ProForm - CROSSWALK 400E

Exploded Diagrams

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

Search on this page by part name

Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
3/8 103764 104478 6 3/8" FLAT WASHER No Model Compatibility List $1.32 / Each

2
MOTOR PIVOT BOLT 118371 104925 3/8 -16 X 4.5 19 MOTOR PIVOT BOLT No Model Compatibility List $5.91 / Each

2,8
ROLLER MAGNET 100081 113842 18 ROLLER MAGNET Yes Model Compatibility List $1.10 / Each

8,1
4 102281 114011 # 4 Yes Model Compatibility List $4.87 / Each

1,4
4 102280 114012 # 4 Yes Model Compatibility List $2.74 / Each

4,5,6
RELEASABLE WIRE TIE 100064 116926 87 RELEASABLE WIRE TIE No Model Compatibility List $0.25 / Each

1,4,2
TIE CLAMP HOLDER - SCREW MOUNT 100262 116927 89 TIE CLAMP HOLDER - SCREW MOUNT No Model Compatibility List $2.49 / Each

1
SCREW,Hex,3/8-16X.75 113294 117332 4 SCREW,Hex,3/8-16X.75" No Model Compatibility List $2.02 / Each

2
40MM X 50MM INT ENDCAP 106302 117544 65 40MM X 50MM INT ENDCAP Yes Model Compatibility List $3.12 / Each

1
3/8 100031 119425 . 3/8" HEX JAM NUT Yes Model Compatibility List $0.55 / Each

2
104328 119994 14 FRAME PIVOT BOLT No Model Compatibility List $2.28 / Each

2,8,3
SEAT RAIL FLANGE NUT 104004 120867 28 SEAT RAIL FLANGE NUT No Model Compatibility List $3.75 / Each

1
U-NUT 100462 012179 99 U-NUT No Model Compatibility List $4.42 / Each

100088 123945 # TECH SHEET ENVELOPE No Model Compatibility List $0.94 / Each

1
117938 124614 32 REAR PLATFORM BOLT No Model Compatibility List $2.55 / Each

2
4 100112 126146 # 4" BLU WIRE F/F, DR MOTOR Yes Model Compatibility List $2.43 / Each

4,5,6
104109 126970 . RESISTOR BOX SCREW No Model Compatibility List $1.82 / Each

2
3/16-7/32 100190 128457 . 3/16-7/32" ALLEN WRENCH No Model Compatibility List $18.74 / Each

1
ROUND GROMMET 101035 129004 70 ROUND GROMMET No Model Compatibility List $1.44 / Each

1
RSW CLAMP 100079 131090 91 RSW CLAMP Yes Model Compatibility List $0.46 / Each

4,5,6,2,1,47
WIRE TIE 100073 132315 49 WIRE TIE No Model Compatibility List $0.56 / Each

2,4,5,6,1
#8 X 3/4 100149 013300 35A #8 X 3/4" WASHER HD SCREW Yes Model Compatibility List $1.28 / Each

HOOD SCREW 100354 013316 73 HOOD SCREW No Model Compatibility List $1.42 / Each

#8 HOOD CLIP 100032 133333 22 #8 HOOD CLIP Yes Model Compatibility List $0.65 / Each

2,9,1,46
UPRIGHT BOLT 102932 013438 102 UPRIGHT BOLT Yes Model Compatibility List $2.11 / Each

3/8 100017 013544 . 3/8" BOLT No Model Compatibility List $2.87 / Each

PLATFORM NUT 100252 136012 67 PLATFORM NUT No Model Compatibility List $1.47 / Each

1
#8 X 3/4 100132 013607 115 #8 X 3/4" TRUSS HEAD SCRW Yes Model Compatibility List $0.22 / Each

#8 X 1/2 100137 136728 83 #8 X 1/2" SCREW Yes Model Compatibility List $0.30 / Each

2
HANDRAIL COVER FASTENER 100290 138853 84 HANDRAIL COVER FASTENER No Model Compatibility List $1.55 / Each

1,40
1/4 100042 014063 . 1/4" FLAT WASHER No Model Compatibility List $1.03 / Each

5/16 100472 014073 116 5/16" WASHER Yes Model Compatibility List $1.25 / Each

3/8 102446 014117 . 3/8" CONSOLE SUPPORT No Model Compatibility List $1.32 / Each

5/16" STAR WASHER 100449 014149 . 5/16" STAR WASHER Yes Model Compatibility List $0.20 / Each

100264 146427 . 1" TEK SCREW No Model Compatibility List $0.28 / Each

2
5/16 101663 150699 . 5/16" X 2 1/2" SCREW Yes Model Compatibility List $7.15 / Each

2
106734 155153 101 #10 X 3/4" SCREW No Model Compatibility List $0.40 / Each

2
BASE PAD 100076 157600 . BASE PAD Yes Model Compatibility List $1.33 / Each

3,12,13,14,46,1
8 100063 016057 68 8" CABLE TIE No Model Compatibility List $1.30 / Each

IDLER WHEEL BOLT 100229 162866 15 IDLER WHEEL BOLT Yes Model Compatibility List $5.49 / Each

2,8
117947 169460 12 LIFT FRAME SPACER No Model Compatibility List $2.49 / Each

2,3,4,5,6,10
3/8 100135 174320 53 3/8"-16X1 1/2" HEX BOLT Yes Model Compatibility List $2.29 / Each

2,41
103169 183824 . ELECTRONICS SCREW No Model Compatibility List $0.19 / Each

2
POWER SWITCH 100201 186726 # POWER SWITCH Yes Model Compatibility List $16.42 / Each

6
#8 X 1/2 100120 186819 114 #8 X 1/2" SCREW Yes Model Compatibility List $0.42 / Each

2
156662 189608 103 MOTOR MOUNT BRACKET No Model Compatibility List $10.81 / Each

2,3,4,5,6
100444 189861 41 REAR ROLLER STAR WASHER No Model Compatibility List $1.00 / Each

2,8
113323 194526 # CONTROLLER GROUND WIRE No Model Compatibility List $2.33 / Each

7,8,4,5,6
BELT GUIDE 100040 198640 82 BELT GUIDE Yes Model Compatibility List $18.62 / Each

15,40
WHEEL 100034 199545 . WHEEL Yes Model Compatibility List $4.12 / Each

8,45
100344 200747 40 GROUND WIRE No Model Compatibility List $2.56 / Each

4,5,6
LOWER HANDRAIL ENDCAP 119371 201469 16 LOWER HANDRAIL ENDCAP Yes Model Compatibility List $5.17 / Each

3,4,5,6,9
5/16 101667 203283 . 5/16"X 2" BTN SCRW, NOTE: Yes Model Compatibility List $2.07 / Each

1,2
FOOT 101638 204005 61 FOOT Yes Model Compatibility List $4.09 / Each
9
KEY/CLIP 100072 208603 . KEY/CLIP Yes Model Compatibility List $17.99 / Each

1
UPRIGHT WIRE 118380 209631 42 UPRIGHT WIRE Yes Model Compatibility List $48.26 / Each

3,4,5,6
POWER CORD ASSEMBLY 119387 214217 79 POWER CORD ASSEMBLY Yes Model Compatibility List $47.93 / Each

4,5,6
MOTOR BOLT 111182 215360 20 MOTOR BOLT Yes Model Compatibility List $3.28 / Each

2
FRONT ROLLER/PULLEY 119351 219035 17 FRONT ROLLER/PULLEY Yes Model Compatibility List $109.54 / Each
1
118379 221619 . RIGHT GRIP PLATE Yes Model Compatibility List $7.99 / Each

11
118377 221620 . LEFT GRIP PLATE Yes Model Compatibility List $4.80 / Each

11
LEFT REAR ENDCAP 117940 222507 31 LEFT REAR ENDCAP Yes Model Compatibility List $10.22 / Each

9,4,5,6
RIGHT REAR ENDCAP 117941 222508 78 RIGHT REAR ENDCAP Yes Model Compatibility List $10.22 / Each

9,4,5,6
LATCH 102233 223504 30 LATCH Yes Model Compatibility List $3.36 / Each

1
INCLINE/CONTROLLER WIRE 102354 223520 56 INCLINE/CONTROLLER WIRE Yes Model Compatibility List $9.35 / Each

4,5,6,7,8,10
EXTENSION LEG NUT 102261 223547 . EXTENSION LEG NUT Yes Model Compatibility List $3.06 / Each
Out Of Stock
2
MOTOR BELT 104319 224019 3 MOTOR BELT Yes Model Compatibility List $21.99 / Each

23
142283 226876 71 LEFT HANDRAIL No Model Compatibility List $30.34 / Each

9,3
142284 226878 72 RIGHT HANDRAIL No Model Compatibility List $30.34 / Each
Out Of Stock
9,3
REAR ROLLER PLATE 119354 226904 44 REAR ROLLER PLATE Yes Model Compatibility List $2.79 / Each

8
HAND GRIP 113316 226956 76 HAND GRIP Sub Assembly Yes Model Compatibility List $6.85 / Each

11,1
161739 226966 # DECAL, ARM, CROSSWALK No Model Compatibility List $2.22 / Each

7,3
142290 227051 # HARDWARE KIT No Model Compatibility List $48.43 / Each

1
UPPER BODY ARM INSERT 113319 227163 21 UPPER BODY ARM INSERT Part # 85 on diagram No Model Compatibility List $5.48 / Each

3,1
LATCH INSERT 117358 228101 . LATCH INSERT Yes Model Compatibility List $9.93 / Each

1
142287 228758 # TECH SHEET No Model Compatibility List $0.87 / Each

1
LATCH PIN ASSEMBLY 142285 229536 . LATCH PIN ASSEMBLY Yes Model Compatibility List $13.64 / Each

12,13,14
REAR ROLLER 119355 235715 100 REAR ROLLER Yes Model Compatibility List $118.71 / Each
Out Of Stock
8
161746 235833 # LITERATURE PACKET No Model Compatibility List $86.36 / Each

4,5,6
161745 235834 . USER-S MANUAL No Model Compatibility List $5.55 / Each

1
142281 236008 25 RT UPPER BODY ARM W/GRIP No Model Compatibility List $99.42 / Each

3,11
142280 236652 1 HOOD No Model Compatibility List $72.27 / Each
Out Of Stock
9
142282 237848 69 UPRIGHT BASE No Model Compatibility List $203.54 / Each

3
100185 240351 # ANCHORED CABLE TIE No Model Compatibility List $0.74 / Each

2,4,5,6,1
CONTROLLER 102317 408938 59 CONTROLLER Yes Model Compatibility List $197.44 / Each
Out Of Stock
7,8
119360 251052 80 REAR ROLLER BRACKET No Model Compatibility List $25.44 / Each

2,8,3,4,5,6
#12 X 1 1/4 102772 251607 117 #12 X 1 1/4" No Model Compatibility List $1.67 / Each

2
100178 252433 62 WARNING DECAL No Model Compatibility List $0.47 / Each

7,3,1
100280 256836 11 LATCH WRNG DECAL, ENGLISH No Model Compatibility List $1.50 / Each

7,3
119356 265332 60 LIFT FRAME No Model Compatibility List $135.62 / Each

3,10
REAR ROLLER ADJ. BOLT 100250 305744 23 REAR ROLLER ADJ. BOLT Yes Model Compatibility List $10.92 / Each

2,8
RESISTANCE ASSEMBLY 113317 316450 108 RESISTANCE ASSEMBLY Yes Model Compatibility List $64.91 / Each
10
Fat Switch Version 000698 186726 128 1 Fat Switch Version Yes Model Compatibility List $16.42 / Each

6
ISOLATOR CUSHION (Used) 1021845 226872 85 1 ISOLATOR CUSHION (Used) No Model Compatibility List $12.59 / Each

1
Rear Roller Bracket (Used) 1021831 226113 80 2 Rear Roller Bracket (Used) No Model Compatibility List $21.09 / Each

1,2
Front Drive Roller (Used) 1000034 219035 0 1 Front Drive Roller (Used) Yes Model Compatibility List $48.99 / Each

1
Bolt 3/8-16-1.50 Inches (Used) 1026116 174320 3 1 Bolt 3/8-16-1.50 Inches (Used) Yes Model Compatibility List $2.29 / Each

2,41
Cone, Resistance (Used) 1026262 226958 113 2 Cone, Resistance (Used) No Model Compatibility List $39.00 / Each
Out Of Stock
1
Motor Drive 1003221 297197 0 1 Motor Drive Yes Model Compatibility List $238.99 / Each
Out Of Stock
28
Drive Belt 20 1003636 224019 0 1 Drive Belt 20" Yes Model Compatibility List $32.99 / Each

23
Screw #8 X 1/2 1004209 013576 5 1 Screw #8 X 1/2" Yes Model Compatibility List $1.99 / Each

#8 X 3/4 1004394 013322 0 1 #8 X 3/4" Foot Pedal Screw No Model Compatibility List $5.99 / Each

Star Washer 5/16 100449 014149 . 1 Star Washer 5/16" Yes Model Compatibility List $12.99 / Each

RPM Speed Sensor Reed Switch (Used) 1005958 183185 0 1 RPM Speed Sensor Reed Switch (Used) No Model Compatibility List $18.99 / Each

47
Rear Idler Roller 1008233 235715 0 1 Rear Idler Roller Yes Model Compatibility List $107.92 / Each
Out Of Stock
8
Magnet 1009452 113842 137 1 Magnet Yes Model Compatibility List $1.10 / Each

8,1
Star Washer 1010876 014064 0 1 Star Washer No Model Compatibility List $11.99 / Each

Nylock Nut 1010890 119425 38 1 Nylock Nut Yes Model Compatibility List $0.55 / Each

2
Walking Belt Guide 1010892 198640 64 1 Walking Belt Guide Yes Model Compatibility List $18.62 / Each

15,40
Handlebar Grip 1010913 226956 0 1 Handlebar Grip Yes Model Compatibility List $19.99 / Each

11,1
Upper Body Arm Endcap 1010916 227163 0 1 Upper Body Arm Endcap No Model Compatibility List $19.99 / Each

3,1
Tinnerman Clip 1011229 133333 126 1 Tinnerman Clip Yes Model Compatibility List $0.65 / Each

2,9,1,46
Nylock Jam Nut 3/8 1011523 133945 0 1 Nylock Jam Nut 3/8" Yes Model Compatibility List $11.99 / Each

2
Reed Switch Cable Retainer Clamp 1011798 131090 114 1 Reed Switch Cable Retainer Clamp Yes Model Compatibility List $0.46 / Each

4,5,6,2,1,47
Leveler Foot Bumper 1011801 157600 23 1 Leveler Foot Bumper Yes Model Compatibility List $1.33 / Each

3,12,13,14,46,1
Cover, Front (Used) 1035138 221569 81 1 Cover, Front (Used) No Model Compatibility List $35.00 / Each

Motor Controller Board 1001217 241697 Motor Controller Board Yes Model Compatibility List $159.00 / Each
Out Of Stock
Arm Upper Left 1035385 226901A Arm Upper Left Yes Model Compatibility List $49.00 / Each
Out Of Stock
Arm Upper Right 1035384 236008A Arm Upper Right Yes Model Compatibility List $49.00 / Each

Black Jumper R-R 8 Inch 1036849 200747 Black Jumper R-R 8 Inch Yes Model Compatibility List $5.00 / Each

4,5,6
