Matrix Fitness - MG-A510 - 10-Pair Pro-Style Dumbbell Rack - 2019 - 2019

Repair Parts for Matrix Fitness MG-A510 - 10-Pair Pro-Style Dumbbell Rack - 2019 FW322

Brand: Matrix Fitness

Category: Freeweight

Type: Strength Systems

Model Number:

Model Numbers are Unique Identifiers, they are important because they lead you to access diagrams and part lists specific to the version of a given model equipment you own. Bottom line, they help you get the right part. Note: Sometimes we put a serial prefix in this field to elicit versioning, and if this field is blank that means the model name alone will suffice for part selection.

FW322

Model Name: MG-A510 - 10-Pair Pro-Style Dumbbell Rack - 2019

Serial Number Prefix: FW322

Version: 2019

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

diag_165_Parts List.pdf

Catalog #	MPN	Part List Key	Part Description	Available Used	Model Compatibility List	New price
700145	000514-C	C14	Foot pad;Tube;Rubber;GM07	No	Model Compatibility List	$3.64 / Each	1
700249	000776-A	G02	Elastomer;E5-09B;FW91	No	Model Compatibility List	$9.52 / Each	1
701545	004573-AE	G03	Screw;Hex Socket;Sink;M10x1.5Px25L	No	Model Compatibility List	$3.64 / Each	1
701660	004696-AB	B07	Screw;Hex Socket;8X1.25X20L;Chromed	No	Model Compatibility List	$2.00 / Each	1
702121	005146-A	M07	Washer;Flat;10.5x20x2.0T;Black Zinc	No	Model Compatibility List	$2.00 / Each	1
713129	1000233200	C52	PLASTIC COVER;;NBR;BL;;;;	No	Model Compatibility List	$1.66 / Each	1
713460	1000303546	C51	Plastic Pad;Foot Pad;-;PP;BL427	No	Model Compatibility List	$3.35 / Each	1
719680	1000363753	V15	Warning Label;Plate Loaded;	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
719681	1000363756	V15	Warning Label;Plate Loaded;French	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
720322	1000371560	C18	Cap;Elliptical;;TPU;;Diam.50.0xDiam.100.	No	Model Compatibility List	$6.73 / Each	1
730755	0000086279	Z62	SCREW;SH;M10X1.5PX25L;;HS;;BAN;;	No	Model Compatibility List	$1.28 / Each	1
731832	1000426444	Not Shown	Spec Label;Weight;40X16;Oval;;;;2.5-150L	No	Model Compatibility List	$7.78 / Each	1
733218	1000426358	G01	Support Rack Set;Disassembly;;painting;;	No	Model Compatibility List	$445.88 / Each	1
733219	1000426305	G02	Fixing Plate;;;painting;;Black Matte;FW3	No	Model Compatibility List	$15.58 / Each	1
733220	1000435564	Not Shown	Manual;Assembly/Manipulate;;NA/EU;;FW323	No	Model Compatibility List	$14.28 / Each	1
733223	004573-AD	G04	SCREW;FH;M10X1.5PX25L;;HS;;CHM;;	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
733427	1000436753	AB1	Support Rack Set;;;painting;;Iced Sliver	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
733428	1000436758	AB1	Support Rack Set;;;painting;;Black Matte	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
733429	1000436766	AB1	Support Rack Set;;;painting;;Planet Fitn	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
733430	1000430469	Not Shown	Hardware Set;;;;;;FW322;	No	Model Compatibility List	$12.98 / Each	1
733431	1000432275	V01	EN LABEL;;;;;;;FW322-KM	No	Model Compatibility List	$0.00 / Each Out Of Stock	1

View Drawing
