Matrix Fitness - VY-D85A-04 - Multi-Adjustable Bench - 2020 - 2020

Repair Parts for Matrix Fitness VY-D85A-04 - Multi-Adjustable Bench - 2020 FW340

Brand: Matrix Fitness

Category: Freeweight

Type: Strength Systems

Model Name: VY-D85A-04 - Multi-Adjustable Bench - 2020

Serial Number Prefix: FW340

Version: 2020

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

   Show All Selected Attributes
  • Other
    Views
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
HALF-ROUND RUBBER BUMPER 713810 1000308421 B12 HALF-ROUND RUBBER BUMPER No Model Compatibility List $29.99 / Each

1
WASHER;FLT;USS;Diam.0.344XDiam.0.875X.06 713818 1000308436 Z19 WASHER;FLT;USS;Diam.0.344XDiam.0.875X.06 No Model Compatibility List $1.43 / Each

1
713821 1000308439 B6 NUT;NLK;.375-16;ZN; No Model Compatibility List $1.43 / Each

1
713824 1000308442 B11 SCREW;SET; .3125-18 X 1.00;SS No Model Compatibility List $1.43 / Each

1
WASHER;FLT;USS;Diam.0.281XDiam.0.734X.06 713828 1000308446 Z23 WASHER;FLT;USS;Diam.0.281XDiam.0.734X.06 No Model Compatibility List $1.43 / Each

1
713830 1000308448 Z15 5/16" X 1 1/2" BOLT No Model Compatibility List $1.43 / Each

1
713831 1000308449 Z32 NUT;NLK;.313-18;ZN; No Model Compatibility List $1.33 / Each

1
713832 1000308450 B39 1" Round Finishing Cap No Model Compatibility List $3.35 / Each

1
5 713833 1000308451 B11 5" RUBBER FOOT No Model Compatibility List $14.59 / Each

1
7 713834 1000308452 B15 7" RUBBER FOOT No Model Compatibility List $14.59 / Each

1
Lable, hand pinch 713842 1000308473 V45 Lable, hand pinch No Model Compatibility List $3.02 / Each

1
2 713937 1000309841 B42 2" X 3" END CAP No Model Compatibility List $7.28 / Each

1
1 1/2 713938 1000309842 B40 1 1/2" X 2" END CAP No Model Compatibility List $5.04 / Each

1
WASHER, .50 OD X .38 ID X .05 713940 1000309847 Z66 WASHER, .50 OD X .38 ID X .05 No Model Compatibility List $1.43 / Each

1
3/4 713950 1000309858 Z52 3/4" FLAT WASHER No Model Compatibility List $1.33 / Each

1
714096 1000312068 Z31 SCREW;HH;.313-18 x 2.25;ZN; No Model Compatibility List $2.18 / Each

1
714103 1000312087 Z10 SCREW;HH;.375-16 x 4.50;ZN; No Model Compatibility List $0.00 / Each
Out Of Stock 		1
714106 1000312093 6 SCREW;HH;.500-13 x 3.00;ZN; No Model Compatibility List $5.04 / Each

1
714110 1000312101 Z43 SCREW;HH;.500-13 x 5.00;ZN; No Model Compatibility List $5.04 / Each

1
NUT;NLK;.500-13;ZN;TALL; 714127 1000312161 Z33 NUT;NLK;.500-13;ZN;TALL; No Model Compatibility List $1.43 / Each

1
BACK PAD PLASTICS 714143 1000312207 J7 BACK PAD PLASTICS No Model Compatibility List $35.46 / Each

1
714145 1000312211 J12 Bottom Pad No Model Compatibility List $0.00 / Each
Out Of Stock 		1
2.5 714170 1000312280 B43 2.5" WHEEL No Model Compatibility List $7.28 / Each

1
1/2 714176 1000312298 Z15 1/2" BRASS BUSHING No Model Compatibility List $5.04 / Each

1
714538 1000315894 V47 DECAL MATRIX 11X1 - Black for Blue Moon, Iced Silver, Blood Red, White, Sunburst Orange, Fence Green, or Yellow frame No Model Compatibility List $6.73 / Each

1
717667 1000346693 B48 1 1/4"OD x 1"ID PLASTIC TUBE - 1.25" No Model Compatibility List $0.00 / Each
Out Of Stock 		1
719680 1000363753 V15 Warning Label;Plate Loaded; No Model Compatibility List $0.00 / Each
Out Of Stock 		1
721552 1000384006 V13 Serial Number Label;4" x 1.5";3M; No Model Compatibility List $0.00 / Each
Out Of Stock 		1
729261 See Pad Matrix J01 Elbow Pad;;PU;Black;;FW213-KM; No Model Compatibility List $0.00 / Each
Out Of Stock 		1
VY-D85A-04 Main Frame Assembly 733432 1000449506 AB1 VY-D85A-04 Main Frame Assembly No Model Compatibility List $0.00 / Each
Out Of Stock 		1
VY-D85A-04 Front Adj Assembly 733433 1000449502 AB2 VY-D85A-04 Front Adj Assembly No Model Compatibility List $0.00 / Each
Out Of Stock 		1
VY-D85A-04 Back pad Frame Assembly 733434 1000449505 AB3 VY-D85A-04 Back pad Frame Assembly No Model Compatibility List $0.00 / Each
Out Of Stock 		1
VY-D85A-04 Seat Frame Assembly 733435 1000449504 AB4 VY-D85A-04 Seat Frame Assembly No Model Compatibility List $0.00 / Each
Out Of Stock 		1
VY-D85A-04 Back Adj Assembly 733436 1000449503 AB5 VY-D85A-04 Back Adj Assembly No Model Compatibility List $0.00 / Each
Out Of Stock 		1
Foam Grip 1.00 733437 1000457141 B10 Foam Grip 1.00"ID 6.75 No Model Compatibility List $0.00 / Each
Out Of Stock 		1
1 x 1/2 733438 1000449507 B13 1 x 1/2" Endcap No Model Compatibility List $0.00 / Each
Out Of Stock 		1
1 1/4 733439 1000449508 B15 1 1/4"OD x 1"ID NYLON BUSHING STOCK - 3 1/4" No Model Compatibility List $0.00 / Each
Out Of Stock 		1
1/2 733440 1000449509 B18 1/2" ID PLASTIC SPACER FOR D85A-04 No Model Compatibility List $0.00 / Each
Out Of Stock 		1
View Drawing
