Replacement Parts for Matrix Fitness MG-SUP-04 - Step-up Platform w/Handle

Matrix Fitness - MG-SUP-04 - Step-up Platform w/Handle - 2019 - 2019

Repair Parts for Matrix Fitness MG-SUP-04 - Step-up Platform w/Handle - 2019

Brand: Matrix Fitness

Category: Single Station

Type: Strength Systems

Model Number:

Model Numbers are Unique Identifiers, they are important because they lead you to access diagrams and part lists specific to the version of a given model equipment you own. Bottom line, they help you get the right part. Note: Sometimes we put a serial prefix in this field to elicit versioning, and if this field is blank that means the model name alone will suffice for part selection.

Model Name: MG-SUP-04 - Step-up Platform w/Handle - 2019

Version: 2019

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

diag_228_Parts List.pdf

Catalog #	MPN	Part List Key	Part Description	Available Used	Model Compatibility List	New price
713806	1000308417	B41	2" x 2" END CAP	No	Model Compatibility List	$5.46 / Each	1
713814	1000308428	Z34	3/8" NUT	No	Model Compatibility List	$1.43 / Each	1
713818	1000308436	Z19	WASHER;FLT;USS;Diam.0.344XDiam.0.875X.06	No	Model Compatibility List	$1.43 / Each	1
713833	1000308451	B11	5" RUBBER FOOT	No	Model Compatibility List	$14.59 / Each	1
713940	1000309847	Z66	WASHER, .50 OD X .38 ID X .05	No	Model Compatibility List	$1.43 / Each	1
714032	1000310308	B9	4" FOOT (LONG)	No	Model Compatibility List	$18.23 / Each	1
714109	1000312099	Z101	HCS 1/2-13 x 4 1/4"	No	Model Compatibility List	$5.04 / Each	1
714127	1000312161	Z33	NUT;NLK;.500-13;ZN;TALL;	No	Model Compatibility List	$1.43 / Each	1
714235	1000312700	Z22	7/16" FLAT WASHER	No	Model Compatibility List	$2.44 / Each	1
714538	1000315894	V47	DECAL MATRIX 11X1 - Black for Blue Moon, Iced Silver, Blood Red, White, Sunburst Orange, Fence Green, or Yellow frame	No	Model Compatibility List	$6.73 / Each	1
720070	1000368439	V44	Warning Label;Plate Loaded;	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
720298	1000371230	Z30	Screw;HH;.375-16 x 3;ZN	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
721552	1000384006	V13	Serial Number Label;4" x 1.5";3M;	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
734194	1000448995	AB1	WELDMENT, MAIN FRAME; 104-474	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
734195	1000448993	B6	D-plate	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
734196	1000462852	B7	1 1/4"OD x .120 Wall HRP&O Pipe - 82 7/8"	No	Model Compatibility List	$0.00 / Each Out Of Stock	1
