Schwinn - 418 - 2003-2004

Repair Parts for Schwinn 418

Brand: Schwinn

Category: Residential Ellipticals

Type: Elliptical

Model Number:

Info

Model Numbers are Unique Identifiers, they are important because they lead you to access diagrams and part lists specific to the version of a given model equipment you own. Bottom line, they help you get the right part. Note: Sometimes we put a serial prefix in this field to elicit versioning, and if this field is blank that means the model name alone will suffice for part selection.

Model Name: 418

Color: Black

Version: 2003-2004

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

VIEWS

Image	Catalog #	MPN	Part List Key	Quantity On Model	Part Description	Notes	Available Used	Model Compatibility List	New price
	1025170	30003	0	1	418 SQ CNSL MST CVR FRT 2003 (Used)		No	Model Compatibility List	$9.99 / Each	1
	1024744	30004	0	1	418P CONSOLE MAST COVER REAR (Used)		No	Model Compatibility List	$9.99 / Each	1
	1024694	30015	0	1	Grip Heart Rate Assembly (Used)		No	Model Compatibility List	$9.99 / Each Out Of Stock	1
	1024745	30023	0	1	Bracket Pedal arm (Used)		No	Model Compatibility List	$24.99 / Each	1
	1024717	30109	0	1	Eye Bolt Screw Magnet Arm (Used)		No	Model Compatibility List	$9.99 / Each	1
	1024758	93314	0	1	Flywheel Eyebolt Set (Used)		No	Model Compatibility List	$11.99 / Each	1
	1026139	95694	32	1	Speed Sensor		Yes	Model Compatibility List	$44.99 / Each	4,42
	1026142	95206	10	1	Leg Extension Leg Curl Tube 0.75 Inches (Used)		No	Model Compatibility List	$14.99 / Each	1
	1026200	12662	0	1	Display Console Board (Used)		No	Model Compatibility List	$69.00 / Each	48
	1029955	84995	19		Leveler Foot (Used)		No	Model Compatibility List	$8.99 / Each Out Of Stock
	1032344	80070	0	1	Bottle Holder (Used)		Yes	Model Compatibility List	$10.00 / Each
	1032371	84995	0	1	Foot, Leveler (Used)		No	Model Compatibility List	$5.00 / Each Out Of Stock
	1032345	91652	0	1	Nut, Wing & Foot Leveler (Used)		No	Model Compatibility List	$6.99 / Each
	1035685	84995	19	2	Foot, Leveler		No	Model Compatibility List	$9.99 / Each
	1002595	30046			Speed RPM Sensor Reed Switch		Yes	Model Compatibility List	$17.99 / Each
	1002592	Icn420l8r			Drive Pulley Belt		Yes	Model Compatibility List	$34.99 / Each
	1036791	004-3793			Main Wire Harness		No	Model Compatibility List	$19.99 / Each
	1010255	seald-225			Sealed Bearing (used)		Yes	Model Compatibility List	$14.99 / Each
