Weider - 8700 I

Repair Parts for Weider 8700 I WEEVSY308100

Brand: Weider

Category: 1 Stack Gym

Type: Strength Systems

Model Name: 8700 I

Exploded Diagrams

Other Languages Available
loader

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

Search on this page by part name

Catalog #
MPN
Part List Key
Quantity On Model
Part Description
Notes
Available Used
Model Compatibility List
New price
Weight Plate 12.5lb (Used) 1029213 120294 0 1 Weight Plate 12.5lb (Used) No Model Compatibility List $17.99 / Each
Out Of Stock 		3
V groove pulley 3.5 1029232 155878 0 1 V groove pulley 3.5" (Used) No Model Compatibility List $29.99 / Each
Out Of Stock 		8
Screw (Used) 1032516 208581 0 1 Screw (Used) No Model Compatibility List $1.79 / Each

2
166786 302055 1 BASE No Model Compatibility List $306.20 / Each

3
166787 307466 2 STABILIZER No Model Compatibility List $186.52 / Each

1
166788 302051 3 UPRIGHT No Model Compatibility List $529.79 / Each

3
166789 302049 4 TOP FRAME No Model Compatibility List $212.88 / Each

3
166790 302056 5 PIVOT FRAME No Model Compatibility List $201.10 / Each

8,3
166791 302060 6 SEAT TUBE No Model Compatibility List $134.65 / Each

3,12,13,14
166792 302057 7 FRONT LEG No Model Compatibility List $178.77 / Each

1
166793 307467 8 LEG LEVER No Model Compatibility List $126.56 / Each

3
166794 302074 9 RIGHT ARM No Model Compatibility List $166.64 / Each

3
166795 302075 10 LEFT ARM No Model Compatibility List $166.64 / Each

3
116969 267615 11 HANDLE No Model Compatibility List $78.80 / Each

11
116842 224344 12 SQUARE PLATE No Model Compatibility List $15.98 / Each

1
166796 267613 13 CURL POST No Model Compatibility List $101.74 / Each

12,13,14
166797 302103 14 CURL PAD No Model Compatibility List $181.10 / Each

12,13,14
166798 302034 15 SEAT No Model Compatibility List $176.04 / Each

12,13,14
166799 307324 16 BACKREST No Model Compatibility List $222.39 / Each

4,5,6,12,13,14
166800 307464 17 LEFT SHROUD No Model Compatibility List $468.64 / Each

12,13,14
166801 307465 18 RIGHT SHROUD No Model Compatibility List $352.86 / Each

12,13,14
117039 301325 19 SHROUD SUPPORT No Model Compatibility List $18.49 / Each

3,12,13,14
117040 301495 20 CARRIAGE BOLT BUSHING No Model Compatibility List $1.44 / Each

2,8
117041 322249 21 WEIGHT GUIDE No Model Compatibility List $197.45 / Each

3
WEIGHT 116815 120294 22 WEIGHT No Model Compatibility List $49.82 / Each

3
WEIGHT TUBE CAP 102192 122691 23 WEIGHT TUBE CAP No Model Compatibility List $2.32 / Each

9,3
117042 302064 24 WEIGHT SELECTOR No Model Compatibility List $82.02 / Each

3
SEAT KNOB 106310 140950 25 SEAT KNOB No Model Compatibility List $21.29 / Each

12,13,14
WEIGHT PIN 116904 193926 26 WEIGHT PIN No Model Compatibility List $19.61 / Each

3,12,13,14
SLIDE BUMPER 104472 194795 27 SLIDE BUMPER No Model Compatibility List $19.98 / Each

1
102161 208378 28 FOAM PAD No Model Compatibility List $29.17 / Each

3,12
SHORT PAD TUBE 114249 265367 29 SHORT PAD TUBE No Model Compatibility List $48.05 / Each

3,12,13,14
50MM ROUND INT ENDCAP 104523 172066 30 50MM ROUND INT ENDCAP No Model Compatibility List $6.97 / Each

9,4,5,6
114026 110913 31 50MM SQUARE INT ENDCAP No Model Compatibility List $1.29 / Each

9,4,5,6
116851 224363 32 38MM SQUARE OUTER CAP No Model Compatibility List $10.13 / Each

9
MOTOR WASHER 100790 014039 33 MOTOR WASHER No Model Compatibility List $3.56 / Each

19MM ROUND INNER CAP 113816 239042 34 19MM ROUND INNER CAP No Model Compatibility List $5.99 / Each

9
117043 267639 35 LAT BAR No Model Compatibility List $129.05 / Each

1
116908 332404 36 HANDGRIP No Model Compatibility List $20.15 / Each

11
100886 103087 37 CABLE CLIP No Model Compatibility List $15.20 / Each

1,2,4,5,6
117044 302059 38 FOOT PLATE No Model Compatibility List $219.45 / Each

9
166802 302078 39 CABLE PIVOT No Model Compatibility List $19.45 / Each

8,4,5,6
117046 270564 40 ARM PIN No Model Compatibility List $30.76 / Each

3,12,13,14
104633 214126 41 FULL PULLEY GUARD No Model Compatibility List $28.35 / Each

8,9,3
116855 200877 42 LARGE FOAM PAD No Model Compatibility List $64.13 / Each

12,13,14
102167 214118 43 HALF FINGER GUARD No Model Compatibility List $7.85 / Each
Out Of Stock 		9,3
116856 215142 44 ARM BUSHING No Model Compatibility List $12.15 / Each

8,3
114724 267617 45 U-BRACKET No Model Compatibility List $52.67 / Each

2,3,4,5,6
V-PULLEY 104483 155878 46 V-PULLEY No Model Compatibility List $72.77 / Each

8
THIN PULLEY 116858 214226 47 THIN PULLEY No Model Compatibility List $76.19 / Each

8
SMALL PULLEY 100863 226917 48 SMALL PULLEY No Model Compatibility List $71.96 / Each

8
101865 234235 49 M4.2 X 18MM SCREW No Model Compatibility List $0.74 / Each

2
104634 194082 50 LARGE CABLE TRAP No Model Compatibility List $6.97 / Each

4,5,6
100866 194081 51 CABLE TRAP No Model Compatibility List $4.42 / Each

4,5,6
13MM SPACER 116859 214060 52 13MM SPACER No Model Compatibility List $4.31 / Each

2,3,4,5,6
117047 302110 53 LOW CABLE No Model Compatibility List $97.37 / Each

4,5,6
M10 Locknut 1005195 148710 53 1 M10 Locknut No Model Compatibility List $1.57 / Each

2
117048 305197 54 ARM CABLE No Model Compatibility List $117.19 / Each

3,4,5,6
HIGH CABLE 117049 302109 55 HIGH CABLE No Model Compatibility List $99.85 / Each

4,5,6
M10 LOCKNUT 100540 148710 56 M10 LOCKNUT No Model Compatibility List $1.57 / Each

2
IDLER WHEEL WASHER 100263 014132 57 IDLER WHEEL WASHER No Model Compatibility List $2.43 / Each

5/16 100472 014073 59 5/16" WASHER Yes Model Compatibility List $1.25 / Each

116863 213899 60 LEG BUMPER No Model Compatibility List $17.48 / Each

1
166803 302081 61 BACKREST FRAME No Model Compatibility List $108.13 / Each

3,4,5,6,12,13,14
116773 135884 62 M6 X 16MM SCREW No Model Compatibility List $1.33 / Each

2
116975 267618 63 DOUBLE U-BRACKET No Model Compatibility List $68.75 / Each

2,3,4,5,6
117051 245935 64 M6 X 32MM SCREW No Model Compatibility List $2.16 / Each

2
116866 200521 65 M8 X 20MM SHOULDER BOLT No Model Compatibility List $5.35 / Each

2
104498 152125 66 M10 X 50MM BOLT No Model Compatibility List $10.55 / Each

2
117052 306495 67 M10 X 86MM CARRIAGE BOLT No Model Compatibility List $15.96 / Each

2
114267 129147 68 M8 X 65MM SCREW No Model Compatibility List $6.67 / Each

2
M4 X 19MM SCREW 100588 194878 69 M4 X 19MM SCREW Yes Model Compatibility List $2.16 / Each

2
117053 225226 70 20MM X 40MM INNER CAP No Model Compatibility List $0.52 / Each

9
M10 X 68MM BOLT 101789 144781 71 M10 X 68MM BOLT No Model Compatibility List $11.72 / Each

2
116736 247632 72 M10 X 130MM BOLT No Model Compatibility List $9.52 / Each

2
166804 302080 73 SEAT FRAME No Model Compatibility List $108.42 / Each

3,12,13,14
104586 165356 74 M10 X 25MM BOLT No Model Compatibility List $6.67 / Each

2
102213 132889 75 M10 X 63MM BOLT No Model Compatibility List $9.39 / Each

2
117055 306494 76 M10 X 64MM BOLT SET No Model Compatibility List $19.83 / Each

2
100557 208581 77 M10 X 25MM BOLT No Model Compatibility List $3.73 / Each

2
M4 X 12MM MACHINE SCREW (New) 108957 251429 78 M4 X 12MM MACHINE SCREW (New) No Model Compatibility List $11.99 / Each

2,4,5,6
104501 132654 79 M10 X 77MM BOLT No Model Compatibility List $11.75 / Each

2
104529 115177 80 HANDLE No Model Compatibility List $40.40 / Each

11
104527 194561 81 M10 X 46MM BOLT No Model Compatibility List $8.11 / Each

2
1/4 100042 014063 82 1/4" FLAT WASHER No Model Compatibility List $1.03 / Each

117056 302139 83 CHAIN No Model Compatibility List $64.72 / Each

1
M12 NUT 106328 194903 84 M12 NUT Yes Model Compatibility List $3.03 / Each

2
106117 194746 85 2" WASHER No Model Compatibility List $10.64 / Each

2
Nut 1010424 194903 85 1 Nut Yes Model Compatibility List $3.03 / Each

2
116918 198678 87 M8 X 63MM CARRIAGE BOLT No Model Compatibility List $4.31 / Each

2
100876 224989 88 LOCK No Model Compatibility List $5.91 / Each

1
100875 186308 89 LOCK PIN No Model Compatibility List $13.68 / Each

12,13,14
117057 302528 90 SHROUD CLAMP No Model Compatibility List $7.85 / Each

4,5,6,12,13,14
117058 301369 91 LONG KNOB No Model Compatibility List $20.72 / Each

1
WEIGHT REST CAP 113811 162910 92 WEIGHT REST CAP No Model Compatibility List $8.60 / Each

9,3
117059 225227 93 25MMX40MM THICK INNER CAP No Model Compatibility List $1.03 / Each

9
M8 Locknut 1011772 012042 102B 1 M8 Locknut Yes Model Compatibility List $11.99 / Each

M4 X 19MM Screw 1010459 194878 133 1 M4 X 19MM Screw Yes Model Compatibility List $2.16 / Each

2
Screw M4 X 19MM 1011824 194878 133 1 Screw M4 X 19MM Yes Model Compatibility List $2.16 / Each

2
LUBE, GREASE 100396 104838 # LUBE, GREASE No Model Compatibility List $6.19 / Each

1,15
100602 166909 # PAD FRAME WARNING DECAL No Model Compatibility List $1.84 / Each

1,3,7,12,13,14
112260 233881 # DECAL, WRNG SITE, 9 LANG No Model Compatibility List $3.34 / Each

7,3
166185 288996 # DECAL, GEN WARNING, 9LANG No Model Compatibility List $13.52 / Each

7,3
166806 306384 # DECAL, GENERAL WARNING No Model Compatibility List $0.69 / Each

7,3
166807 307326 # USER-S MANUAL No Model Compatibility List $0.00 / Each
Out Of Stock 		1
166808 307327 # USER-S MANUAL, SPANISH No Model Compatibility List $0.00 / Each
Out Of Stock 		1
166809 307328 # USER-S MANUAL, FRENCH No Model Compatibility List $0.00 / Each
Out Of Stock 		1
166810 307329 # USER-S MANUAL, GERMAN No Model Compatibility List $0.00 / Each
Out Of Stock 		1
166811 307330 # USER-S MANUAL, ITALIAN No Model Compatibility List $0.00 / Each
Out Of Stock 		1
166812 307331 # USER-S MANUAL, DUTCH No Model Compatibility List $0.00 / Each
Out Of Stock 		1
166813 307332 # USER-S MANUAL, PRTGS No Model Compatibility List $0.00 / Each
Out Of Stock 		1
166805 400945 # EXERCISE GUIDE No Model Compatibility List $17.16 / Each

1
5MM ALLEN WRENCH 100604 045008 # 5MM ALLEN WRENCH Yes Model Compatibility List $3.85 / Each

6MM ALLEN WRENCH 100541 045021 # 6MM ALLEN WRENCH Yes Model Compatibility List $5.28 / Each

1
Locking Nut 21-CD7-KR (Used) 1007264 060714 Locking Nut 21-CD7-KR (Used) Yes Model Compatibility List $7.79 / Each

1
