	Available Used	Model Compatibility List	New price

735296	1000334550	AB1	WELDMENT MAIN FRAME CENTER;Iced Silver	No	Model Compatibility List	$0.00 / Each Out Of Stock
735297	1000334551	AB1	WELDMENT MAIN FRAME CENTER;Black Glossy	No	Model Compatibility List	$0.00 / Each Out Of Stock
735298	1000334552	AB1	WELDMENT MAIN FRAME CENTER;Lace White	No	Model Compatibility List	$0.00 / Each Out Of Stock
735291	1000412059	AB2	Seat Frame Assy;946;Iced Silver	No	Model Compatibility List	$1078.98 / Each
735292	1000412060	AB2	Seat Frame Assy;946;Black Glossy	No	Model Compatibility List	$1076.38 / Each
735299	1000412061	AB2	Seat Frame Assy;946;Lace White	No	Model Compatibility List	$0.00 / Each Out Of Stock
734033	1000463002	B4	Stack Guard;Metal 4 Hole;	No	Model Compatibility List	$0.00 / Each Out Of Stock
735300	1000324103	B13	10ga PLASMA	No	Model Compatibility List	$0.00 / Each Out Of Stock
735293	1000324104	B15	PLATE ABS FOOT PLATE	No	Model Compatibility List	$24.68 / Each
730027	1000310331	B29	10ga PLASMA - 1 1/2" x 5 1/4"	No	Model Compatibility List	$0.00 / Each Out Of Stock
735301	1000421279	B56	Cable Assy;946;	No	Model Compatibility List	$0.00 / Each Out Of Stock
730820	1000393238	B57	TAPE;Double faced 2" x 8.5	No	Model Compatibility List	$0.00 / Each Out Of Stock
735294	1000334577	B57	Cable#2 946	No	Model Compatibility List	$198.88 / Each
735295	1000432913	B58	Safety Tape;9.5";	No	Model Compatibility List	$23.38 / Each
717333	1000344108	Clamp Kit Set	900 Series Coupler Set;Metal;	No	Model Compatibility List	$131.79 / Each
731570	1000328307	Clamp Kit Set	900 SERIES TOWER CLAMP (SET OF 2)	No	Model Compatibility List	$0.00 / Each Out Of Stock
730659	1000337789	Coupler 1	Bracket;;;;0.187in;;900 Tower;Assembly;J	No	Model Compatibility List	$0.00 / Each Out Of Stock
717233	1000343290	Kit 1	Connect Plate;;;painting;;Black C;900 To	No	Model Compatibility List	$13.49 / Each
717216	1000342964	Kit 5	Pipe;3/4"ODx1/2"ID;With Zinc Coating	No	Model Compatibility List	$20.25 / Each
733135	1000424282	Weight Stack 7	Center Stick;19";CR3;	No	Model Compatibility List	$0.00 / Each Out Of Stock
733134	1000421546	Weight Stack Set	Weight Stack Assy;Stepped;#390;	No	Model Compatibility List	$0.00 / Each Out Of Stock
713826	1000308444	Z9	WASHER;FLT;USS;Diam.0.406XDiam.1.000X.06	No	Model Compatibility List	$1.43 / Each
714390	1000314246	Z9	SCREW;HH;.375-16 x 3.50;ZN;	No	Model Compatibility List	$3.90 / Each
713814	1000308428	Z34	3/8" NUT	No	Model Compatibility List	$1.43 / Each

View Drawing
