Matrix Fitness - MG-MOPT-R47-02 - Connecting Flange - 2019 - 2019

Repair Parts for Matrix Fitness MG-MOPT-R47-02 - Connecting Flange - 2019 MGPR226

Brand: Matrix Fitness

Category: Single Station

Type: Strength Systems

Model Number:

Model Numbers are Unique Identifiers, they are important because they lead you to access diagrams and part lists specific to the version of a given model equipment you own. Bottom line, they help you get the right part. Note: Sometimes we put a serial prefix in this field to elicit versioning, and if this field is blank that means the model name alone will suffice for part selection.

MGPR226

Model Name: MG-MOPT-R47-02 - Connecting Flange - 2019

Serial Number Prefix: MGPR226

Version: 2019

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

diag_218_Parts List.pdf

Catalog #	MPN	Part List Key	Part Description	Available Used	Model Compatibility List	New price
713826	1000308444	Z9	WASHER;FLT;USS;Diam.0.406XDiam.1.000X.06	No	Model Compatibility List	$1.43 / Each	1
714099	1000312076	Z16	SCREW;HH;.375-16 x 0.75;ZN;	No	Model Compatibility List	$1.33 / Each	1
718939	1000354629	B3	5/16" HOLE PLUG; NYLON	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
721552	1000384006	V13	Serial Number Label;4" x 1.5";3M;	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
722195	1000388817	B30	Band Peg Attachment;	No	Model Compatibility List	$52.36 / Each	1
723695	1000411863	B22	Endcap;3" x 4";	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
732827	1000437540	Weight Stack Base AB	Weldment, MR47 Base; RH	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
732828	1000437542	Weight Stack Base AB	Weldment, MR47 Base; LH	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
732829	1000448494	Weight Stack Base B2	Lower Band Peg Assy; MR Rack	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
732830	1000437539	Weight Stack Base Se	Base Assembly; Weight StackS; RH	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
732831	1000437541	Weight Stack Base Se	Base Assembly; Weight StackS; LH	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
735209	1000437544	Weight Stack Top AB1	MR47 TOP; WEIGHT STACK MOUNT; LH	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
735210	1000437546	Weight Stack Top AB1	MR47 TOP; WEIGHT STACK MOUNT; RH	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
735211	1000437543	Weight Stack Top Set	TOP ASSEMBLY; WEIGHT STACKS; LH	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
735212	1000437545	Weight Stack Top Set	TOP ASSEMBLY; WEIGHT STACKS; RH	No	Model Compatibility List	$0.00 / Each Out Of Stock	1

View Drawing
