Matrix Fitness - S-DRIVEM - TM534 - 2019 - 2019-2022

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

Search on this page by part name

Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
Deck Spring - Black 1000412624 1000412624 B46 2 Deck Spring - Black Yes Model Compatibility List $16.33 / Each
Out Of Stock
SCREW, SH, M6X1.0PX110L, HS, BAN, (Used) 1035593 0000089153 B53 1 SCREW, SH, M6X1.0PX110L, HS, BAN, (Used) No Model Compatibility List $5.00 / Each

Front Roller Screw M8-1.25 1020604 004483-00 Front Roller Screw M8-1.25"x25mm No Model Compatibility List $11.99 / Each

Screw;Round Head;M6x1.0Px25.5L;;Hex Sock 730175 1000395521 Z33 Screw;Round Head;M6x1.0Px25.5L;;Hex Sock No Model Compatibility List $2.58 / Each

Screw;Button Head;Diam.4x10L;Hi/Lo Threa 730893 1000400077 Seat Handle 001 Screw;Button Head;Diam.4x10L;Hi/Lo Threa No Model Compatibility List $1.02 / Each

Elastomer Set;Running Deck;Back;T1x-F; 730941 0000091092 14 Elastomer Set;Running Deck;Back;T1x-F; No Model Compatibility List $7.78 / Each

Clip Nut;Attached Plate;Elastomer;SPCC;1.6t;Zn Pl 730960 0000089165 B38 Clip Nut;Attached Plate;Elastomer;SPCC;1.6t;Zn Pl No Model Compatibility List $2.80 / Each

Nut;Nlk;M8X1.25Px6t;;BZN;; 730961 0000095437 B41 Nut;Nlk;M8X1.25Px6t;;BZN;; No Model Compatibility List $1.38 / Each

Screw;BH;M8X1.25PX20L;;HS;;BAN;; 730962 0000084584 B51 Screw;BH;M8X1.25PX20L;;HS;;BAN;; No Model Compatibility List $1.38 / Each

Elastomer Set;Semi-Assy;;Nai-Li;;TM501-1 731049 0000095663 AB29 Elastomer Set;Semi-Assy;;Nai-Li;;TM501-1 No Model Compatibility List $0.00 / Each
Out Of Stock
Bracket;Side Rail;SPHC;2.0t;TM501; 731079 0000084526 B23 Bracket;Side Rail;SPHC;2.0t;TM501; No Model Compatibility List $2.32 / Each

Washer;Flat;Diam.6.0XDiam.16.0X1.0T;Stai 731209 0000082605 Z21 Washer;Flat;Diam.6.0XDiam.16.0X1.0T;Stai No Model Compatibility List $1.68 / Each

Clamp;Push Tie;KSS/KWS-2L;;;; 731314 1000354827 R63 Clamp;Push Tie;KSS/KWS-2L;;;; No Model Compatibility List $1.02 / Each

Adapter;;100-240V;12V/2A;;1.77m;TC-33024 731360 1000414837 P18 Adapter;;100-240V;12V/2A;;1.77m;TC-33024 No Model Compatibility List $0.00 / Each
Out Of Stock
lithium battery;;;;;HE1-10050-JS;5.5V;57 (v1.4) 731469 1000436683 P04 lithium battery;;;;;HE1-10050-JS;5.5V;57 (v1.4) No Model Compatibility List $0.00 / Each
Out Of Stock
Support tube group;handlebar;left;;TM533 731489 1000417021 11 Support tube group;handlebar;left;;TM533 No Model Compatibility List $292.48 / Each

Console Base Set;Semi-Assy;;;TM534-US/KM 731490 1000412962 14 Console Base Set;Semi-Assy;;;TM534-US/KM No Model Compatibility List $376.98 / Each

Arm Rest set;;;;TM534; 731491 1000413054 15 Arm Rest set;;;;TM534; No Model Compatibility List $1296.08 / Each

Console Set;;;MS/ES;H001;V1.13;TM534; 731492 1000414555 19 Console Set;;;MS/ES;H001;V1.13;TM534; No Model Compatibility List $380.88 / Each

Protection kits;;;Inner;TM533; 731493 1000412959 6 Protection kits;;;Inner;TM533; No Model Compatibility List $54.58 / Each

Arm Rest Set-Exreawork;;;Dipping PVC;;TM 731494 1000412967 AG9 Arm Rest Set-Exreawork;;;Dipping PVC;;TM No Model Compatibility List $1246.68 / Each

cover-Extrawork;;;Print;;TM533;Flywheel; 731495 1000412927 AQ12 cover-Extrawork;;;Print;;TM533;Flywheel; No Model Compatibility List $41.58 / Each

Fly Wheel Set;;;;TM533; 731496 1000412996 AR3 Fly Wheel Set;;;;TM533; No Model Compatibility List $153.38 / Each

flywheel set;;;;TM533;; 731497 1000412995 AR4 flywheel set;;;;TM533;; No Model Compatibility List $395.18 / Each

Roller Set;;back;Diam.89.7;TM529;; 731498 1000386203 AR6 Roller Set;;back;Diam.89.7;TM529;; No Model Compatibility List $253.48 / Each

Treadmill Belt;554X3330X2.3T;FORBO;;;;;N 731499 1000419266 AR7 Treadmill Belt;554X3330X2.3T;FORBO;;;;;N No Model Compatibility List $782.58 / Each

generator;;;;;BL90_X(0.45x105T/10P) 731500 1000411427 AS1 generator;;;;;BL90_X(0.45x105T/10P) No Model Compatibility List $292.48 / Each

Temsion knob set;;;;;;TM533; 731501 1000435513 AS10 Temsion knob set;;;;;;TM533; No Model Compatibility List $88.38 / Each

Temsion knob set;;;;;;TM533; 731502 1000435514 AS11 Temsion knob set;;;;;;TM533; No Model Compatibility List $88.38 / Each

ECB Set;;;;TM533;; 731503 1000413001 AS2 ECB Set;;;;TM533;; No Model Compatibility List $105.28 / Each

ECB Set;;;;TM533;; 731504 1000412998 AS3 ECB Set;;;;TM533;; No Model Compatibility List $74.08 / Each

Heart rate receiver;;;;;;SET;140(TKP,H66 731505 1000413003 AW1 Heart rate receiver;;;;;;SET;140(TKP,H66 No Model Compatibility List $57.18 / Each

Control Board;Generator;;H001;V1.19;;TM5 731506 1000424251 AY2 Control Board;Generator;;H001;V1.19;;TM5 No Model Compatibility List $172.88 / Each

Control Board;POWER;;H001;;;AR12; 731507 1000431831 AY4 Control Board;POWER;;H001;;;AR12; No Model Compatibility List $36.38 / Each

Foot Pad;Rubber 731508 0000081207 B41 Foot Pad;Rubber No Model Compatibility List $15.58 / Each

Clamp;Push Tie;CCMK-1;Black; 731509 1000419240 B87 Clamp;Push Tie;CCMK-1;Black; No Model Compatibility List $1.68 / Each

Cover;Console Base;;PC 510;BL/Black C;;T 731510 1000395508 C01 Cover;Console Base;;PC 510;BL/Black C;;T No Model Compatibility List $7.78 / Each

Handle Bar;;;painting;;Yellow;TM531;Gold 731511 1000402052 C03 Handle Bar;;;painting;;Yellow;TM531;Gold No Model Compatibility List $37.68 / Each

Cover;Arm Rest;;;BL/Black C;TPR+10%PP;TM 731512 1000395511 C04 Cover;Arm Rest;;;BL/Black C;TPR+10%PP;TM No Model Compatibility List $5.18 / Each

Rubber Pad;Consoel Mast;;SBR;BL/Black C; 731513 1000395512 C05 Rubber Pad;Consoel Mast;;SBR;BL/Black C; No Model Compatibility List $3.88 / Each

Drylin;;IGS;JUMO-01-16;;IGS; 731514 1000395525 C10 Drylin;;IGS;JUMO-01-16;;IGS; No Model Compatibility List $9.08 / Each

Pin;Pin;;Stainless;;TM531;; 731515 1000395515 C15 Pin;Pin;;Stainless;;TM531;; No Model Compatibility List $12.98 / Each

Bushing;;;SS41;Chrome;TM534;;Console Bas 731516 1000413051 C20 Bushing;;;SS41;Chrome;TM534;;Console Bas No Model Compatibility List $3.88 / Each

Screw;Button Head;M5x1.0Px56.5L;;Hex Soc 731517 1000402711 C22 Screw;Button Head;M5x1.0Px56.5L;;Hex Soc No Model Compatibility List $5.18 / Each

Spring;Compression;Pin;SWPB;Prevent-rust 731518 1000395519 C23 Spring;Compression;Pin;SWPB;Prevent-rust No Model Compatibility List $5.18 / Each

Screw;;M6x1.0Px15.5L;;Hex Socket;Stainle 731519 1000395520 C24 Screw;;M6x1.0Px15.5L;;Hex Socket;Stainle No Model Compatibility List $2.32 / Each

Screw;Socket Head;M8X1.25PX60L(30L);;Hex 731520 1000403359 C28 Screw;Socket Head;M8X1.25PX60L(30L);;Hex No Model Compatibility List $1.68 / Each

Screw;Hex Socket;Sink;Stainless;M5x0.8Px10L 731521 018625-AB C32 Screw;Hex Socket;Sink;Stainless;M5x0.8Px10L No Model Compatibility List $7.78 / Each

Screw;Socket Head;M6x1.0Px12L;;Hex Socke 731522 1000402134 C35 Screw;Socket Head;M6x1.0Px12L;;Hex Socke No Model Compatibility List $1.02 / Each

Screw;Socket Head;M6x1.0Px20L;;Hex Socke 731523 1000402135 C36 Screw;Socket Head;M6x1.0Px20L;;Hex Socke No Model Compatibility List $1.02 / Each

WASHER;WW;Diam.8.2XDiam.12.5X0.3T;;; 731524 005224-00 C37 WASHER;WW;Diam.8.2XDiam.12.5X0.3T;;; No Model Compatibility List $0.08 / Each

Washer;Wave;Diam.10.5xDiam.14.5x0.3T;;;R 731525 0000081849 C41 Washer;Wave;Diam.10.5xDiam.14.5x0.3T;;;R No Model Compatibility List $1.02 / Each

Positioning beads;;;;;TM534;Diam.6.0X9.0 731526 1000419821 C44 Positioning beads;;;;;TM534;Diam.6.0X9.0 No Model Compatibility List $6.48 / Each

Console Power Extension Wire;;Two;Black; 731527 1000412970 G30 Console Power Extension Wire;;Two;Black; No Model Compatibility List $38.98 / Each

Cover;Fixing Base;;PC 510;BL/Black C;;TM 731528 1000401883 N03 Cover;Fixing Base;;PC 510;BL/Black C;;TM No Model Compatibility List $5.18 / Each

Hardware Set;;;For Service;TM533;; 731529 1000424132 Not Shown Hardware Set;;;For Service;TM533;; No Model Compatibility List $25.98 / Each

Manual;;;English;;TM533 731530 1000421490 Not Shown Manual;;;English;;TM533 No Model Compatibility List $6.48 / Each

Power Extension Wire;;;;;;200L;(SCD-026C 731531 1000422312 P30 Power Extension Wire;;;;;;200L;(SCD-026C No Model Compatibility List $11.68 / Each

External Power Wire Set;;;;;;;1US;TM535 731532 1000422313 P33 External Power Wire Set;;;;;;;1US;TM535 No Model Compatibility List $11.99 / Each

Side Rail Set;;left;;TM533;; 731533 1000413086 Q03 Side Rail Set;;left;;TM533;; No Model Compatibility List $139.08 / Each

Pulley;;WZN;SS41;Diam.90; 731534 1000412921 R12 Pulley;;WZN;SS41;Diam.90; No Model Compatibility List $15.58 / Each

Pulley;;WZN;SS41;Diam.21;Genertor; 731535 1000412923 R13 Pulley;;WZN;SS41;Diam.21;Genertor; No Model Compatibility List $7.78 / Each

Belt;POLY-V;;170-J2;; 731536 1000411778 R15 Belt;POLY-V;;170-J2;; No Model Compatibility List $5.18 / Each

Decal;Safety;;Green;PVC;;;TM529 731537 1000382906 V08 Decal;Safety;;Green;PVC;;;TM529 No Model Compatibility List $2.32 / Each

Warning Label;Fly Wheel Cover;;;PVC;;;TM 731538 1000422614 V12 Warning Label;Fly Wheel Cover;;;PVC;;;TM No Model Compatibility List $2.32 / Each

Console Power Extension Wire;;1;;;;330L; 731539 1000412964 W03 Console Power Extension Wire;;1;;;;330L; No Model Compatibility List $14.28 / Each

Screw;Socket Head;M8x1.25Px20L;;Hex Sock 731540 1000402109 Z43 Screw;Socket Head;M8x1.25Px20L;;Hex Sock No Model Compatibility List $1.68 / Each

Screw;Button Head;M5X0.8PX20L;;Phillip;S 731541 1000403214 Z44 Screw;Button Head;M5X0.8PX20L;;Phillip;S No Model Compatibility List $1.02 / Each

Front Seat belt;;;;;TM533 731542 1000436627 01 Front Seat belt;;;;;TM533 No Model Compatibility List $0.00 / Each
Out Of Stock
Rear Seat belt;;;;;TM533 731543 1000436628 02 Rear Seat belt;;;;;TM533 No Model Compatibility List $0.00 / Each
Out Of Stock
Seat belt Set;;Elastic;;;TM533; 731544 1000436626 5 Seat belt Set;;Elastic;;;TM533; No Model Compatibility List $0.00 / Each
Out Of Stock
Frame Set;;;painting;;Black Matte;TM533; 731545 1000412958 AB2 Frame Set;;;painting;;Black Matte;TM533; No Model Compatibility List $0.00 / Each
Out Of Stock
Console Base Set;;;;TM534;; 731546 1000412963 AC11 Cnsl Base Console Base Set;;;;TM534;; No Model Compatibility List $0.00 / Each
Out Of Stock
Seat belt Slide Set;;;TM531-US/KM;T-DPT- 731547 1000404129 AC11 Handlebar Seat belt Slide Set;;;TM531-US/KM;T-DPT- No Model Compatibility List $0.00 / Each
Out Of Stock
Support Tube Welding Set;Arm Rest;L;pain 731548 1000417022 AC12 Support Tube Welding Set;Arm Rest;L;pain No Model Compatibility List $0.00 / Each
Out Of Stock
Support Tube Welding Set;Arm Rest;R;pain 731549 1000360865 AC14 Support Tube Welding Set;Arm Rest;R;pain No Model Compatibility List $0.00 / Each
Out Of Stock
Arm Rest;;Rear;painting;;Black Matte;TM5 731550 1000360871 AG8 Arm Rest;;Rear;painting;;Black Matte;TM5 No Model Compatibility List $0.00 / Each
Out Of Stock
Protected Sleeve;;;painting;;Black Matte 731551 1000412960 B19 Protected Sleeve;;;painting;;Black Matte No Model Compatibility List $0.00 / Each
Out Of Stock
Fixing Plate;Battery;;painting;;Black C; 731552 1000414735 B70 Fixing Plate;Battery;;painting;;Black C; No Model Compatibility List $0.00 / Each
Out Of Stock
Cover;Battery;;PC510;BL/Black C;;TM534; 731553 1000414552 B71 Cover;Battery;;PC510;BL/Black C;;TM534; No Model Compatibility List $0.00 / Each
Out Of Stock
Console Base Frame Set;;;painting;;Silve 731554 1000423169 C02 Console Base Frame Set;;;painting;;Silve No Model Compatibility List $0.00 / Each
Out Of Stock
Fixing Plate;Bolt;;Stainless Steel;4.0T; 731555 1000395532 C06 Fixing Plate;Bolt;;Stainless Steel;4.0T; No Model Compatibility List $0.00 / Each
Out Of Stock
Fixing Plate;Guide Rail2;;SS41(bright);; 731556 1000395533 C07 Fixing Plate;Guide Rail2;;SS41(bright);; No Model Compatibility List $0.00 / Each
Out Of Stock
Elliptical Track;;;73.9x310.0L;AL 6061 T 731557 1000395531 C08 Elliptical Track;;;73.9x310.0L;AL 6061 T No Model Compatibility List $0.00 / Each
Out Of Stock
Seat Silde Set;;;painting;;Bright silver 731558 1000423170 C09 Seat Silde Set;;;painting;;Bright silver No Model Compatibility List $0.00 / Each
Out Of Stock
Battery wire;;;;;;;60(TKP,H6630R1-06+TKP 731559 1000427078 P09 Battery wire;;;;;;;60(TKP,H6630R1-06+TKP No Model Compatibility List $0.00 / Each
Out Of Stock
Brass Pillar;;M3x0.5Px10L;;; 731560 1000424072 P52 Brass Pillar;;M3x0.5Px10L;;; No Model Compatibility List $0.00 / Each
Out Of Stock
Cover;Frame;;;BL/Black C;PA746H;TM529; 731561 1000360923 Q01 Cover;Frame;;;BL/Black C;PA746H;TM529; No Model Compatibility List $0.00 / Each
Out Of Stock
Nut;Cap;M8x1.25P;BED; 731562 004921-00 L51 Nut;Cap;M8x1.25P;BED; No Model Compatibility List $0.00 / Each
Out Of Stock
Velcro;Both Sides;50x50mm;TM65; 731563 001540-B Q11 Velcro;Both Sides;50x50mm;TM65; No Model Compatibility List $0.00 / Each
Out Of Stock
