Matrix Retail - R30-02 XER - 2016

Repair Parts for Matrix Retail R30-02 XER RB207,TM698

Brand: Matrix Retail

Category: Recumbent

Type: Stationary Bikes

Model Name: R30-02 XER

Version: 2016

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

Search on this page by part name

Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
700014 000021-B B34 Mobile Wheel;Rear Deck Yes Model Compatibility List $11.62 / Each

D 700390 001193-00 D44 End-Cap;Seat Pad;20x40x1.6t;RB06 No Model Compatibility List $1.51 / Each

D 701091 003713-00 D85 Screw;RND;M4x20L;-;PH;-;WZN;-;-;ROHS; No Model Compatibility List $1.79 / Each

701139 004021-A T17 Pedal Set;w/ Belt;L/R;9/16-20UNF;Black1; No Model Compatibility List $0.00 / Each
Out Of Stock
701215 004177-A R07 Drive Belt;Poly-V;390-J8 Yes Model Compatibility List $57.49 / Each

D 701261 004321-AB D98 Screw;RND;M4x10L;-;PH;-;CHM;-;-; No Model Compatibility List $2.00 / Each

701288 004356-00 Q17 Screw;Phillip;BH;M4x0.7Px12L;Gap; No Model Compatibility List $2.00 / Each

Z 701348 004394-00 Z81 Screw;Phillip;BH;M6x1.0Px15L;;Zn-BL No Model Compatibility List $1.79 / Each

C 701449 004493-00 C16 Screw;Hex Socket;Round;M8x1.25Px16L No Model Compatibility List $1.79 / Each

H 701476 004523-00 H08 Screw;Hex Socket;Round;M8x1.25Px40L;Adhe No Model Compatibility List $2.00 / Each

701585 004616-00 P08 Screw;Umbrella Cross Tapped;4x12L No Model Compatibility List $2.00 / Each

701586 004617-00 S03 Screw;Console Case;Oval Tapping;4x15L No Model Compatibility List $2.00 / Each

701588 004618-00 D72 Screw;Oval Tapping;4x20L No Model Compatibility List $2.00 / Each

2,12,13,14
D 701685 004716-00 D95 Screw;BH;M6X1.0PX55L-23L;;HS;;BZN;;P-T No Model Compatibility List $1.79 / Each

701699 004724-00 D93 Bolt;M8x1.25Px15L Yes Model Compatibility List $2.00 / Each

D 701730 004756-00 D68 Screw;Hex Socket;BH;M8x1.25Px20L No Model Compatibility List $1.79 / Each

B 701734 004758-AD B35 Screw;BH;M10X1.5PX50L-15L;;HS;;CHM;;P-T No Model Compatibility List $1.25 / Each

C 701841 004859-00 C14 Screw;Umbrella Hex Scoket;M8x1.25Px20L No Model Compatibility List $2.00 / Each

2
701869 004891-00 R02 Nut;Hex;3/8-26UNCX9H No Model Compatibility List $2.00 / Each

R 701907 004933-00 R05 Nut;Nylon;1/4"--20UNC;BED No Model Compatibility List $1.79 / Each

B 701914 004943-00 B36 Nut;Nylon;M10x1.5P;Cr Plate; No Model Compatibility List $2.00 / Each

701961 005004-00 D96 Washer;Spring;Lock;SW6 6.1x12.2x1.5t No Model Compatibility List $2.00 / Each

D 701965 005005-AC D94 Washer;Split;8.2X15.4X2.0T;;BZN; No Model Compatibility List $1.79 / Each

H 701978 005015-00 H09 Washer;Spring;SW8 8.2X13.5X2.0T Yes Model Compatibility List $2.00 / Each

702217 005330-00 Q10 Tinnamen Nut Yes Model Compatibility List $1.59 / Each

702241 005366-00 T11 C-Clip;External;S-25 No Model Compatibility List $1.59 / Each

704068 020179-00 Q16 Screw;Phillip;BH;Tapped;4x12L;Flat End No Model Compatibility List $1.59 / Each

R 704096 020231-Z R03 SCREW;EB;1/4"-20UNCX70L-40L;;;;BZN;;HOLE No Model Compatibility List $3.69 / Each

Q 704273 022177-A Q11 Bracket;Side Cover;2 Hole Plate No Model Compatibility List $2.47 / Each

B 704979 028275-AA B37 Adjustable Leveler Yes Model Compatibility List $1.90 / Each

705700 055204-A Q13 Screw;SelfTapping;4x10L No Model Compatibility List $2.00 / Each

S 705770 056124-A S02 Tension Cable No Model Compatibility List $11.73 / Each

V 706142 059542-AX V06 Sticker;Warning No Model Compatibility List $1.77 / Each

1
R 707735 1000094722 R06 Drive Axle Assembly;RB134 No Model Compatibility List $273.75 / Each

P 708253 1000101534 P02 Speed Sensor Wire Yes Model Compatibility List $12.99 / Each

D 710774 1000213545 D66 Plastic Cover;F;ABS,PA-757;-;;;RB146-1US No Model Compatibility List $9.57 / Each

A 711941 1000224007 AD3 BACK PAD ADJUST SET;SA;;RB150;;; No Model Compatibility List $299.00 / Each

712041 1000225747 P01 WIRE;POWER SET;;900mmDC CKM 25430101-2P Yes Model Compatibility List $9.10 / Each

A 712462 1000228989 AT1 PEDAL SET;NO LOGO; Yes Model Compatibility List $54.73 / Each

T 712715 1000230349 T16 Screw;;;;;;;;; No Model Compatibility List $9.10 / Each

H 713376 1000301968 H03 ADJ plate;;;SPHC;4.0t;BED;RB307; No Model Compatibility List $3.35 / Each

H 713379 1000301971 H07 Spacing Sleeve;Guide Rail;;SS41;White Zi No Model Compatibility List $3.35 / Each

P 713449 1000303372 P10 Protect Bushing;-;-;-;BL/Black C;GEQ-262 No Model Compatibility List $1.66 / Each

H 713506 1000304422 H05 Screw;Oval Head;M6x1.0Px16L;;Hex Socket; No Model Compatibility List $1.79 / Each

H 713509 1000304430 H04 ADJ plate;stopper;;SPHC;31x22.3x6;BAN;RB No Model Compatibility List $9.10 / Each

P 714359 1000314036 P20 Adapter;UL;100-240V/50-60Hz;12V/2A;;2.75m cord;2.1mm prong No Model Compatibility List $72.98 / Each

N 716100 1000332709 Not Shown Hardware Set;;;;;RB161;; No Model Compatibility List $37.15 / Each

1
Q 716101 1000332723 Q14 Decal Plate;Side Cover;left;ABS/PA757K;; No Model Compatibility List $9.10 / Each

Q 716102 1000332724 Q15 Decal Plate;Side Cover;right;ABS/PA757K; No Model Compatibility List $8.42 / Each

A 717042 1000341232 AR01 Drive Axle Set;;;;;CB201-1US;; No Model Compatibility List $182.49 / Each

8,10
P 717378 1000344571 P04 Pulse Sensor;;;;;26AWGx10C;350L; No Model Compatibility List $45.97 / Each

H 717401 1000344795 H01 Elliptical Track;;;110.0x60.8x625L;AL 60 No Model Compatibility List $177.42 / Each

H 717403 1000344799 H06 Fixing Rod;Guide Rail2;;SS41;9.0T;BED;RB No Model Compatibility List $17.73 / Each

A 717404 1000344804 AD5 SEAT RACK SET;;;painting;DM334;;RB207; No Model Compatibility List $76.65 / Each

Q 717406 1000344829 Q01 Cover;;left;ABS/PA757;;;PQ-BLACK 7C;RB16 No Model Compatibility List $74.52 / Each

9,4,5,6
V 717407 1000344830 V01 Model Label;Side Cover;;;;Left;;RB161 No Model Compatibility List $1.77 / Each

9
Q 717408 1000344832 Q02 Cover;;right;ABS/PA757;;;PQ-BLACK 7C;RB1 No Model Compatibility List $74.52 / Each

9,4,5,6
V 717409 1000344833 V02 Model Label;Side Cover;;;;Right;;RB161 No Model Compatibility List $1.77 / Each

9
Q 717412 1000344876 Q03 Cover;;mid;ABS/PA757;;;PQ-Black 7C;RB161 No Model Compatibility List $26.81 / Each

Q 717413 1000344878 Q04 Cover;Consoel Mast;front;ABS/PA757;;;PQ- No Model Compatibility List $24.91 / Each

Q 717414 1000344880 Q05 Cover;Consoel Mast;back;ABS/PA757;;;PQ-B No Model Compatibility List $45.97 / Each

Q 717415 1000344881 Q06 Cover;Roller;;ABS/PA757;;;PQ-Black 7C;RB No Model Compatibility List $11.49 / Each

Q 717416 1000344882 Q08 Cover;;down;ABS/PA757;;;PQ-Black 7C;RB16 No Model Compatibility List $12.40 / Each

Q 717417 1000344884 Q09 End Cap;Guide Rail;;ABS/PA757;;;PQ-Black No Model Compatibility List $6.19 / Each

P 717778 1000347511 P03 Console Wire Set;;;;;24AWG;900;Molex7006 No Model Compatibility List $28.73 / Each

H 718276 1000349999 H02 Adjustable Plate;Slippery Base;;POM+20%F No Model Compatibility List $13.39 / Each

D 718659 1000352768 D91 Seat Pad;;Vesicant;;;with CARB decal;RB1 No Model Compatibility List $63.23 / Each

T 719239 1000358248 T05 Bearing;Ball;6005ZZ;?25x?47x12T;TPI;C3 No Model Compatibility List $17.24 / Each

719853 1000366428 AC3 Console Mast Set-Exreawork;;;Screen prin No Model Compatibility List $22.98 / Each

A 719855 1000366438 AC2 grip-Extrawork;;front;Dipping plastic;;R No Model Compatibility List $1.90 / Each

Q 719857 1000366448 Q18 Cover;;back;ABS/PA757;;;RB207;MXR-PQ-BLA No Model Compatibility List $46.12 / Each

D 719859 1000366451 D67 Plastic Cover;;back;ABS/PA757;BL/Black C No Model Compatibility List $6.68 / Each

D 719860 1000366452 D92 Kettle Rack;;;ABS/PA757;BL/Black C;;RB20 No Model Compatibility List $13.39 / Each

T 719904 1000366925 T03 Crank;;L;painting;DM334;;CB204; No Model Compatibility List $54.73 / Each

T 719906 1000366929 T04 Crank;;R;painting;DM334;;CB204; No Model Compatibility List $54.73 / Each

N 719907 1000366961 Not Shown Manual;Assembly/Manipulate;;;;CB204 No Model Compatibility List $35.46 / Each

3
D 720990 1000379350 D80 Quick Key CON Wire;;Left;;;24AWG;750mm;5 No Model Compatibility List $15.31 / Each

D 720991 1000379351 D84 Quick Key CON Wire;;Right;;;24AWG;750mm; No Model Compatibility List $15.31 / Each

A 721103 1000380604 AD01 Guide base set;Semi-Assy;;;;RB207;; No Model Compatibility List $321.96 / Each

3
N 721540 1000383747 Not Shown Manual;Use Manipulate;;English/French/Sp No Model Compatibility List $18.23 / Each

N 721561 1000384190 Not Shown Protect Sleeve;;;PU;;320*240*15;EP701-1U No Model Compatibility List $13.49 / Each

N 721618 1000384759 Not Shown Manual;BK safety direction;;;;CB204 No Model Compatibility List $6.73 / Each

9
P 721904 1000386240 P24 Pulse CON;;;Black;;26AWGx10C;2550L;; No Model Compatibility List $57.49 / Each

A 722629 1000396371 AD07 Handgrip Set;;left;;;;RB208; No Model Compatibility List $47.89 / Each

A 722630 1000396372 AD08 Handgrip Set;;right;;;;RB208; No Model Compatibility List $47.89 / Each

11
S 723697 1000412073 S01 LCB;ECB Small Motor;;HBPB;V2.002;;digita No Model Compatibility List $84.47 / Each

725869 077441 C10 Sticker;Warning;Console set;38x54;EP197 No Model Compatibility List $1.77 / Each

726878 085758 T05 Washer;Lock;10.0x20.0x1.5t;;;; No Model Compatibility List $0.44 / Each

N 729821 ZMS4006122 Not Shown 2016 Matrix Retail Frame Spray Paint (Black) No Model Compatibility List $125.03 / Each

3,4,5,6
A 1000135 1000228989 AT1 1 Bike Pedal Set 9/16" Yes Model Compatibility List $77.99 / Each

R 1000628 004177-A R07 Poly V Drive Belt 8 Ribs Yes Model Compatibility List $39.99 / Each

Q 957398 005330-00 Q10 Gear Rower Retainer Clip (New) Yes Model Compatibility List $11.99 / Each

P 986316 004616-00 P08 Umbrella Cross Tapped Screw 4x12L (New) No Model Compatibility List $12.00 / Each
