Octane Fitness - Pro4700 Standard Base

Repair Parts for Octane Fitness Pro4700 Standard Base

Brand: Octane Fitness

Category: Commercial Ellipticals

Type: Elliptical

Model Name: Pro4700 Standard Base

Color: Grey

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

Search on this page by part name

Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
# 600018 100265-001 ADJUSTABLE ROCKER SCREW, M2 X 0.4 X 10, PAN HEAD, TYPE 1 CROSS RECESSED, CZ No Model Compatibility List $4.68 / Each

2
# 600035 100396-001 CONSOLE MAST GRIP, STATIONARY, DIPPED No Model Compatibility List $3.75 / Each

11
# 600044 100411-001 MAIN FRAME COMPONENTS AXLE, TRANSPORT WHEEL No Model Compatibility List $4.68 / Each

8
# 600045 100414-001 CONSOLE MAST COVER, CONSOLE BACK No Model Compatibility List $11.88 / Each

7,9,4,5,6
# 600047 100416-001 CONSOLE MAST INSERT, BOTTLE HOLDER Yes Model Compatibility List $25.00 / Each

9
# 600049 100429-001 LOWER FRAME COMPONENTS SCREW, M4.8 X 1.6 X 13 TYPE AB, TYPE 1 CROSS RECESS PAN HEAD, ST, BZ No Model Compatibility List $4.68 / Each

2
# 600054 100457-001 #22-ASSY SPACER, FLANGE TENSIONER No Model Compatibility List $4.68 / Each

2,3,4,5,6
# 600057 100464-001 FAN MAGNET, RPM PULLEY No Model Compatibility List $4.68 / Each

8
# 600070 100554-001 LOWER FRAME COMPONENTS SCREW, M5 X 0.8 X 12, PAN HEAD, TYPE 1 CROSS RECESSED, BZ No Model Compatibility List $4.68 / Each

2
# 600074 100602-001 TOUCH SCREEN MAST SCREW, M5 X 0.8 X 10, PAN HEAD, TYPE 1, No Model Compatibility List $4.68 / Each

2
# 600082 100700-001 MAIN FRAME COMPONENTS SCREW, M12x1.75x20L SHCS, STL, BZ No Model Compatibility List $4.68 / Each

2
BOLT, M10 X 1.5 X 55, HEX HEAD, 12.9 STL, CZ 600085 100715-001 BOLT, M10 X 1.5 X 55, HEX HEAD, 12.9 STL, CZ No Model Compatibility List $2.50 / Each

2
BOLT, M10 X 1.5 X 20, HEX HEAD, GR 8.8, CZ 600086 100716-001 BRACED PEDAL LEVER BOLT, M10 X 1.5 X 20, HEX HEAD, GR 8.8, CZ No Model Compatibility List $4.68 / Each

2
# 600109 100760-001 CONSOLE MAST TERMINAL, EYELET TO QUICK DISCONNECT No Model Compatibility List $4.68 / Each

4,5,6
BELT, DRIVE, 10 RIB, 580J 600129 100822-001 BELT, DRIVE, 10 RIB, 580J Yes Model Compatibility List $67.50 / Each

23
# 600130 100828-001 REAR TRACK COVER DUAL LOCK, 20.6MM DIA - 250 No Model Compatibility List $3.75 / Each

1
# 600131 100830-001 LOWER FRAME COMPONENTS BRAKE, GENERATOR, 6302 Yes Model Compatibility List $999.00 / Each

8
# 600158 100882-001 CONSOLE MAST DECAL, LARGE OCTANE No Model Compatibility List $5.00 / Each

7,3
# 600161 100890-001 CONSOLE MAST CABLE ASSEMBLY, FEMALE SPADE - 5MM EYELET No Model Compatibility List $4.68 / Each

3,4,5,6,12,13,14
# 600171 100913-001 FAN SCREW, M3.5 X 1.3 X 10 TYPE B, TYPE 1 CROSS RECESS PAN HEAD, ST, BZ No Model Compatibility List $4.68 / Each

2
# 600179 100924-001 BAGGED HARDWARE WRENCH, HEX, M6 No Model Compatibility List $4.68 / Each

2
# 600211 101013-001 CONSOLE MAST SCREW, M5 X 0.8 X 6, PAN HEAD, TYPE 1 CROSS RECESSED, CZ No Model Compatibility List $4.68 / Each

2
# 600212 101014-001 LOWER FRAME COMPONENTS WASHER, M5, EXTERNAL TOOTH, STEEL, CZ No Model Compatibility List $4.68 / Each

2
# 600216 101028-001 LOWER FRAME COMPONENTS CONNECTOR, PLASTIC, CONTROL BOARD No Model Compatibility List $4.68 / Each

7,9
# 600226 101039-001 CONSOLE MAST DECAL, SMALL OCTANE No Model Compatibility List $3.75 / Each

7,3
# 600228 101041-001 ACCESS PANEL DECAL, MEDIUM OCTANE No Model Compatibility List $7.50 / Each

7,3
# 600261 101245-001 HOOD SHROUD DECAL, 80 DIA BUG No Model Compatibility List $4.38 / Each

7,3
SCREW, M8 X 1.25 X 20.0L SHCS, BLACK ZINC, 12.9 STL 600268 101295-001 #16-ASSY SCREW, M8 X 1.25 X 20.0L SHCS, BLACK ZINC, 12.9 STL No Model Compatibility List $4.68 / Each

2,4,5,6
# 600269 101296-001 #7-ASSEMBLY SCREW, M8 X 1.25 X 45.0L SHCS, BLACK ZIN, 12.9 STL No Model Compatibility List $4.68 / Each

2,4,5,6
# 600271 101298-001 #8-ASSEMBLY SCREW, M5 X 0.8 X 10.0L SHCS, BLACK ZINC, 12.9 STL, SPRING WASHER No Model Compatibility List $4.68 / Each

2,4,5,6
# 600294 101394-001 TOUCH SCREEN MAST TIE, CABLE, W3.6 X L185 No Model Compatibility List $4.68 / Each

2,4,5,6
# 600295 101416-001 LOWER FRAME COMPONENTS CABLE TIE, SCREW MOUNT, M5 No Model Compatibility List $4.68 / Each

2,4,5,6
600296 101436-001 Q47 PULLEY WELDMENT, CRANK SHAFT Yes Model Compatibility List $47.50 / Each

8,3
# 600298 101443-001 MOVING ARM LABEL, LEVEL No Model Compatibility List $4.68 / Each

3
# 600302 101456-001 MAIN FRAME COMPONENTS COVER, PLASTIC BOTTOM No Model Compatibility List $18.75 / Each

9
# 600303 101461-001 LH MOVING ARM LABEL, STRIDE No Model Compatibility List $4.68 / Each

10
# 600307 101561-001 #6-ASSEMBLY BOLT, M10 X 1.5 X 50, HEX HEAD, GR 8.8, CZ No Model Compatibility List $4.68 / Each

2
# 600308 101565-001 RIGHT 3P LINK BUSHING, NUT, SHAFT ACTUATOR, Q47 Yes Model Compatibility List $2.50 / Each

2,8,3,4,5,6
# 600315 101592-001 CONSOLE MAST COUPLER ASSEMBLY, 8 POSITION, IN-LINE No Model Compatibility List $10.00 / Each

3
# 600323 101646-001 ADJUSTABLE ROCKER BEARING, BALL, 6005, C2 No Model Compatibility List $6.88 / Each

8
ASSEMBLY, ACCESS PANEL 600332 101668-001 ASSEMBLY, ACCESS PANEL Yes Model Compatibility List $75.00 / Each

7,3,4,5,6
# 600345 101711-001 RIGHT 3P LINK SWINGARM MOUNTING SLEEVE, ACTUATOR LINK No Model Compatibility List $3.13 / Each

2,3,4,5,6
# 600347 101713-001 RIGHT 3P LINK RETAINING RING, 14MM No Model Compatibility List $4.68 / Each

2
# 600348 101714-001 RIGHT 3P LINK WASHER 14 X 22 X 1.0, STEEL, CZ No Model Compatibility List $4.68 / Each

2
# 600349 101715-001 RIGHT 3P LINK BOLT, M8 X 1.25 X 35 HCS, 8.8 ST, BZ No Model Compatibility List $4.68 / Each

2
# 600350 101718-001 MOVING ARM SPACER, ARM PIVOT TUBE No Model Compatibility List $2.50 / Each

2,8,3,4,5,6
WASHER, 10 X 30 X 2, STEEL, CZ 600352 101720-001 #10-ASSY WASHER, 10 X 30 X 2, STEEL, CZ No Model Compatibility List $4.68 / Each

2
# 600365 101772-001 RIGHT 3P LINK B18.3.1M, M5 X 0.8 X 35.0L SHCS, BLACK ZINC, STL No Model Compatibility List $4.68 / Each

4,5,6
SCREW, M5 X 0.8 X 16.0L SHCS, SS, FLAT WASHER 600382 101821-001 SCREW, M5 X 0.8 X 16.0L SHCS, SS, FLAT WASHER No Model Compatibility List $4.68 / Each

2
# 600385 101845-001 MAIN FRAME COMPONENTS GROMMET, 24 X 31.5 No Model Compatibility List $4.38 / Each

2
# 600388 101861-001 MAIN FRAME COMPONENTS BOLT, 10MM J-HOOK No Model Compatibility List $5.00 / Each

2
# 600389 101862-001 #11-ASSEMBLY SCREW, M8 X 1.25 X 16.0L SHCS, BLACK ZINC, 12.9 STL No Model Compatibility List $4.68 / Each

2,4,5,6
600390 101863-001 #1-ASSY SHROUD, RIGHT Yes Model Compatibility List $130.00 / Each

7,9,12,13,14
# 600391 101864-001 #1-ASSY SHROUD, LEFT Yes Model Compatibility List $132.50 / Each

7,9,12,13,14
# 600392 101865-001 TOP SHROUD CLASSIC SHROUD, TOP No Model Compatibility List $65.00 / Each

7,9,12,13,14
# 600393 101866-001 TOP SHROUD SHROUD, FRONT No Model Compatibility List $65.00 / Each

7,9,12,13,14
600396 101870-001 COVER, MAST BOOT Yes Model Compatibility List $27.50 / Each

9,3
600398 101878-001 MOVING ARM CONTACT, SS, BACK W/ ADHESIVE Yes Model Compatibility List $25.00 / Each

4,5,6
600399 101879-001 MOVING ARM CONTACT, SS, FRONT W/ ADHESIVE Yes Model Compatibility List $30.00 / Each

4,5,6
# 600400 101881-001 MOVING ARM SCREW, M3 X 0.5 X 16 BHCS, SS No Model Compatibility List $4.68 / Each

2
# 600410 101920-001 MAIN FRAME COMPONENTS WASHER, WAVE, 16.7 X 22.5 X .3 No Model Compatibility List $4.68 / Each

2,4,5,6
# 600416 101933-001 CONSOLE MAST CABLE ASSEMBLY, MAST, HR, PRO3700(XL) Yes Model Compatibility List $13.75 / Each

7,3,4,5,6,12,13,14
# 600418 101935-001 RH MOVING ARM CABLE ASSEMBLY, HR-GRIPS Yes Model Compatibility List $10.00 / Each

7,3,4,5,6,12,13,14,11
# 600420 101939-001 BRACED PEDAL LEVER PEDAL, SOFT DESIGN, PLASTIC No Model Compatibility List $37.50 / Each

8,9
# 600421 101940-001 BRACED PEDAL LEVER PEDAL INSERT Yes Model Compatibility List $30.00 / Each

8,9
600428 101979-001 COVER, HANDLE BAR, NO DUAL LOCK Yes Model Compatibility List $5.63 / Each

9,11
# 600430 101982-001 MAIN FRAME COMPONENTS WHEEL, TRANSPORT, 80MM, RIB No Model Compatibility List $3.75 / Each

8
# 600431 101986-001 RIGHT 3P LINK CABLE ASSEMBLY, LIMIT SWITCH Yes Model Compatibility List $16.25 / Each

1
# 600439 102020-001 MOVING ARM KEYPAD, MOVING HANDLEBAR, Q47 No Model Compatibility List $10.63 / Each

9,12,13,14,11
# 600440 102021-001 MOVING ARM PLATE, KEYPAD BACKER No Model Compatibility List $4.68 / Each

9,3,4,5,6,12,13,14
600441 102022-001 MOVING ARM CAP, MOVING HB BUTTONS, FRONT Yes Model Compatibility List $4.38 / Each

9
600442 102023-001 MOVING ARM CAP, MOVING HB BUTTONS, BACK Yes Model Compatibility List $4.38 / Each

9,4,5,6
# 600443 102024-001 MOVING ARM CLIP, GROUNDING, MOVING HANDLEBAR No Model Compatibility List $4.68 / Each

2,11
# 600444 102025-001 MOVING ARM BUTTON, MOVING HANDLEBAR No Model Compatibility List $3.13 / Each

11
600447 102042-001 WELDMENT, OFFSET CRANK, PRO Yes Model Compatibility List $92.50 / Each

8,3
WELDMENT, RIGHT CRANK ARM 600448 102047-001 WELDMENT, RIGHT CRANK ARM Yes Model Compatibility List $67.50 / Each

8,3
600449 102048-001 WELDMENT, LEFT CRANK ARM Yes Model Compatibility List $67.50 / Each

8,3
# 600450 102071-001 REAR TRACK COVER COVER, REAR TRACK Yes Model Compatibility List $23.75 / Each

9,15,3,4,5,6
COLLAR, LOCKING, SET SCREW, 25MM 600451 102074-001 COLLAR, LOCKING, SET SCREW, 25MM No Model Compatibility List $4.68 / Each

2
# 600452 102076-001 MAIN FRAME COMPONENTS CABLE, CO-AXIAL, BASE No Model Compatibility List $25.00 / Each

3,4,5,6
# 600459 102134-001 #35-ASSY SCREW, M5 X 0.8 X 18, PAN HEAD, TYPE 1 CROSS RECESSED, SS No Model Compatibility List $4.68 / Each

2
# 600460 102135-001 REAR STABILIZER SCREW, M5 X 0.8 X 10, PAN HEAD, TYPE 1 CROSS RECESSED, SS No Model Compatibility List $4.68 / Each

2
# 600492 102304-001 LOWER FRAME COMPONENTS SCREW, M5 X 0.8 X 12, PAN HEAD, TYPE 1, CROSS RECESSED, BZ, FLAT WASHER No Model Compatibility List $4.68 / Each

2
# 600494 102306-001 PRO310 SCREW, M5 X 0.8 X 18, PAN HEAD, TYPE 1, CROSS RECESSED, BZ, FLAT WASHER No Model Compatibility List $4.68 / Each

2
# 600495 102312-001 RIGHT 3P LINK ASSEMBLY, ACTUATOR SWINGARM Yes Model Compatibility List $35.00 / Each

3,4,5,6
# 600496 102316-001 ADJUSTABLE ROCKER TIE, CABLE, W3.6 X L310 No Model Compatibility List $4.68 / Each

2,4,5,6
# 600513 102453-001 #3-ASSY BOLT, M8 X 1.25 X 20, HEX HEAD, GR 8.8, CZ No Model Compatibility List $5.63 / Each

2
# 600514 102454-001 LOWER FRAME COMPONENTS WASHER, 8 X 24 X 2, STEEL, CZ No Model Compatibility List $4.68 / Each

2
SHAFT, ROCKER 600517 102498-001 SHAFT, ROCKER No Model Compatibility List $10.63 / Each

3
600518 102505-001 CONSOLE MAST CABLE ASSEMBLY, CSAFE Yes Model Compatibility List $11.25 / Each

3,4,5,6
# 600520 102513-001 3700 IFI MAST CABLE ASSEMBLY, MAST, HB BUTTONS Yes Model Compatibility List $13.75 / Each

3,4,5,6
ASSEMBLY, MULTI-AXIS BEARING LINK, PLAST 600538 102710-001 ASSEMBLY, MULTI-AXIS BEARING LINK, PLAST Yes Model Compatibility List $195.00 / Each

8,3
ASSEMBLY, TRACK COVER, OUTSIDE, LH 600555 102777-001 ASSEMBLY, TRACK COVER, OUTSIDE, LH No Model Compatibility List $65.00 / Each

9,15,3,4,5,6
ASSEMBLY, TRACK COVER, OUTSIDE, RH 600556 102778-001 ASSEMBLY, TRACK COVER, OUTSIDE, RH No Model Compatibility List $65.00 / Each

9,15,3,4,5,6
# 600563 102856-001 RH MOVING ARM CABLE ASSEMBLY, MOVING HANDLE BAR CONTROLS Yes Model Compatibility List $15.00 / Each

7,3,4,5,6,11
# 600564 102857-001 RH MOVING ARM SCREW, M2.5 X 0.45 X 8 SHCS, SS No Model Compatibility List $4.68 / Each

2
# 600567 102875-001 CONSOLE MAST SCREW, M5 X 0.8 X 12, PAN HEAD, TYPE 1 CROSS RECESSED, SS, SPRING WSHR-FLAT WSHR No Model Compatibility List $4.68 / Each

7,2,12,13,14
# 600568 102892-001 LOWER FRAME COMPONENTS STAND-OFF, CABLE, 14 DIA No Model Compatibility List $4.68 / Each

2,4,5,6
ASSEMBLY, REAR TRACK COVER 600575 102916-001 ASSEMBLY, REAR TRACK COVER No Model Compatibility List $38.50 / Each

9,15,3,4,5,6
ASSEMBLY, MAIN FRAME COMPONENTS 600577 102935-001 ASSEMBLY, MAIN FRAME COMPONENTS No Model Compatibility List $0.00 / Each
Out Of Stock 		3
ASSEMBLY, CONSOLE MAST, PRO4700 600578 102941-001 ASSEMBLY, CONSOLE MAST, PRO4700 No Model Compatibility List $537.50 / Each

7,3
# 600579 102956-001 LINK ASSEMBLY, STABILITY LINK, BEARINGS Yes Model Compatibility List $0.00 / Each
8,3
# 600622 103171-001 ADJUSTABLE ROCKER ACTUATOR NUT, 3G, DELRIN No Model Compatibility List $8.13 / Each

2,4,5,6
# 600669 103393-001 #23-ASSEMBLY NUT, HEX, NYLON INSERT, M8 X 1.25, CZ CLASS 10 No Model Compatibility List $4.68 / Each

2
NUT, HEX, NYLON INSERT, M10 X 1.5, CZ CLASS 10 600670 103395-001 #6-ASSY NUT, HEX, NYLON INSERT, M10 X 1.5, CZ CLASS 10 No Model Compatibility List $4.68 / Each

2
# 600675 103428-001 LOWER FRAME COMPONENTS INSULATOR, BRAKE BASE No Model Compatibility List $3.75 / Each

8,3
# 600678 103435-001 RIGHT 3P LINK ASSEMBLY, ACUTATOR LINK WITH BUSHINGS Yes Model Compatibility List $152.50 / Each

8,3,4,5,6
# 600679 103440-001 RIGHT 3P LINK ACTUATOR MOTOR MOUNTING SLEEVE, 3P No Model Compatibility List $3.13 / Each

2,3,4,5,6,10
# 600680 103441-001 RIGHT 3P LINK O-RING, 8 X 13 X 2.5 No Model Compatibility List $4.68 / Each

2
# 600681 103442-001 RIGHT 3P LINK O-RING, 24 X 29 X 2.5 No Model Compatibility List $4.68 / Each

2
ASSEMBLY, TRACK COVER, CENTER 600682 103455-001 ASSEMBLY, TRACK COVER, CENTER No Model Compatibility List $55.00 / Each

9,15,3,4,5,6
SCREW, M10 X 1.5 X 45L BHCS, BLACK ZINC, 10.9 STL 600683 103459-001 SCREW, M10 X 1.5 X 45L BHCS, BLACK ZINC, 10.9 STL No Model Compatibility List $4.68 / Each

2,4,5,6
# 600685 103461-001 MAIN FRAME COMPONENTS BRACKET, BATTERY RETAINER No Model Compatibility List $7.50 / Each

2,3,4,5,6
# 600686 103488-001 MAIN FRAME COMPONENTS ASSEMBLY, LOWER REAR SHROUD No Model Compatibility List $52.50 / Each

7,9,3,12,13,14
# 600698 103531-001 MAIN FRAME COMPONENTS ASSEMBLY, TENSIONER, INSULATED Yes Model Compatibility List $52.50 / Each

3
# 600699 103533-001 #16-ASSEMBLY INSULATOR, J-HOOK BOLT No Model Compatibility List $3.75 / Each

2,3
# 600700 103534-001 LOWER FRAME COMPONENTS INSULATOR, BRAKE BOLT No Model Compatibility List $4.68 / Each

2,8,3
# 600703 103540-001 LOWER FRAME COMPONENTS BOLT, M6 X 1.0 X 25, HEX HEAD, GR 8.8, CZ No Model Compatibility List $4.68 / Each

2
# 600726 103672-001 LOWER FRAME COMPONENTS CABLE ASSEMBLY, BASE Yes Model Compatibility List $16.25 / Each

3,4,5,6
# 600727 103673-001 MAIN FRAME COMPONENTS CABLE ASSEMBLY, BASE C-SAFE Yes Model Compatibility List $22.50 / Each

3,4,5,6
# 600734 103686-001 4700 TOP SHROUD LABEL, FRONT SHROUD No Model Compatibility List $32.50 / Each

7,9,12,13,14
# 600751 103739-001 LOWER FRAME COMPONENTS CIRCUIT BOARD ASSEMBLY, PRO 4700 POWER AND CONTROL BOARD No Model Compatibility List $399.00 / Each

3,4,5,6,7
600754 103750-001 LOWER FRAME COMPONENTS ASSEMBLY, BATTERY PACK Yes Model Compatibility List $447.50 / Each

3,4,5,6
# 600763 103842-001 BRACED PEDAL LEVER LABEL, PEDAL, LEFT No Model Compatibility List $7.50 / Each

8,9
# 600764 103843-001 BRACED PEDAL LEVER LABEL, PEDAL, RIGHT No Model Compatibility List $7.50 / Each

8,9
# 600771 103914-001 LOWER FRAME COMPONENTS CABLE ASSEMBLY, GENERATOR BRAKE POWER No Model Compatibility List $4.38 / Each

8,3,4,5,6
# 600772 103915-001 MAIN FRAME COMPONENTS CABLE ASSEMBLY, GENERATOR BRAKE INDUCTOR No Model Compatibility List $3.13 / Each

8,3,4,5,6
CABLE ASSEMBLY, ACTUATOR, PRO4700 600795 104046-001 CABLE ASSEMBLY, ACTUATOR, PRO4700 Yes Model Compatibility List $30.00 / Each

3,4,5,6
# 600833 104247-001 PEDAL LEVER ASSY, ROUNDED ROLLER Yes Model Compatibility List $87.50 / Each

8,3
# 600892 104583-001 MAIN FRAME COMPONENTS COVER, LOWER BOARD No Model Compatibility List $37.50 / Each

9
# 600895 104638-001 CONSOLE MAST SCREW, M5 X 0.8 X 6, PAN HEAD, TYPE 1 CROSS RECESSED, BZ No Model Compatibility List $4.68 / Each

2
# 600898 104647-001 RIGHT 3P LINK ACTUATOR, T-MOTION MOTOR, 750N, RoHS Yes Model Compatibility List $257.50 / Each

4,5,6,10
600929 104956-001 ASSY, Q47 PULLEY, ROHS Yes Model Compatibility List $120.00 / Each

8,3
# 600941 105030-001 CAST 3P LINK WASHER, WAVE, 19.3 X 26.0 X 1.4 No Model Compatibility List $6.50 / Each

2,4,5,6
# 600942 105036-001 CAST 3P LINK WASHER, 10.5 X 26 X .5, SNAP FIT No Model Compatibility List $4.68 / Each

2
# 600943 105037-001 CAST 3P LINK SLEEVE, LINKAGE No Model Compatibility List $11.25 / Each

3
600945 105039-001 CAST 3P LINK AXLE, SHOULDERED Yes Model Compatibility List $11.25 / Each

8
# 600951 105102-001 MAIN FRAME COMPONENTS SCREW, M4 X 0.7 X 16, PAN HEAD, TYPE 1 CROSS RECESSED, SS No Model Compatibility List $4.68 / Each

2
ASSEMBLY, LINK, STABILIZER 600966 105159-001 ASSEMBLY, LINK, STABILIZER Yes Model Compatibility List $75.00 / Each

3
ASSEMBLY, RIGHT 3P LINK 600967 105160-001 ASSEMBLY, RIGHT 3P LINK Yes Model Compatibility List $575.00 / Each

3
ASSEMBLY, LEFT 3P LINK 600968 105161-001 ASSEMBLY, LEFT 3P LINK Yes Model Compatibility List $575.00 / Each

3
WLDMT, RIGHT COMM ROCKER 600975 105197-001 WLDMT, RIGHT COMM ROCKER No Model Compatibility List $90.00 / Each

3
WLDMT, LEFT COMM ROCKER 600976 105199-001 WLDMT, LEFT COMM ROCKER No Model Compatibility List $90.00 / Each

3
600992 105605-001 #5-ASSEMBLY KIT BAR, ARM, M10 HOLES Yes Model Compatibility List $9.38 / Each

3
# 600993 105606-001 #4-ASSEMBLY KIT BOLT, M10 X 1.5 X 65, HEX HEAD, GR 8.8, CZ No Model Compatibility List $3.13 / Each

2
# 600994 105608-001 MAIN FRAME COMPONENTS CABLE ASSY, BASE, HB BUTTONS, LONG Yes Model Compatibility List $18.75 / Each

3,4,5,6
# 600995 105609-001 MAIN FRAME COMPONENTS CABLE ASSY, BASE, MOVING HR, LONG Yes Model Compatibility List $21.25 / Each

7,3,4,5,6,12,13,14
601029 105938-001 MAIN FRAME COMPONENTS CABLE ASSEMBLY, PAC BOARD TO CONTROL BOARD Yes Model Compatibility List $9.38 / Each

7,3,4,5,6
CABLE, CO-AXIAL, MAST 601045 106102-001 CONSOLE MAST CABLE, CO-AXIAL, MAST Yes Model Compatibility List $23.75 / Each

4,5,6
CABLE ASSEMBLY, LAN 601061 106182-001 CONSOLE MAST CABLE ASSEMBLY, LAN Yes Model Compatibility List $20.00 / Each

3,4,5,6
ASSEMBLY KIT, BASE HARDWARE 601071 106216-001 ASSEMBLY KIT, BASE HARDWARE No Model Compatibility List $32.50 / Each

3
# 601081 106358-001 BRACED PEDAL LEVER PEDAL INSERT, REAR No Model Compatibility List $2.50 / Each

8,9
ASSY, RH MOVING ARM, 3700/4700 601091 106485-001 ASSY, RH MOVING ARM, 3700/4700 Yes Model Compatibility List $282.50 / Each

3
601092 106489-001 ASSY, LH MOVING ARM, 4700 No Model Compatibility List $282.50 / Each

3
# 601110 106604-001 MULTI-AXIS LINK BEARING, BALL, 6000, C0 No Model Compatibility List $5.00 / Each

8
ASSY, RH STANDING SHROUD 601174 106935-001 ASSY, RH STANDING SHROUD Yes Model Compatibility List $130.00 / Each

7,9,3,12,13,14
ASSY, LH STANDING SHROUD 601175 106936-001 ASSY, LH STANDING SHROUD Yes Model Compatibility List $130.00 / Each

7,9,3,12,13,14
ASSY, 4700 TOP SHROUD 601176 106941-001 ASSY, 4700 TOP SHROUD No Model Compatibility List $190.00 / Each

7,9,3,12,13,14
# 601184 106983-001 CONSOLE MAST MOUNT, CABLE TIE, SCREW MOUNT No Model Compatibility List $4.68 / Each

2,4,5,6
# 601193 107021-001 CONSOLE MAST CABLE ASSEMBLY, MAST, PRO4700 Yes Model Compatibility List $27.50 / Each

3,4,5,6
# 601220 107249-001 MAIN FRAME COMPONENTS ASSEMBLY, ROUNDED TRACK, LEFT, RoHS No Model Compatibility List $300.00 / Each

15,3,4,5,6
# 601221 107250-001 MAIN FRAME COMPONENTS ASSEMBLY, ROUNDED TRACK, RIGHT, RoHS No Model Compatibility List $300.00 / Each

15,3,4,5,6
601269 107670-001 BRACED PEDAL LEVER WLDMT, BRACED PEDAL LEVER, PRO Yes Model Compatibility List $499.00 / Each

8,9,3,4,5,6
ASSY, BRACED PEDAL LEVER, 4700 601271 107673-001 ASSY, BRACED PEDAL LEVER, 4700 No Model Compatibility List $582.50 / Each

8,9,3,4,5,6
# 601275 107721-001 MAIN FRAME COMPONENTS PAC BOARD, 4700 PLASTIC DRIP GUARD No Model Compatibility List $9.38 / Each

9,3,4,5,6
# 601279 107762-001 MAIN FRAME COMPONENTS CLIP, PUSH CONNECTOR, 4.5mm HOLE No Model Compatibility List $4.68 / Each

2
# 601298 107836-001 MULTI-AXIS LINK SCREW, M6 X 1.0 X 18, SHCS, LOCK WSH, BZ No Model Compatibility List $2.50 / Each

2
# 601876 110963-001 MAIN FRAME COMPONENTS ASSEMBLY, SHROUD, UPPER REAR No Model Compatibility List $40.00 / Each

7,9,3,12,13,14
RING, RETAINING, 25MM 602215 900009-001 #3-ASSEMBLY RING, RETAINING, 25MM No Model Compatibility List $4.68 / Each

2
602219 900015-001 LOWER FRAME COMPONENTS LEVELER, 50MM DIAMETER Yes Model Compatibility List $14.99 / Each

1,13
# 602222 900031-002 LOWER FRAME COMPONENTS NUT, HEX BLIND INSERT, M5 X 0.8 No Model Compatibility List $4.68 / Each

2
# 602226 950005-009 #11-ASSEMBLY B18.3.1M, M5 X .8 X 20.0L SHCS, BLACK ZINC, STL No Model Compatibility List $4.68 / Each

4,5,6
# 602229 950006-010 MAIN PULLEY B18.3.1M, M6 X 1.0 X 25.0L SHCS, BLACK ZINC, STL No Model Compatibility List $4.68 / Each

4,5,6
# 602242 950038-009 LOWER FRAME COMPONENTS B18.2.4.1M, HEX NUT, STYLE 1, M10 X 1.5, BLACK ZINC, STL No Model Compatibility List $4.68 / Each

2,4,5,6
# 602243 950042-007 LOWER FRAME COMPONENTS B18.22M, WASHER, PLAIN, STL, M6 No Model Compatibility List $4.68 / Each

2
# 602244 950042-008 MULTI-AXIS LINK B18.22M, WASHER, PLAIN, STL, M8 No Model Compatibility List $4.68 / Each

2
# 602245 950042-009 #5-HARDWARE KIT B18.22M, WASHER, PLAIN, STL, M10 No Model Compatibility List $4.68 / Each

2
# 602246 950042-010 MAIN FRAME COMPONENTS B18.22M, WASHER, PLAIN, STL, M12 No Model Compatibility List $4.68 / Each

2
# 602247 950046-006 LATX TOUCH LOWER FRAME NUT, HEX, NYLON INSERT, STL, M5 No Model Compatibility List $4.68 / Each

2
# 602248 950046-007 LOWER FRAME COMPONENTS NUT, HEX, NYLON INSERT, STL, M6 No Model Compatibility List $4.68 / Each

2
602249 950046-008 REPLACED BY: 103393-001 ADJUSTABLE ROCKER NUT, HEX, NYLON INSERT, STL, M8 No Model Compatibility List $4.68 / Each

602250 950046-009 REPLACED BY: 103395-001 MULTI-AXIS LINK NUT, HEX, NYLON INSERT, STL, M10 No Model Compatibility List $4.68 / Each

# 602252 950052-006 #12-ASSEMBLY B18.21.2M, WASHER, LOCK, STL, M5 No Model Compatibility List $4.68 / Each

2
# 602254 950052-008 #17-ASSY B18.21.2M, WASHER, LOCK, STL, M8 No Model Compatibility List $4.68 / Each

2
# 602255 950052-009 #3-ASSEMBLY KIT B18.21.2M, WASHER, LOCK, STL, M10 No Model Compatibility List $4.68 / Each

2
# 602256 950052-010 MAIN FRAME COMPONENTS B18.21.2M, WASHER, LOCK, STL, M12 No Model Compatibility List $4.68 / Each

2
Octane Fitness Brake Control Board 1013119 103087-001 1 Octane Fitness Brake Control Board Yes Model Compatibility List $199.00 / Each
7
PLATE, PULLEY WASHER 1013287 100463-001 # 1 PLATE, PULLEY WASHER No Model Compatibility List $11.99 / Each

3
ASSEMBLY, KEYPAD, PRO4700 000186 102943-001 # 1 ASSEMBLY, KEYPAD, PRO4700 Yes Model Compatibility List $399.00 / Each

1
BASE CLEVIS, ACTUATOR LINK, CABLE ROUTE 1013223 102881-001 # 1 BASE CLEVIS, ACTUATOR LINK, CABLE ROUTE Yes Model Compatibility List $29.99 / Each

8
WELDMENT, ACTUATOR, CABLE ROUTE 1013224 102882-001 # 1 WELDMENT, ACTUATOR, CABLE ROUTE Yes Model Compatibility List $29.99 / Each

8
Pulley Poly V (Used) 1013288 103638-001 # 1 Pulley Poly V (Used) No Model Compatibility List $38.99 / Each

8
ACCESSORY TRAY 000187 108393-001 # 1 ACCESSORY TRAY Yes Model Compatibility List $29.99 / Each

1
Heart Rate Pulse (used) 1013337 Octplsboard # 1 Heart Rate Pulse (used) No Model Compatibility List $48.59 / Each

7
# 1001077 900015-001 #2-ASSEMBLY, MAIN FRAME COMPONENTS Adjustment Foot Leveler Yes Model Compatibility List $17.99 / Each

1,13
4 Pin Interconnect Wire Harness (Used) 1039360 inter-wir-60 4 Pin Interconnect Wire Harness (Used) Yes Model Compatibility List $5.00 / Each

4
4 Pin Wire Harness Console Cable (Used) 1039359 consl-wir-59 4 Pin Wire Harness Console Cable (Used) Yes Model Compatibility List $6.00 / Each

4,5
Cable Wire Harness (Used) 1039355 cble-355 Cable Wire Harness (Used) Yes Model Compatibility List $15.00 / Each

4,5
Display Console Fan (Used) 1039365 fan-365 Display Console Fan (Used) Yes Model Compatibility List $10.00 / Each

1
Wire Harness (Used) 1039349 349-wire Wire Harness (Used) Yes Model Compatibility List $5.00 / Each

4
View Drawing

general Info

Customer Service

About us

Address

6114 Madison Ct.
Morton Grove, IL 60053
847-309-2818

Hydra Fitness Exchange © 2025. All Rights Reserved.

Payment options
