Sole - E20 - 2014 Series

Repair Parts for Sole E20

Brand: Sole

Category: Residential Ellipticals

Type: Elliptical

Model Name: E20

Serial Number Prefix: 520013

Version: 2014 Series

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

Search on this page by part name

Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
213851 B060055-Q2 22 Controller Fixing Plate No Model Compatibility List $8.74 / Each

7,8
209031 B130089-Z3 45 Speaker Iron Net (R) No Model Compatibility List $14.56 / Each

1
191146 BB010056-Q2 1 No Longer Available Main Frame No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6
190237 BB030037-Q2 6 Rail, Rear No Model Compatibility List $116.40 / Each

9
191150 BB030041-Q2 6 Rail, Rear No Model Compatibility List $52.38 / Each

9
213112 BB060107-Q2 12.1 Lower Handle Bar (L) Assembly No Model Compatibility List $34.92 / Each

11
198293 BB060108-Q2 13.1 Lower Handle Bar (R) Assembly No Model Compatibility List $34.92 / Each

11
213842 BB070091-Q2 9 Incline Device No Model Compatibility List $81.24 / Each

10
190488 BB070092-Q2 2 Stablizer, Front No Model Compatibility List $34.92 / Each

1
190315 BB070093-Q2 3 Rail, Incline No Model Compatibility List $58.20 / Each

9,10
213846 BB070094-Q2 14 Idler Wheel Assembly No Model Compatibility List $34.92 / Each

8
218081 BB070095 16 Lock Tube No Model Compatibility List $8.74 / Each

3
190931 BB080004-Q2 3 Console Holder Assembly No Model Compatibility List $14.56 / Each

7
Rod, End, SH 190157 C050048-Z4 20 Rod End SH No Model Compatibility List $21.54 / Each

3
191031 C110001-Z3 182 Axle Stopper No Model Compatibility List $8.74 / Each

8
213840 C140026 5 Crank Axle No Model Compatibility List $37.49 / Each

8
209361 C145002-Q2 14 Idler Wheel Assembly No Model Compatibility List $0.00 / Each
Out Of Stock 		8
213860 E010064 36 400m/m Connecting Wire Controller No Model Compatibility List $18.74 / Each

7,8,4,5,6
190977 E010081 52 Wire, Jumper, White No Model Compatibility List $8.74 / Each

190260 E020703 37 Wire harness No Model Compatibility List $27.29 / Each

4,5,6
190978 E040007 53 200m/m Ground Wire No Model Compatibility List $10.93 / Each

Module, AC 190205 F030053 51 Module AC Yes Model Compatibility List $37.49 / Each

6
Sensor 190141 F030193 50 500mm Reed Switch Speed Sensor Yes Model Compatibility List $24.99 / Each

1
190983 F090235 56 850m/m Handpulse W/Cable Assembly (Red) No Model Compatibility List $31.24 / Each

4,5,6,12,13,14
190267 G110076 54 Motor Incline No Model Compatibility List $374.99 / Each

10
191149 G110085 54 Motor, Incline No Model Compatibility List $230.40 / Each

10
191000 J010002-ZZ 103 Hex Head Bolt Yes Model Compatibility List $2.91 / Each

2
190322 J010503-YQ 104 Screw No Model Compatibility List $2.90 / Each

2
213869 J010504-YN 105 Fastener No Model Compatibility List $2.91 / Each

2
190282 J010507A-Y3 106 Screw No Model Compatibility List $2.91 / Each

2
189931 J010510A-Z1 177 Bolt, Hex Head No Model Compatibility List $2.33 / Each

2
191184 J011004-Y1 108 Screw No Model Compatibility List $2.91 / Each

2
191185 J011006-Y1 110 Screw No Model Compatibility List $2.33 / Each

2
213872 J011006A-Y1 109 3/8" x 1-1/2" Hex Head Bolt No Model Compatibility List $2.33 / Each

2
191255 J011015A-Y3 112 Bolt Hex Head No Model Compatibility List $2.91 / Each

2
210656 J013513L-Y1 109 M10 130m/m_Hex Head Bolt No Model Compatibility List $5.83 / Each

2
Screw 190918 J020501-Y3 164 5/16" × 1/2"_Button Head Socket Bolt (ALT J020501-Z1) Yes Model Compatibility List $4.74 / Each

2
213877 J020507A-Y3 116 Fastener No Model Compatibility List $2.91 / Each

2
190158 J020520-Y3 115 Screw No Model Compatibility List $2.91 / Each

190475 J031002-Z4 113 BOLT No Model Compatibility List $2.91 / Each

2
M8 x 35m/m Socket Head Cap Bolt (Blackfast) 213876 J033007-Z4 114 M8 x 35m/m Socket Head Cap Bolt (Blackfast) No Model Compatibility List $2.74 / Each

2,9,4,5,6
213892 J080005-YR 148 M5 x 5m/m Slotted Set Screw (Blackfast) No Model Compatibility List $0.00 / Each
Out Of Stock 		2,4,5,6
190754 J092001-Y3 119 Screw No Model Compatibility List $2.33 / Each

213879 J092001-YN 118 M5 x 10m/m Phillips Head Screw No Model Compatibility List $2.91 / Each

2
190164 J092003-Y3 120 Screw No Model Compatibility List $2.91 / Each

2
213878 J094502-Y3 117 M4 x 12m/m Phillips Head Screw No Model Compatibility List $2.33 / Each

2
Nut 190740 J129021-Y3 134 Nut No Model Compatibility List $2.91 / Each

191013 J129031-Z1 138 Nut No Model Compatibility List $2.91 / Each

2
213885 J129272-ZS 131 M8 x 6.3T Nut (Blackfasl) No Model Compatibility List $2.91 / Each

2,4,5,6
190737 J139011-Y3 130 3/8" x 7.0T Nyloc Nut No Model Compatibility List $0.00 / Each
Out Of Stock
190281 J139062-Y3 129 Nut No Model Compatibility List $2.33 / Each

210966 J139062F-Y3 129 5/16" x 7T_Nyloc Nut No Model Compatibility List $0.00 / Each
Out Of Stock 		2
213884 J139411-Y3 127 M4 x 5T Nyloc Nut No Model Compatibility List $0.00 / Each
Out Of Stock 		2
218082 J160028-Z1 139.1 Nut No Model Compatibility List $2.33 / Each

2
190743 J210003-Y3 139 Washer, Flat No Model Compatibility List $2.33 / Each

190159 J210009-Y3 136 Washer, Flat No Model Compatibility List $3.49 / Each

2
213887 J210012-Y3 135 1/4" x 19m/m Flat Washer No Model Compatibility List $1.86 / Each

2
190332 J210014-Y3 137 Washer Flat No Model Compatibility List $2.75 / Each

2
213893 J210018-Y3 157 5/16" x 018 x 1.5T Flat Washer No Model Compatibility List $0.00 / Each
Out Of Stock 		2
Washer, Flat 190206 J210042-Y3 138 Washer Flat No Model Compatibility List $3.50 / Each

2
213888 J210067-Z1 141 038 x 026 x 1.5T Flat Washer No Model Compatibility List $0.00 / Each
Out Of Stock 		2
190280 J220001-Y3 143 Washer No Model Compatibility List $2.91 / Each

2
191171 J220002-Y3 144 Washer, Curved No Model Compatibility List $3.49 / Each

2
190395 J250002-Z4 176 wave washer No Model Compatibility List $2.74 / Each

2
213889 J260003-Y3 142 3/8" x 2T Split Washer No Model Compatibility List $0.00 / Each
Out Of Stock 		2
190995 J320009-Z1 163 7 x 7 x 25m/m Woodruff Key No Model Compatibility List $6.24 / Each

9
189835 J330023 153 Wrench, Allen No Model Compatibility List $8.74 / Each

2
191323 J330025-Z1 159 Wrench No Model Compatibility List $8.74 / Each

2
211222 J341007-Y3 146 3/8" x1-3/4"_Flat Head Socket Bolt No Model Compatibility List $2.33 / Each

2
190207 J341008-Y3 146 Washer, Curved No Model Compatibility List $2.33 / Each

2
190355 J367114-Y3 121 Screw No Model Compatibility List $2.33 / Each

190165 J396804-Y3 122 Screw No Model Compatibility List $2.33 / Each

213880 J396805-Y3 123 03.5 x 16m/m Sheet Metal Screw No Model Compatibility List $0.00 / Each
Out Of Stock 		2,3
213881 J517007-Y3 124 03 x 20m/m Tapping Screw No Model Compatibility List $2.33 / Each

2,12,13,14
213891 J562501-YN 147 M6 x 10m/m Thumb Head Socket Screw No Model Compatibility List $2.33 / Each

2
190239 K500042 28 Flywheel No Model Compatibility List $224.99 / Each

8
197086 L120001-A1 31 Handgrip Foam No Model Compatibility List $27.29 / Each

Rail 190240 M030011-Z0 23 Rail 567 MM No Model Compatibility List $29.28 / Each
Out Of Stock 		9
Round Cap 190986 P040050-A1 62 Round Cap No Model Compatibility List $12.49 / Each

9
Round Cap 190393 P040052-A1 80 Round Cap Yes Model Compatibility List $11.14 / Each

199086 P040135-A1 69 O25 50 2.0T_Oval End Cap No Model Compatibility List $11.24 / Each

9
Endcap, Round 190336 P040136-A1 65 Endcap Round No Model Compatibility List $6.55 / Each

4,5,6,9
218093 P050021 58 Wheel No Model Compatibility List $14.56 / Each

8
190335 P050038-A1 179 Wheel No Model Compatibility List $10.93 / Each

8
190162 P060029-A1 69 Bushing No Model Compatibility List $21.83 / Each

213863 P060112-A1 70 040 x 080 Oval End Cap No Model Compatibility List $10.93 / Each

Button Head Plug-032(1.8T) 190392 P060253-A1 61 Button Head Plug-032(1.8T) Yes Model Compatibility List $13.93 / Each

9
218104 P060264 64 Foot Pad No Model Compatibility List $8.74 / Each

9,12,13,14
Nylon Washer 190987 P060277 67 Nylon Washer No Model Compatibility List $12.49 / Each

212250 P060279 75 O25 ?25_Rubber Foot Pad No Model Compatibility List $0.00 / Each
Out Of Stock 		9,12,13,14
190324 P060440 61 Bushing No Model Compatibility List $10.93 / Each

8
Bushing 190252 P060451 62 Bushing No Model Compatibility List $6.55 / Each

8
191029 P060490-A1 181 PVC Bushing-(018.8 x1Tx40L) No Model Compatibility List $1.86 / Each

8
190203 P060549 98 Stopper No Model Compatibility List $8.24 / Each

1
190293 P100137A-JH 83 Cover, Side No Model Compatibility List $58.20 / Each

9
190294 P100138-JH 84 Cover, Side No Model Compatibility List $58.20 / Each

9
Foot Pad, Left 190202 P130015B-A1 85 Foot Pad Left Yes Model Compatibility List $49.99 / Each

9,12,13,14
Pedal, Right 190166 P130016B-A1 86 Pedal Right Yes Model Compatibility List $49.99 / Each

8,9
Handle, Front 218078 P180104-A1 89 Handle Front No Model Compatibility List $21.24 / Each

11
218096 P180105-A1 90 Handle Rear No Model Compatibility List $18.20 / Each

11
190310 P180106-A1 91 Cover Bar Right No Model Compatibility List $18.20 / Each

9
191164 P180107-A1 92 Cover Handle Rear No Model Compatibility List $18.20 / Each

9,11
191105 P190040-A1 96 Cover Incl No Model Compatibility List $74.99 / Each

9
190201 P190041-A1 97 Cover No Model Compatibility List $62.49 / Each

9
191161 P200007-A1 87 Wheel No Model Compatibility List $29.10 / Each

8
Wheel 191160 P200008-A1 88 Wheel No Model Compatibility List $15.00 / Each

8
213857 P250001-A1 35 6.5" Water-resist Rubber-(143 x94 x1.5T) No Model Compatibility List $14.56 / Each

1
211967 P250002-A1 35 Console Bottom Cover No Model Compatibility List $34.92 / Each

7,9
Bushing, Inside 190169 P270042 76 Bushing Inside No Model Compatibility List $8.74 / Each

8
Bushing, Outside 190170 P270043 77 Bushing Outside No Model Compatibility List $8.74 / Each

8
Bushing 190175 P270044 78 Bushing No Model Compatibility List $8.73 / Each

8
Bushing 190176 P270045 79 Bushing No Model Compatibility List $6.55 / Each

8
198283 RBB060107-Q2 12 LOWER HANDLE BAR (LEFT)(ORDER RBB060107-Q2) No Model Compatibility List $162.49 / Each

11
214170 RBB060108-Q2 13 Lower Handle Bar Right No Model Compatibility List $162.49 / Each

11
190217 RP050055A-PU 59.1 Wheel No Model Compatibility List $21.83 / Each

8
202069 RTT040466-Q2 18.1 Upper Swing Arm (L) Assembly No Model Compatibility List $125.00 / Each

3
201805 RTT040468-Q2 19 Swing Arm (R)(ORDER RTT040468-Q2) No Model Compatibility List $125.00 / Each

3
201791 TT040466-Q2 18 Swing Arm (L)(ORDER RTT040466-Q2) No Model Compatibility List $0.00 / Each
Out Of Stock 		3
210990 J139361F-Y3 132 M10 8T_Nyloc Nut No Model Compatibility List $0.00 / Each
Out Of Stock 		2
190201 P190041-A1 95 1 Cover No Model Compatibility List $62.49 / Each

9
190203 P060549 96 4 Stopper No Model Compatibility List $8.24 / Each

1
190205 F030053 1 Module AC Yes Model Compatibility List $37.49 / Each

6
190296 2 Kit, Hardware Yes Model Compatibility List $21.83 / Each

1
191191 4 Cover, Side Yes Model Compatibility List $14.56 / Each

9
191201 35 34 Wire harness Yes Model Compatibility List $17.46 / Each

4,5,6
194740 2 Console Overlay Yes Model Compatibility List $34.92 / Each

7
200352 6.1 1 Rear Rail Assembly Yes Model Compatibility List $116.40 / Each

9
210287 2 Poly sticker on consloe (SOLE E20) Yes Model Compatibility List $14.56 / Each

1
210511 1 Carton Yes Model Compatibility List $25.61 / Each

1
Cover, Incl 1033510 P190040-A1 0 1 Cover, Incl (Used) No Model Compatibility List $29.00 / Each

9
Cover 1030005 P190041-A1 0 1 Cover, Bar, Rear (Used) No Model Compatibility List $29.00 / Each
Out Of Stock 		9
Bearing, Sealed 4000000 K056005 6005_Bearing No Model Compatibility List $21.24 / Each

8
4000001 K056203 6203_Bearing No Model Compatibility List $16.24 / Each

8
Pulley, Drive 4000002 P060090-A1 O330_Drive Pulley (P060090-A1) Yes Model Compatibility List $43.74 / Each

8
4000008 P060252 O25 O25 15T_Rubber Foot Pad No Model Compatibility List $11.24 / Each

4000010 E020151 WIRING HARNESS MAIN 1000MM XE100/350/550E/VE/WE55/95 No Model Compatibility List $24.99 / Each

4000046 F080045 Power Adaptor-(INPUTAC120V/60HZ/27WOUTPUT DC12V/1.5A +2.0DC) No Model Compatibility List $48.74 / Each

4000048 BB080004-Q13 Console Holder Assembly No Model Compatibility List $24.99 / Each

4000049 P060278 5/16" 25 3T_Nylon Washer No Model Compatibility List $2.74 / Each

4000078 M030020-Z0 Aluminum Rail (38.22.5T590) No Model Compatibility List $43.74 / Each

4000079 D080200-01 Gear Motor (D080200) No Model Compatibility List $49.99 / Each
Out Of Stock
4000080 F030158 300m/m_Sensor W/Cable No Model Compatibility List $31.24 / Each

4
4000081 RP050040 O82_Slide Wheel Urethane No Model Compatibility List $31.24 / Each

4000082 J010520-XB 5/16" 15mm_Hex Head Bolt No Model Compatibility List $2.74 / Each

4000083 D080306 Console Display Board No Model Compatibility List $237.49 / Each

4000120 F080062 Power Adaptor No Model Compatibility List $31.24 / Each

4000137 RBB030037-Q2 Rear Rail Assembly No Model Compatibility List $137.49 / Each

4000138 RBB050147-Q2 Pedal Arm (R) Assembly E20 2014 No Model Compatibility List $112.49 / Each

4000139 RBB020075-Q2 Console Mast Assembly No Model Compatibility List $99.99 / Each

4000140 RZ5TE003C-20 Console Assembly (RZ5TE003C-20) No Model Compatibility List $311.25 / Each

4000141 D080300 Console Display Board (TZ-4630 - E2/E20) No Model Compatibility List $162.49 / Each

4000142 D080900 Receiver HR-(TZ-RF 300mm) No Model Compatibility List $74.99 / Each

4000143 RP100137AB-JH Side Case (L) No Model Compatibility List $74.99 / Each

4000144 RP100138B-JH Side Case(R)+Sticker No Model Compatibility List $74.99 / Each

4000145 J99B0080-01 Hardware Kit (SOLE Logo E20) No Model Compatibility List $18.75 / Each

Cord, Power, 110V 1001371 E060001 Right Angle Power Supply Cord Yes Model Compatibility List $24.99 / Each

Power Cord 110 Volt 1010033 pwr-crd-033 Power Cord 110 Volt Yes Model Compatibility List $19.99 / Each

View Drawing

general Info

Customer Service

About us

Address

6114 Madison Ct.
Morton Grove, IL 60053
847-309-2818

Hydra Fitness Exchange © 2024. All Rights Reserved.

Payment options
